Intel Iris Xe Graphics G7 80EUs

Intel Iris Xe G7 80EUs

英特尔Xe显卡G780EU(80EU虎湖UGPU)是中端虎湖UCPU(15-28瓦特,例如酷睿i5第11代CPU)的集成显卡。 正在使用新的Xe体系结构(Gen12),预计2020年后发表。

性能取决于笔记本电脑的TDP设置和使用冷却设备。 根据第一个信息,芯片可以设置为 15W 和 28W TDP(作为 Ice Lake-U 芯片),并且性能必须在 3D Mark 基准的专用 GeForce MX330 附近。 由于缺少专用图形内存和驱动程序支持,游戏性能可能会下降。 与以前的Iris Plus G4相比,Tiger Lake GPU的速度应该快两倍。 从各种笔记本电脑的基准来看,80EU版本比96EU更快,比MX330低18%。 与AMD iGPU相比,G780EU位于Vega 7和Vega 8芯片周围(详情见下图)。

因此,iGPU仅适用于要求苛刻的游戏中最低的图形设置和低分辨率。 Days Gone或Cyberpunk等现代游戏中,最低设定值不会超过30fps(参照下文)。

Tiger Lake SoCs 和集成 GPU 在英特尔采用最新的 10nm+ (10nm Superfin) 工艺(改进的 10nm 工艺)制造,因此效率非常高。

Gen. 12 / Xe Series
Iris Xe G7 96EUs 96 @ 0.4 - 1.35 GHz
Iris Xe G7 80EUs 80 @ 0.4 - 1.35 GHz
UHD Graphics 64EUs 64 @ 1.4 GHz
UHD Graphics Xe G4 48EUs 48 @ 0.35 - 1.45 GHz
UHD Graphics Xe 32EUs (Tiger Lake-H) 32 @ 0.35 - 1.45 GHz
UHD Graphics Xe 750 32EUs 32 @ 0.35 - 1.45 GHz
UHD Graphics Xe 16EUs (Tiger Lake-H) 16 @ 0.35 - 1.45 GHz
CodenameTiger Lake Xe
ArchitectureGen. 11 Ice Lake
Pipelines80 - unified
Core Speed400 - 1350 (Boost) MHz
Shared Memoryyes
APIDirectX 12_1, OpenGL 4.6
Power Consumption28 Watt
technology10 nm
FeaturesQuickSync
Date of Announcement15.08.2020
CPU in Iris Xe G7 80EUsGPU Base SpeedGPU Boost / Turbo
Intel Core i5-12600H12 x 2000 MHz, 45 W? MHz1400 MHz
Intel Core i5-12500H12 x 1800 MHz, 45 W? MHz1300 MHz
Intel Core i5-1250P12 x 1200 MHz, 28 W? MHz1400 MHz
min. - max.400 MHz850 - 1400 MHz

Benchmarks

Performance Rating - 3DMark 11 + Fire Strike + Time Spy
8.9 pt (10%)
Intel HD Graphics (Bay Trail) -89%
...
AMD Radeon R9 M280X -5%
AMD Radeon RX Vega 9 -5%
NVIDIA GeForce GTX 760M -3%
Intel Iris Xe Graphics G7 80EUs
AMD Radeon R9 M385X 2%
AMD FirePro M5100 2%
NVIDIA Quadro K3100M 2%
NVIDIA GeForce GTX 765M 3%
NVIDIA GeForce GTX 1050 Max-Q 3%
NVIDIA Quadro P2000 Max-Q 4%
...
0%
100%
3DMark - 3DMark Time Spy Score
min: 833     avg: 1261     median: 1274 (7%)     max: 1689 Points
3DMark - 3DMark Time Spy Graphics
min: 743     avg: 1128     median: 1145 (5%)     max: 1511 Points
Intel UHD Graphics 605 -90%
...
NVIDIA Quadro P520 -11%
AMD Radeon R9 M280X -10%
AMD Radeon RX 550X (Laptop) -7%
AMD Radeon Pro 555 -4%
AMD Radeon Pro 455 -1%
Intel Iris Xe Graphics G7 80EUs
NVIDIA GeForce GTX 960M 2%
NVIDIA Quadro P600 3%
AMD Radeon Pro 560 22%
NVIDIA Quadro P620 23%
NVIDIA Quadro P1000 24%
...
0%
100%
3DMark - 3DMark Ice Storm Unlimited Graphics
min: 106742     avg: 150178     median: 159077 (21%)     max: 173584 Points
3DMark - 3DMark Ice Storm Extreme Graphics
min: 27687     avg: 53627     median: 62965 (9%)     max: 74754 Points
3DMark - 3DMark Cloud Gate Score
min: 11341     avg: 15310     median: 15250 (19%)     max: 19800 Points
3DMark - 3DMark Cloud Gate Graphics
min: 12824     avg: 21206     median: 20668.5 (8%)     max: 30894 Points
3DMark - 3DMark Fire Strike Standard Score
min: 1680     avg: 3210     median: 3087 (8%)     max: 4445 Points
3DMark - 3DMark Fire Strike Standard Graphics
min: 1990     avg: 3587     median: 3435.5 (6%)     max: 4847 Points
3DMark - 3DMark Ice Storm Graphics
min: 25199     avg: 73725     median: 85777 (11%)     max: 93077 Points
3DMark - 3DMark Night Raid
min: 7611     avg: 12532     median: 12873 (16%)     max: 15740 Points
3DMark - 3DMark Night Raid Graphics Score
min: 7524     avg: 14046     median: 14522 (8%)     max: 19367 Points
3DMark 11 - 3DM11 Performance Score
min: 3453     avg: 5370     median: 5398 (11%)     max: 6566 Points
3DMark 11 - 3DM11 Performance GPU
min: 3480     avg: 5194     median: 5295.5 (8%)     max: 6120 Points
...
NVIDIA GeForce GTX 860M -5%
NVIDIA GeForce GTX 770M -4%
AMD Radeon RX Vega 7 -3%
NVIDIA Quadro M2000M -1%
AMD Radeon Pro 555 0%
Intel Iris Xe Graphics G7 80EUs
NVIDIA GeForce GTX 960M 2%
AMD Radeon Pro 560 2%
AMD Radeon RX 550X (Laptop) 3%
AMD Radeon Pro 455 4%
AMD FirePro M6100 5%
...
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
min: 23181     avg: 23526     median: 23526 (36%)     max: 23871 Points
Unigine Valley 1.0 - Unigine Valley 1.0 DX
17.4 fps (8%)
Unigine Heaven 3.0 - Unigine Heaven 3.0 DX 11
43.8 fps (14%)
Unigine Heaven 3.0 - Unigine Heaven 3.0 OpenGL
57.3 fps (25%)
Unigine Heaven 2.1 - Heaven 2.1 high
63.2 fps (12%)
...
AMD Radeon R9 M385X -8%
NVIDIA Quadro M1000M -1%
NVIDIA GeForce GTX 770M -1%
Intel Iris Xe Graphics G7 80EUs
NVIDIA Quadro P1000 0%
NVIDIA GeForce GTX 960M 9%
NVIDIA GeForce GTX 860M 9%
NVIDIA GeForce GT 755M SLI 13%
AMD FirePro M6100 14%
NVIDIA Quadro M2000M 15%
...
0%
100%
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
min: 13678     avg: 14168     median: 13805 (59%)     max: 15022 points
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 55.6     avg: 60.5     median: 59.6 (22%)     max: 68.87 fps
Cinebench R15
Cinebench R15 OpenGL 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL 64 Bit
min: 38.2     avg: 84.2     median: 86.4 (23%)     max: 103 fps
Cinebench R15 OpenGL Ref. Match 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
97.8 % (98%)
GFXBench (DX / GLBenchmark) 2.7
GFXBench 2.7 T-Rex HD Onscreen C24Z16 +
GFXBench (DX / GLBenchmark) 2.7 - GFXBench 2.7 T-Rex HD Onscreen C24Z16
157.5 fps (5%)
GFXBench T-Rex HD Offscreen C24Z16 +
GFXBench (DX / GLBenchmark) 2.7 - GFXBench T-Rex HD Offscreen C24Z16
256.9 fps (2%)
GFXBench 3.0 - GFXBench 3.0 Manhattan
86.6 fps (24%)
GFXBench 3.0 - GFXBench 3.0 Manhattan Offscreen
170.4 fps (13%)
GFXBench - GFXBench 5.0 Aztec Ruins High Tier Onscreen
32.4 fps (21%)
GFXBench - GFXBench 5.0 Aztec Ruins High Tier Offscreen
min: 38.68     avg: 43.1     median: 43.1 (14%)     max: 47.5 fps
...
AMD Radeon RX Vega 8 (Ryzen 2000/3000) -49%
Intel Iris Plus Graphics G4 (Ice Lake 48 EU) -49%
AMD Radeon RX Vega 10 -46%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) -44%
AMD Radeon 540X -42%
AMD Radeon RX Vega 7 -38%
NVIDIA Quadro P520 -31%
AMD Radeon RX 550X (Laptop) -22%
Intel Iris Xe Graphics G7 80EUs
NVIDIA GeForce GTX 1050 Max-Q 12%
NVIDIA GeForce GTX 1050 Ti Max-Q 15%
AMD Radeon RX 560X (Laptop) 22%
NVIDIA Quadro T2000 Max-Q 50%
Apple M1 7-Core GPU 68%
...
Apple M1 Max 32-Core GPU 620%
0%
100%
GFXBench - GFXBench 5.0 Aztec Ruins Normal Tier Onscreen
50.5 fps (25%)
GFXBench - GFXBench 5.0 Aztec Ruins Normal Tier Offscreen
min: 91.4     avg: 105.8     median: 105.8 (14%)     max: 120.1 fps
GFXBench - GFXBench Car Chase Onscreen
40.9 fps (1%)
GFXBench - GFXBench Car Chase Offscreen
91.4 fps (0%)
LuxMark v2.0 64Bit - LuxMark v2.0 Room GPU
min: 286     avg: 489     median: 489 (2%)     max: 692 Samples/s
LuxMark v2.0 64Bit - LuxMark v2.0 Sala GPU
min: 1176     avg: 1685     median: 1685 (3%)     max: 2194 Samples/s
ComputeMark v2.1 - ComputeMark v2.1 Result
min: 2634     avg: 2950     median: 2950 (6%)     max: 3267 points
Power Consumption - Furmark Stress Test Power Consumption - external Monitor *
min: 17.4     avg: 33.1     median: 33 (5%)     max: 50.4 Watt
