NVIDIA GeForce RTX 4090

NVIDIA GeForce RTX 4090

Nvidia GeForce RTX 4090是基于AD102芯片的高端桌面显卡，采用Ada Lovelace架构。4090提供了18,432个内核中的16,384个和24GB GDDR6X显存，拥有384位内存总线，时钟为21Gbits。由于有128个专用的光线追踪核心，该卡提供了出色的光线追踪性能。对于人工智能计算（和游戏中的DLSS 3），RTX 4090有512个Tensor核心。

游戏性能非常适用于最大细节设置的4k游戏。在大多数游戏中，甚至可以在没有DLSS的情况下使用Raytracing效果。与竞争对手相比，RTX 4090是2022年最快的显卡，AMD Radeon RX 7900 XTX和RTX 4080位居第二。

AD102 chp是在台积电的现代4纳米工艺制造的（4N与EUV），指定的TGP（总图形功率）为450瓦。Nvidia为RTX4090推荐了850瓦的电源。

GeForce RTX 4000 Series

GeForce RTX 4090 16384 @ 2.24 - 2.52 GHz384 Bit @ 21000 MHz
GeForce RTX 4080 Super 10240 @ 2.3 - 2.55 GHz256 Bit @ 23000 MHz
GeForce RTX 4080 9728 @ 2.21 - 2.51 GHz256 Bit @ 22400 MHz
GeForce RTX 4070 Ti SUPER 8448 @ 2.34 - 2.61 GHz256 Bit @ 21000 MHz
GeForce RTX 4070 Ti 7680 @ 2.31 - 2.61 GHz192 Bit @ 21000 MHz
GeForce RTX 4070 SUPER 7168 @ 1.98 - 2.48 GHz192 Bit @ 21000 MHz
GeForce RTX 4070 5888 @ 1.92 - 2.48 GHz192 Bit @ 21000 MHz
GeForce RTX 4060 Ti 16G 4352 @ 2.31 - 2.54 GHz128 Bit @ 18000 MHz
GeForce RTX 4060 Ti 8G 4352 @ 2.31 - 2.54 GHz128 Bit @ 18000 MHz
GeForce RTX 4060 3072 @ 1.83 - 2.46 GHz128 Bit @ 17000 MHz
CodenameAD102-300-A1
ArchitectureAda Lovelace
Pipelines16384 - unified
TMUs512
ROPs176
Raytracing Cores128
Tensor / AI Cores512
Core Speed2235 - 2520 (Boost) MHz
Theoretical Performance82.6 TFLOPS FP16, 82.6 TFLOPS FP32
AI GPU1321 TOPS INT8
CacheL2: 72 MB
Memory Speed21000 effective = 1313 MHz
Memory Bus Width384 Bit
Memory TypeGDDR6X
Max. Amount of Memory24 GB
Shared Memoryno
Memory Bandwidth1008 GB/s
APIDirectX 12 Ultimate, Shader 6.7, OpenGL 4.6, OpenCL 3.0, Vulkan 1.3
Power Consumption450 Watt
Transistor Count76.3 Billion
Die Size 608 mm²
Man. Technology5 nm
Displays4 Displays (max.), HDMI 2.1, DisplayPort 1.4a
Date of Announcement20.09.2022
Link to Manufacturer Pagewww.nvidia.com
PredecessorGeForce RTX 3090

Benchmarks

Performance Rating - 3DMark 11 + Fire Strike + Time Spy
33.3 pt (100%)
AMD Radeon HD 8180
0.0639 -100%
...
NVIDIA GeForce RTX 4080
26 -22%
AMD Radeon RX 6950 XT
26.3 -21%
AMD Radeon RX 9070
26.6 -20%
AMD Radeon RX 9070 XT
27.4 -18%
AMD Radeon RX 7900 XT
27.9 -16%
NVIDIA GeForce RTX 5080
28.3 -15%
AMD Radeon RX 7900 XTX
29.4 -12%
NVIDIA GeForce RTX 5070 Ti
31 -7%
NVIDIA GeForce RTX 5090
31.9 -4%
NVIDIA GeForce RTX 4090
33.3
0%
100%
Restrict / Search: Model: Max. age: years
3DMark - 3DMark Speed Way Score
min: 9800     avg: 10105     median: 10133.5 (68%)     max: 10302 Points
+ 28 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Steel Nomad
min: 8985     avg: 9538     median: 9249.5 (64%)     max: 10389 Points
+ 20 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Steel Nomad Light
min: 40837     avg: 42772     median: 43338 (99%)     max: 43729 Points
+ 7 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Wild Life Unlimited
min: 174004     avg: 187234     median: 189194 (95%)     max: 198505 Points
+ 3 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Wild Life Extreme Unlimited
86227 Points (100%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Solar Bay
min: 188399     avg: 192245     median: 190208 (78%)     max: 201611 Points
+ 13 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Score
min: 39525     avg: 51329     median: 52237 (79%)     max: 59532 Points
+ 37 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Graphics
min: 55924     avg: 74454     median: 75641 (69%)     max: 88564 Points
+ 37 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Graphics
min: 513138     avg: 723668     median: 724802 (80%)     max: 903610 Points
+ 29 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Time Spy Score
min: 24181     avg: 30155     median: 30520 (79%)     max: 34682 Points
+ 39 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Time Spy Graphics
min: 28308     avg: 35933     median: 36671 (75%)     max: 37809 Points
+ 39 benchmarks and specifications   - Hide comparison chart
Qualcomm Adreno 618
112 -100%
...
NVIDIA GeForce RTX 5090 Laptop
23736 -34%
AMD Radeon RX 7900 XT
26376 -27%
AMD Radeon RX 9070
26512 -26%
NVIDIA GeForce RTX 4080
27394 -24%
NVIDIA GeForce RTX 5070 Ti
27541 -23%
NVIDIA GeForce RTX 4080 Super
28344 -21%
AMD Radeon RX 9070 XT
30021 -16%
AMD Radeon RX 7900 XTX
31462 -12%
NVIDIA GeForce RTX 5080
32333 -10%
NVIDIA GeForce RTX 4090
35933
NVIDIA GeForce RTX 5090
44063 23%
0%
100%
Restrict / Search: Model: Max. age: years
3DMark - 3DMark Ice Storm Unlimited Graphics
min: 650505     avg: 790070     median: 787951 (80%)     max: 990769 Points
+ 28 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Extreme Graphics
min: 468296     avg: 682848     median: 678512 (79%)     max: 853906 Points
+ 29 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Score
min: 57157     avg: 84293     median: 84332 (80%)     max: 105843 Points
+ 29 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Graphics
min: 172708     avg: 269500     median: 260357 (64%)     max: 406437 Points
+ 29 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Night Raid
min: 51233     avg: 87054     median: 87344 (82%)     max: 105987 Points
+ 27 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Night Raid Graphics Score
min: 120914     avg: 209526     median: 209923 (81%)     max: 259910 Points
+ 27 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance Score
min: 48408     avg: 63532     median:
