AMD Radeon HD 8750M

AMD Radeon HD 8750M

AMD Radeon HD 8750M（有时也被称为了ATI Mobility Radeon HD 8750）是DirectX 11.1显卡的笔记本电脑。它是基于火星芯片（GCN架构的28nm）384着色器核心，24 TMUs，16个ROPs。核心的时钟频率在620 - 775兆赫（670 - 825 MHz的升压），并可以访问DDR3或GDDR5 VRAM（1000兆赫），根据型号不同。的Radeon HD 8750M的性能应该是在范围内的GeForce GT 640M LE。当前和要求苛刻的游戏“孤岛惊魂3（或多或少）流利运行在中等分辨率和细节设置。 384着色器可以使用与OpenCL 1.2通用计算的（8计算单位）。老万亿次芯片相比，基于GCN-火星的体系结构提供了更好的性能，在此框架内。特色的8750M包括通过UVD3视频解码进行解码的MPEG-4 AVC/H.264，VC-1，MPEG-2，和Flash直接从AMD GPU。多视图编解码器（MVC）和MPEG-4的第2部分（DIVX，XVID）的高清视频是目前兼容。 8700M系列还支持集成的GPU和独立显卡之间的自动显卡切换。耐力赛，这项技术取代了AMD的动态切换显卡，是类似于NVIDIA的Optimus。另外，8750M可以直接支持2个连接显示器如果耐力赛被禁止使用Eyefinity技术。的8700M系列的其它特征包括ZeroCore为降低功耗，当显示器关闭和电源选通区域中未使用的芯片断电。 PowerTune允许的显卡的GPU自动超频和降频是在其TDP限制。例如，该芯片可以降频运行时的FurMark和OCCT，但会在某些游戏如“失落的星球”，“孤岛危机”，“生化危机5超频。集成的HD音频处理器能够通过HDMI和DisplayPort（例如，蓝光视频）传输高清音频（TrueHD或DTS Master音频）。此外，现在它可以同时并行多个设备的音频输出与新的离散数字多音频（DDMA）功能。应该是相似的或稍低于HD 7670M的功耗。其结果是，是最适合于13英寸的笔记本电脑或更大8750M。

Radeon HD 8700M Series

Radeon HD 8790M 384 @ 0.85 GHz128 Bit @ 4500 MHz
Radeon HD 8770M 384 @ 0.78 GHz128 Bit @ 4500 MHz
Radeon HD 8550G + HD 8750M Dual Graphics 640 @ 0.72 GHz128 Bit @ 1800 MHz
Radeon HD 8750M 384 @ 0.62 - 0.78 GHz128 Bit @ 2000 - 4000 MHz
Radeon HD 8730M 384 @ 0.65 GHz128 Bit @ 2000 MHz
CodenameMars Pro
ArchitectureGCN
Pipelines384 - unified
Core Speed620 - 775 (Boost) MHz
Memory Speed2000 - 4000 MHz
Memory Bus Width128 Bit
Memory TypeGDDR5, DDR3
Max. Amount of Memory2048 MB
Shared Memoryno
APIDirectX 11.1, Shader 5.0
Transistor Count900 Million
technology28 nm
Notebook Sizemedium sized
Date of Announcement16.11.2012

Benchmarks

Performance Rating - 3DMark 11 + Fire Strike + Time Spy
0.6 pt (2%)
AMD Radeon HD 8180
0.06605 -89%
...
AMD Radeon R7 M460
0.536 -8%
Intel UHD Graphics 24EUs (Alder Lake-N)
0.539 -7%
AMD Radeon R7 M440
0.546 -6%
Intel UHD Graphics Xe 16EUs (Tiger Lake-H)
0.548 -6%
AMD Radeon R7 M340
0.551 -5%
AMD Radeon HD 8690M
0.551 -5%
Intel UHD Graphics 630
0.552 -5%
NVIDIA GeForce GT 640M
0.558 -4%
AMD Radeon R7 M270
0.573 -1%
AMD Radeon HD 8750M
0.581
AMD Radeon R5 (Bristol Ridge)
0.585 1%
Intel UHD Graphics G7 (Lakefield GT2 64 EU)
0.59 2%
AMD Radeon HD 8550G + HD 8750M Dual Graphics
0.594 2%
AMD Radeon 520
0.601 3%
AMD Radeon R7 M265
0.609 5%
NVIDIA Quadro K1100M
0.611 5%
Intel Iris Pro Graphics 5200
0.629 8%
NVIDIA GeForce 830M
0.632 9%
AMD Radeon R7 M260X
0.636 9%
...
NVIDIA GeForce RTX 4090 Laptop GPU
21.1 3532%
max:
NVIDIA GeForce RTX 4090
33.3 5631%
0%
100%
3DMark - 3DMark Cloud Gate Score
min: 5433     avg: 5910     median: 5610 (6%)     max: 7521 Points
+ 9 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Graphics
min: 7690     avg: 8445     median: 8524.5 (2%)     max: 8882 Points
+ 8 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Score
min: 1090     avg: 1192     median: 1186 (2%)     max: 1281 Points
+ 9 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Graphics
min: 1170     avg: 1278     median: 1276.5 (1%)     max: 1339 Points
+ 8 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Graphics
min: 41642     avg: 55701     median: 54564 (7%)     max: 70678 Points
+ 8 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance Score
min: 1512     avg: 1884     median: 1863.5 (3%)     max: 2515 Points
+ 10 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance GPU
min: 1379     avg: 1749     median: 1698 (1%)     max: 2662 Points
+ 10 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 6250
171.8 -90%
...
NVIDIA GeForce GT 735M
1703 -3%
AMD Radeon R5 (Bristol Ridge)
1708 -2%
NVIDIA GeForce GT 640M
1708 -2%
AMD Radeon R5 (Carrizo)
1711 -2%
NVIDIA GeForce 920M
1711 -2%
AMD FirePro M4100
1728 -1%
AMD Radeon R7 (Kaveri)
1734 -1%
NVIDIA GeForce GT 730M
1741 0%
Intel UHD Graphics 630
1742 0%
AMD Radeon HD 8750M
1749
NVIDIA GeForce 825M
1757 0%
AMD Radeon R5 M335
1784 2%
Intel UHD Graphics G7 (Lakefield GT2 64 EU)
1792 2%
AMD Radeon R7 (Carrizo)
1793 3%
NVIDIA Quadro K2000M
1807 3%
NVIDIA Quadro K1100M
1819 4%
NVIDIA GeForce 920MX
1823 4%
AMD Radeon R5 M255
1831 5%
NVIDIA GeForce GTX 560M
1843 5%
...
AMD Radeon RX 7900M
59943 3327%
max:
NVIDIA GeForce RTX 4090
106023 5962%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
min: 6491     avg: 6902     median: 6840 (2%)     max: 7297 Points
+ 7 benchmarks and specifications   + Show comparison chart
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
min: 5951     avg: 6451     median: 6352 (4%)     max: 7610 Points
+ 7 benchmarks and specifications   - Hide comparison chart
ATI Radeon HD 3200
62 -99%
...
NVIDIA GeForce 8800M GTX SLI
5995 -7%
AMD Radeon R7 M445
6000 -7%
AMD Radeon R7 M270
6027 -7%
AMD Radeon 610M
6032 -6%
Intel UHD Graphics 630
6111 -5%
ATI Mobility Radeon HD 4870
6139 -5%
Intel HD Graphics 630
6208 -4%
NVIDIA GeForce 9800M GTS SLI
6327 -2%
AMD Radeon HD 7660G + HD 7670M Dual Graphics
6414 -1%
AMD Radeon HD 8750M
6451
ATI Mobility Radeon HD 3870 X2
6498 1%
NVIDIA GeForce 930M
6557 2%
NVIDIA GeForce GT 640M
6578 2%
NVIDIA Quadro 3000M
6661 3%
NVIDIA GeForce 920MX
6665 3%
NVIDIA GeForce GT 645M
6673 3%
NVIDIA GeForce GTX 460M
6763 5%
AMD Radeon R8 M445DX
6770 5%
NVIDIA GeForce 840M
6846 6%
...
NVIDIA GeForce RTX 4090 Laptop GPU
132443 1953%
max:
AMD Radeon RX 7900 XTX
170928 2550%
0%
100%
3DMark 03 - 3DMark 03 - Standard
min: 18964     avg: 22144     median: 22143.5 (12%)     max: 25323 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DMark 05 - 3DMark 05 - Standard
min: 9722     avg: 13620     median: 13642.5 (15%)     max: 17472 Points
+ 4 benchmarks and specifications   - Hide comparison chart
Intel Graphics Media Accelerator (GMA) 500
133.4 -99%
...
NVIDIA GeForce 8600M GT SLI
12932 -5%
NVIDIA GeForce GT 425M
12975 -5%
NVIDIA Quadro NVS 5100M
13125 -4%
NVIDIA GeForce 9700M GTS
13125 -4%
NVIDIA Quadro FX 880M
13217 -3%
ATI Mobility Radeon HD 5165
13284 -2%
NVIDIA GeForce GT 525M
13307 -2%
NVIDIA GeForce 830M
13441 -1%
NVIDIA GeForce 9800M GS
13587 0%
AMD Radeon HD 8750M
13620
AMD Radeon HD 7670M
13666 0%
NVIDIA GeForce GTS 160M
13775 1%
ATI Mobility Radeon HD 5730
13817 1%
Intel HD Graphics 530
13920 2%
NVIDIA Quadro FX 3600M
13950 2%
NVIDIA GeForce GT 720M
13952 2%
NVIDIA GeForce GT 435M
14036 3%
AMD Radeon HD 6550M
14084 3%
NVIDIA GeForce 8700M GT SLI
14111 4%
...
NVIDIA GeForce RTX 4090 Laptop GPU
61850 354%
max:
NVIDIA GeForce RTX 4080 Super
87172 540%
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
min: 8173     avg: 9095     median: 8901.5 (12%)     max: 10331 Points
+ 8 benchmarks and specifications   + Show comparison chart
Unigine Heaven 3.0 - Unigine Heaven 3.0 DX 11
16.9 fps (6%)
+ 1 benchmarks and specifications   + Show comparison chart
Unigine Heaven 2.1 - Heaven 2.1 high
min: 21.2     avg: 22     median: 22.2 (4%)     max: 22.6 fps
+ 3 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 7310
0.6 -97%
...
NVIDIA GeForce GT 740M
19.4 -12%
AMD Radeon R7 (Bristol Ridge)
19.5 -11%
AMD Radeon R7 M340
19.8 -10%
AMD Radeon 530
19.95 -9%
AMD Radeon R8 M445DX
20.3 -8%
AMD Radeon HD 7520G + HD 7670M Dual Graphics
20.4 -7%
NVIDIA GeForce GT 730M
20.93 -5%
AMD Radeon RX Vega 3
21.2 -4%
AMD Radeon HD 8730M
21.2 -4%
AMD Radeon HD 8750M
22
NVIDIA GeForce 920M
22.1 0%
Intel Iris Xe Graphics G7 96EUs
23.1 5%
NVIDIA GeForce GT 645M
23.35 6%
NVIDIA Quadro K1100M
23.4 6%
NVIDIA GeForce GT 640M
23.87 9%
ATI Mobility Radeon HD 5870
24 9%
NVIDIA Quadro K2000M
24 9%
NVIDIA GeForce GTX 460M
24.01 9%
AMD Radeon RX Vega 8 (Ryzen 2000/3000)
25 14%
...
NVIDIA Quadro RTX 5000 (Laptop)
532 2318%
0%
100%
SPECviewperf 11
specvp11 snx-01 +
SPECviewperf 11 - specvp11 snx-01
6.4 fps (4%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 tcvis-02 +
SPECviewperf 11 - specvp11 tcvis-02
2.9 fps (2%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 sw-02 +
SPECviewperf 11 - specvp11 sw-02
11.9 fps (9%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 proe-05 +
SPECviewperf 11 - specvp11 proe-05
3 fps (4%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 maya-03 +
SPECviewperf 11 - specvp11 maya-03
6.3 fps (5%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 lightwave-01 +
SPECviewperf 11 - specvp11 lightwave-01
13.2 fps (14%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 ensight-04 +
SPECviewperf 11 - specvp11 ensight-04
12.2 fps (6%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 catia-03 +
SPECviewperf 11 - specvp11 catia-03
5.5 fps (3%)
+ 1 benchmarks and specifications   + Show comparison chart
SPECviewperf 12
specvp12 sw-03 +
SPECviewperf 12 - specvp12 sw-03
26.4 fps (7%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 snx-02 +
SPECviewperf 12 - specvp12 snx-02
4.9 fps (1%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 showcase-01 +
SPECviewperf 12 - specvp12 showcase-01
6.3 fps (1%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 maya-04 +
SPECviewperf 12 - specvp12 maya-04
5.6 fps (2%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 creo-01 +
SPECviewperf 12 - specvp12 creo-01
13.2 fps (5%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 catia-04 +
SPECviewperf 12 - specvp12 catia-04
16.3 fps (3%)
+ 1 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Gaming graphics
min: 6.6     avg: 6.7     median: 6.7 (85%)     max: 6.8 Points
+ 2 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Graphics
min: 6.6     avg: 6.7     median: 6.7 (85%)     max: 6.8 Points
+ 2 benchmarks and specifications   + Show comparison chart
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
min: 4687     avg: 6449     median: 6519 (5%)     max: 8055 points
+ 8 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 29.12     avg: 34.9     median: 34.8 (12%)     max: 39.75 fps
+ 10 benchmarks and specifications   + Show comparison chart
Cinebench R15
Cinebench R15 OpenGL 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL 64 Bit
min: 30.88     avg: 38.7     median: 40.2 (2%)     max: 43.4 fps
+ 4 benchmarks and specifications   + Show comparison chart
Cinebench R15 OpenGL Ref. Match 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
98 % (98%)
+ 4 benchmarks and specifications   + Show comparison chart
LuxMark v2.0 64Bit - LuxMark v2.0 Room GPU
min: 221     avg: 224.5     median: 224.5 (1%)     max: 228 Samples/s
+ 2 benchmarks and specifications   + Show comparison chart
LuxMark v2.0 64Bit - LuxMark v2.0 Sala GPU
min: 367     avg: 372.5     median: 372.5 (1%)     max: 378 Samples/s
+ 2 benchmarks and specifications   + Show comparison chart
ComputeMark v2.1 - ComputeMark v2.1 Result
min: 1214     avg: 1218     median: 1217.5 (1%)     max: 1221 points
+ 2 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Thief

Thief

2014
low 1024x768
21  fps    + Compare
med. 1366x768
14.8  fps    + Compare
high 1366x768
11.1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
X-Plane 10.25

X-Plane 10.25

2013
low 1024x768
59.8 63.5 ~ 62 fps    + Compare
med. 1366x768
30.4 33.3 ~ 32 fps    + Compare
high 1366x768
13.1 14 ~ 14 fps    + Compare
ultra 1920x1080
11.7  fps    + Compare
» With all tested laptops playable in detail settings low.
Need for Speed: Rivals

Need for Speed: Rivals

2013
low 1024x768
30  fps    + Compare
med. 1366x768
28.8  fps    + Compare
high 1366x768
23.7  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Call of Duty: Ghosts

Call of Duty: Ghosts

2013
low 1024x768
35.3  fps    + Compare
med. 1366x768
32.7  fps    + Compare
high 1366x768
14.3  fps    + Compare
» With all tested laptops playable in detail settings low.
Battlefield 4

Battlefield 4

2013
low 1024x768
48.7 49.6 ~ 49 fps    + Compare
med. 1366x768
33 37.9 ~ 35 fps    + Compare
high 1366x768
22.4 28 ~ 25 fps    + Compare
ultra 1920x1080
8.1  fps    + Compare
» With all tested laptops playable in detail settings low.
Batman: Arkham Origins

Batman: Arkham Origins

2013
low 1024x768
70  fps    + Compare
med. 1366x768
43  fps    + Compare
high 1366x768
27  fps    + Compare
» With all tested laptops playable in detail settings med..
F1 2013

F1 2013

2013
low 1024x768
80 92 ~ 86 fps    + Compare
med. 1366x768
54 66 ~ 60 fps    + Compare
high 1366x768
37 60 ~ 49 fps    + Compare
ultra 1920x1080
23 29 ~ 26 fps    + Compare
» With all tested laptops playable in detail settings high.
Fifa 14

Fifa 14

2013
low 1024x768
229.4 253.6 316.3 ~ 266 fps    + Compare
med. 1366x768
146.5 147.9 182.7 ~ 159 fps    + Compare
high 1366x768
122.5 142.3 157.9 ~ 141 fps    + Compare
ultra 1920x1080
78.3 97.5 99.2 ~ 92 fps    + Compare
» With all tested laptops playable in detail settings ultra.
Total War: Rome II

Total War: Rome II

2013
low 1024x768
41 62.3 66.9 ~ 57 fps    + Compare
med. 1366x768
32 50 54.8 ~ 46 fps    + Compare
high 1366x768
23 40.4 ~ 32 fps    + Compare
ultra 1920x1080
7 7.9 ~ 7 fps    + Compare
» With most tested laptops playable in detail settings med..
Saints Row IV

Saints Row IV

2013
low 1280x720
36.8  fps    + Compare
med. 1366x768
29.1  fps    + Compare
high 1366x768
18.6  fps    + Compare
ultra 1920x1080
12.5  fps    + Compare
» With all tested laptops playable in detail settings low.
The Bureau: XCOM Declassified

The Bureau: XCOM Declassified

2013
low 1024x768
49.9  fps    + Compare
med. 1366x768
33.1  fps    + Compare
high 1366x768
22.4  fps    + Compare
ultra 1920x1080
12.5  fps    + Compare
» With all tested laptops playable in detail settings low.
Splinter Cell: Blacklist

Splinter Cell: Blacklist

2013
low 1024x768
49.9  fps    + Compare
med. 1366x768
21.5  fps    + Compare
» With all tested laptops playable in detail settings low.
Dota 2

Dota 2

2013
low 1024x768
71.8 96.4 99.3 ~ 89 fps    + Compare
med. 1366x768
52.7 53.9 70.3 ~ 59 fps    + Compare
ultra 1920x1080
29.5 30.7 34.8 ~ 32 fps    + Compare
» With all tested laptops playable in detail settings med..
Company of Heroes 2

Company of Heroes 2

2013
low 1024x768
28 30 ~ 29 fps    + Compare
med. 1366x768
22.1 24 ~ 23 fps    + Compare
high 1366x768
12 13.9 ~ 13 fps    + Compare
ultra 1920x1080
2.1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
GRID 2

GRID 2

2013
low 1024x768
74 86.8 ~ 80 fps    + Compare
med. 1366x768
52.5 57.4 ~ 55 fps    + Compare
high 1366x768
41.6 50.7 ~ 46 fps    + Compare
ultra 1920x1080
15.5  fps    + Compare
» With all tested laptops playable in detail settings high.
Metro: Last Light

Metro: Last Light

2013
low 1024x768
17 36 41 ~ 31 fps    + Compare
med. 1366x768
12 27.8 28.7 ~ 23 fps    + Compare
high 1366x768
7 16 16.3 ~ 13 fps    + Compare
ultra 1920x1080
7.9  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
BioShock Infinite

BioShock Infinite

2013
low 1280x720
59.7 59.8 ~ 60 fps    + Compare
med. 1366x768
34.8 36.8 ~ 36 fps    + Compare
high 1366x768
30.6 31 ~ 31 fps    + Compare
ultra 1920x1080
10.6 11.2 ~ 11 fps    + Compare
» With most tested laptops playable in detail settings med..
StarCraft II: Heart of the Swarm

StarCraft II: Heart of the Swarm

2013
low 1024x768
181.2 187.2 ~ 184 fps    + Compare
med. 1366x768
71.7 79.1 ~ 75 fps    + Compare
high 1366x768
42.8 44 ~ 43 fps    + Compare
ultra 1920x1080
15.3  fps    + Compare
» With all tested laptops playable in detail settings high.
SimCity

SimCity

2013
low 1024x768
42.5 66 ~ 54 fps    + Compare
med. 1366x768
26 26.8 ~ 26 fps    + Compare
high 1366x768
19 20.1 ~ 20 fps    + Compare
ultra 1920x1080
10.8  fps    + Compare
» With all tested laptops playable in detail settings low.
Tomb Raider

Tomb Raider

2013
low 1024x768
71.2 92.6 94 104.4 ~ 91 fps    + Compare
med. 1366x768
38.7 45.5 45.9 49.4 ~ 45 fps    + Compare
high 1366x768
25.3 30.8 30.8 33.6 ~ 30 fps    + Compare
ultra 1920x1080
11.8 15.3 ~ 14 fps    + Compare
» With all tested laptops playable in detail settings med..
Crysis 3

Crysis 3

2013
low 1024x768
32.5 36 ~ 34 fps    + Compare
med. 1366x768
20.8 22 ~ 21 fps    + Compare
high 1366x768
14 14.5 ~ 14 fps    + Compare
ultra 1920x1080
5.8  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Dead Space 3

Dead Space 3

2013
low 1024x768
119.8 138 ~ 129 fps    + Compare
med. 1366x768
54 54.9 ~ 54 fps    + Compare
high 1366x768
42 42.8 ~ 42 fps    + Compare
ultra 1920x1080
25.5  fps    + Compare
» With all tested laptops playable in detail settings high.
Far Cry 3

Far Cry 3

2012
low 1024x768
57  fps    + Compare
med. 1366x768
40  fps    + Compare
high 1366x768
18.5  fps    + Compare
ultra 1920x1080
6  fps    + Compare
» With all tested laptops playable in detail settings med..
Assassin´s Creed III

Assassin´s Creed III

2012
med. 1366x768
20.9  fps    + Compare
high 1366x768
19.4  fps    + Compare
ultra 1920x1080
7.3  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Hitman: Absolution

Hitman: Absolution

2012
low 1024x768
22.7  fps    + Compare
med. 1366x768
20.1  fps    + Compare
high 1366x768
15.7  fps    + Compare
ultra 1920x1080
6  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Call of Duty: Black Ops 2

Call of Duty: Black Ops 2

2012
low 1024x768
74.6  fps    + Compare
med. 1366x768
54.3  fps    + Compare
high 1366x768
26  fps    + Compare
ultra 1920x1080
18.3  fps    + Compare
» With all tested laptops playable in detail settings med..
Need for Speed: Most Wanted

Need for Speed: Most Wanted

2012
low 1024x768
45  fps    + Compare
med. 1366x768
36.6  fps    + Compare
high 1366x768
22.5  fps    + Compare
ultra 1920x1080
14.3  fps    + Compare
» With all tested laptops playable in detail settings med..
Medal of Honor: Warfighter

Medal of Honor: Warfighter

2012
low 1024x768
54.7  fps    + Compare
med. 1366x768
33.8  fps    + Compare
high 1366x768
25.6  fps    + Compare
ultra 1920x1080
9.7  fps    + Compare
» With all tested laptops playable in detail settings low.
Dishonored

Dishonored

2012
low 1024x768
71.7  fps    + Compare
med. 1366x768
56.4  fps    + Compare
high 1366x768
49.3  fps    + Compare
ultra 1920x1080
27.8  fps    + Compare
» With all tested laptops playable in detail settings high.
Fifa 13

Fifa 13

2012
low 1024x768
258.6  fps    + Compare
med. 1366x768
141 174.5 ~ 158 fps    + Compare
high 1366x768
128 143.2 ~ 136 fps    + Compare
ultra 1920x1080
84.5  fps    + Compare
» With all tested laptops playable in detail settings ultra.
F1 2012

F1 2012

2012
low 1024x768
73  fps    + Compare
med. 1366x768
57  fps    + Compare
high 1366x768
39  fps    + Compare
ultra 1920x1080
30  fps    + Compare
» With all tested laptops playable in detail settings high.
Borderlands 2

Borderlands 2

2012
low 1024x768
53  fps    + Compare
med. 1366x768
41  fps    + Compare
high 1366x768
31.3  fps    + Compare
ultra 1920x1080
18.1  fps    + Compare
» With all tested laptops playable in detail settings med..
Guild Wars 2

Guild Wars 2

2012
low 1024x768
59.7  fps    + Compare
high 1366x768
26.4  fps    + Compare
ultra 1920x1080
10.4  fps    + Compare
» With all tested laptops playable in detail settings low.
Counter-Strike: GO

Counter-Strike: GO

2012
low 1024x768
135  fps    + Compare
med. 1366x768
100.6  fps    + Compare
high 1366x768
82.3  fps    + Compare
ultra 1920x1080
53.5  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Darksiders II

Darksiders II

2012
med. 1366x768
51.2  fps    + Compare
ultra 1920x1080
29.5  fps    + Compare
» With all tested laptops playable in detail settings med..
Sleeping Dogs

Sleeping Dogs

2012
low 1024x768
31.3  fps    + Compare
med. 1366x768
30.2  fps    + Compare
high 1366x768
23.6  fps    + Compare
ultra 1920x1080
7  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Ghost Recon: Future Soldier

Ghost Recon: Future Soldier

2012
low 1024x768
33.4  fps    + Compare
med. 1366x768
17.5  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Max Payne 3

Max Payne 3

2012
low 1024x768
42.7  fps    + Compare
med. 1366x768
26.8  fps    + Compare
high 1366x768
25.6  fps    + Compare
ultra 1920x1080
16.5  fps    + Compare
» With all tested laptops playable in detail settings low.
Dirt Showdown

Dirt Showdown

2012
low 1024x768
71.3  fps    + Compare
med. 1366x768
44.3  fps    + Compare
high 1366x768
35.1  fps    + Compare
ultra 1920x1080
15.9  fps    + Compare
» With all tested laptops playable in detail settings high.
Diablo III

Diablo III

2012
low 1024x768
80.5 81.2 85.2 93 ~ 85 fps    + Compare
med. 1366x768
57.4 57.7 57.7 68 ~ 60 fps    + Compare
high 1366x768
49.2 49.3 49.5 56 ~ 51 fps    + Compare
ultra 1920x1080
30.3 30.8 31.7 ~ 31 fps    + Compare
» With all tested laptops playable in detail settings high.
Risen 2: Dark Waters

Risen 2: Dark Waters

2012
low 1024x768
44.8  fps    + Compare
med. 1366x768
30.3  fps    + Compare
high 1366x768
23  fps    + Compare
ultra 1920x1080
11.2  fps    + Compare
» With all tested laptops playable in detail settings low.
Mass Effect 3

Mass Effect 3

2012
low 1280x720
57 57.6 ~ 57 fps    + Compare
high 1366x768
44.3 45 ~ 45 fps    + Compare
ultra 1920x1080
26.3  fps    + Compare
» With all tested laptops playable in detail settings high.
Alan Wake

Alan Wake

2012
low 1024x768
43.7  fps    + Compare
med. 1366x768
26  fps    + Compare
ultra 1920x1080
12.2  fps    + Compare
» With all tested laptops playable in detail settings low.
Anno 2070

Anno 2070

2011
low 1024x768
97 103.6 109.8 126.5 129.5 ~ 113 fps    + Compare
med. 1366x768
48.1 50.4 52.5 54.1 58.5 ~ 53 fps    + Compare
high 1366x768
29.4 29.7 31.4 32.1 34.6 ~ 31 fps    + Compare
ultra 1920x1080
14.1 14.4 15 15 ~ 15 fps    + Compare
» With all tested laptops playable in detail settings med..
The Elder Scrolls V: Skyrim

The Elder Scrolls V: Skyrim

2011
low 1280x720
55 70.7 ~ 63 fps    + Compare
med. 1366x768
38.8 46.5 ~ 43 fps    + Compare
high 1366x768
28.4 32.4 ~ 30 fps    + Compare
ultra 1920x1080
18.1  fps    + Compare
» With all tested laptops playable in detail settings med..
CoD: Modern Warfare 3

CoD: Modern Warfare 3

2011
low 1024x768
130.3  fps    + Compare
med. 1366x768
79.8  fps    + Compare
high 1366x768
46.6  fps    + Compare
ultra 1920x1080
27.4  fps    + Compare
» With all tested laptops playable in detail settings high.
Battlefield 3

Battlefield 3

2011
low 1024x768
43.4  fps    + Compare
med. 1366x768
32.2  fps    + Compare
high 1366x768
25.5  fps    + Compare
ultra 1920x1080
10.3  fps    + Compare
» With all tested laptops playable in detail settings low.
Batman: Arkham City

Batman: Arkham City

2011
low 1024x768
86  fps    + Compare
med. 1366x768
69  fps    + Compare
high 1366x768
30  fps    + Compare
» With all tested laptops playable in detail settings med..
Deus Ex Human Revolution

Deus Ex Human Revolution

2011
low 1024x768
99.7  fps    + Compare
high 1366x768
52.4  fps    + Compare
ultra 1920x1080
22.9  fps    + Compare
» With all tested laptops playable in detail settings high.
Total War: Shogun 2

Total War: Shogun 2

2011
low 1024x768
125.3  fps    + Compare
med. 1280x720
31.6  fps    + Compare
ultra 1920x1080
23.5  fps    + Compare
» With all tested laptops playable in detail settings low.
Additional Benchmarks
CPU 1280x1024
15.3
Civilization 5

Civilization 5

2010
low 1024x768
45.7  fps    + Compare
ultra 1920x1080
15.1  fps    + Compare
» With all tested laptops playable in detail settings low.
Mafia 2

Mafia 2

2010
low 800x600
57.1  fps    + Compare
med. 1024x768
53.6  fps    + Compare
high 1360x768
48.2  fps    + Compare
» With all tested laptops playable in detail settings high.
StarCraft 2

StarCraft 2

2010
low 1024x768
126  fps    + Compare
med. 1360x768
47  fps    + Compare
high 1360x768
35  fps    + Compare
» With all tested laptops playable in detail settings med..
Just Cause 2

Just Cause 2

2010
ultra 1920x1080
24.9  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Metro 2033

Metro 2033

2010
low 800x600
72  fps    + Compare
med. 1360x768
40  fps    + Compare
high 1600x900
23  fps    + Compare
» With all tested laptops playable in detail settings med..
Battlefield: Bad Company 2

Battlefield: Bad Company 2

2010
low 1024x768
78.6  fps    + Compare
med. 1366x768
60.2  fps    + Compare
high 1366x768
44.1  fps    + Compare
» With all tested laptops playable in detail settings high.
Resident Evil 5

Resident Evil 5

2009
low 800x600
96  fps    + Compare
high 1360x768
55.1  fps    + Compare
ultra 1920x1080
33.5  fps    + Compare
» With all tested laptops playable in detail settings high.
Need for Speed Shift

Need for Speed Shift

2009
low 800x600
84.8  fps    + Compare
med. 1024x768
64  fps    + Compare
high 1366x768
37.1  fps    + Compare
» With all tested laptops playable in detail settings high.
Trackmania Nations Forever

Trackmania Nations Forever

2008
low 640x480
154  fps    + Compare
high 1024x768
48.4  fps    + Compare
ultra 1920x1080
25.1  fps    + Compare
» With all tested laptops playable in detail settings high.
Crysis - GPU Benchmark

Crysis - GPU Benchmark

2007
low 1024x768
108.9  fps    + Compare
high 1024x768
40.4  fps    + Compare
» With all tested laptops playable in detail settings high.
Crysis - CPU Benchmark

Crysis - CPU Benchmark

2007
low 1024x768
106.2  fps    + Compare
high 1024x768
33.7  fps    + Compare
» With all tested laptops playable in detail settings low.
World of Warcraft

World of Warcraft

2005
low 800x600
64  fps    + Compare
med. 1024x768
64  fps    + Compare
high 1280x1024
31  fps    + Compare
ultra 1920x1080
18.7  fps    + Compare
» With all tested laptops playable in detail settings med..
lowmed.highultraQHD4K
Thief2114.811.1
X-Plane 10.2562321411.7
Need for Speed: Rivals3028.823.7
Call of Duty: Ghosts35.332.714.3
Battlefield 44935258.1
Batman: Arkham Origins704327
F1 201386604926
Fifa 1426615914192
Total War: Rome II5746327
Saints Row IV36.829.118.612.5
The Bureau: XCOM Declassified49.933.122.412.5
Splinter Cell: Blacklist49.921.5
Dota 2895932
Company of Heroes 22923132.1
GRID 280554615.5
Metro: Last Light3123137.9
BioShock Infinite60363111
StarCraft II: Heart of the Swarm184754315.3
SimCity54262010.8
Tomb Raider91453014
Crysis 33421145.8
Dead Space 3129544225.5
Far Cry 3574018.56
Assassin´s Creed III20.919.47.3
Hitman: Absolution22.720.115.76
Call of Duty: Black Ops 274.654.32618.3
Need for Speed: Most Wanted4536.622.514.3
Medal of Honor: Warfighter54.733.825.69.7
Dishonored71.756.449.327.8
Fifa 13258.615813684.5
F1 201273573930
Borderlands 2534131.318.1
Guild Wars 259.726.410.4
Counter-Strike: GO135100.682.353.5
Darksiders II51.229.5
Sleeping Dogs31.330.223.67
Ghost Recon: Future Soldier33.417.5
Max Payne 342.726.825.616.5
Dirt Showdown71.344.335.115.9
Diablo III85605131
Risen 2: Dark Waters44.830.32311.2
Mass Effect 3574526.3
Alan Wake43.72612.2
Anno 2070113533115
The Elder Scrolls V: Skyrim63433018.1
CoD: Modern Warfare 3130.379.846.627.4
Battlefield 343.432.225.510.3
Batman: Arkham City866930
Deus Ex Human Revolution99.752.422.9
Total War: Shogun 2125.331.623.5
Civilization 545.715.1
Mafia 257.153.648.2
StarCraft 21264735
Just Cause 224.9
Metro 2033724023
Battlefield: Bad Company 278.660.244.1
Resident Evil 59655.133.5
Need for Speed Shift84.86437.1
Trackmania Nations Forever15448.425.1
Crysis - GPU Benchmark108.940.4
Crysis - CPU Benchmark106.233.7
World of Warcraft64643118.7
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps		3
24
23
9		13
29
9
2		24
27
1
2		41
5
2






For more games that might be playable and a list of all games and graphics cards visit our Gaming List

v1.26
log 24. 13:26:49

#0 no ids found in url (should be separated by "_") +0s ... 0s

#1 not redirecting to Ajax server +0s ... 0s

#2 did not recreate cache, as it is less than 5 days old! Created at Mon, 22 Apr 2024 05:40:21 +0200 +0.001s ... 0.001s

#3 no comparison url found in template nbc.compare_page_1 needed +0.066s ... 0.067s

#4 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.067s

#5 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.067s

#6 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.068s

#7 composed specs +0s ... 0.068s

#8 did output specs +0s ... 0.068s

#9 start showIntegratedCPUs +0s ... 0.068s

#10 getting avg benchmarks for device 3727 +0.028s ... 0.096s

#11 got single benchmarks 3727 +0.043s ... 0.139s

#12 got avg benchmarks for devices +0s ... 0.139s

#13 min, max, avg, median took s +0.675s ... 0.814s

#14 before gaming benchmark output +0s ... 0.814s

#15 Got 315 rows for game benchmarks. +0.035s ... 0.849s

#16 composed SQL query for gamebenchmarks +0s ... 0.849s

#17 got data and put it in $dataArray +0.045s ... 0.894s

#18 benchmarks composed for output. +1.859s ... 2.754s

#19 no comparison url found in template nbc.compare_page_1 needed +0.005s ... 2.759s

#20 return log +0s ... 2.759s

Please share our article, every link counts!

» Comparison of GPUs
Detailed list of all laptop GPUs sorted by class and performance.

» Benchmark List
Sort and restrict laptop GPUs based on performance in synthetic benchmarks.

» Notebook Gaming List
Playable games for each graphics card and their average FPS results.

Class 1

NVIDIA GeForce RTX 4090 Laptop GPU
NVIDIA RTX 5000 Ada Generation Laptop GPU
Radeon RX 7900M
NVIDIA GeForce RTX 4080 Laptop GPU
NVIDIA RTX 4000 Ada Generation Laptop GPU
NVIDIA RTX 3500 Ada Generation Laptop GPU
GeForce RTX 3080 Ti Laptop GPU
NVIDIA GeForce RTX 4070 Laptop GPU
NVIDIA RTX 3000 Ada Generation Laptop GPU
RTX A5500 Laptop GPU
GeForce RTX 3080 Laptop GPU
Radeon RX 6850M XT
GeForce RTX 3070 Ti Laptop GPU
RTX A4500 Laptop GPU
RTX A5000 Laptop GPU
NVIDIA GeForce RTX 4060 Laptop GPU
NVIDIA RTX 2000 Ada Generation Laptop GPU
Quadro RTX 6000 (Laptop)
Radeon RX 6800M
GeForce RTX 2080 Super Mobile
GeForce RTX 3070 Laptop GPU
RTX A4000 Laptop GPU *

Class 2

Radeon RX 6800S
Radeon RX 7600M XT *
Radeon RX 7700S *
M3 Max 40-Core GPU *
M2 Max 38-Core GPU *
GeForce RTX 2080 Mobile
Radeon RX 6700M
M3 Max 30-Core GPU *
Quadro RTX 5000 (Laptop)
Radeon RX 7600M *
M2 Max 30-Core GPU *
GeForce RTX 3060 Laptop GPU
M1 Max 32-Core GPU *
Radeon RX 7600S
GeForce RTX 2070 Super Mobile
GeForce RTX 2080 Super Max-Q
RTX A3000 Laptop GPU
M1 Max 24-Core GPU *
A770M *
Radeon RX 6650M XT *
M3 Pro 18-Core GPU *
M2 Pro 19-Core GPU *
Radeon RX 6650M
Radeon RX 6600M
Radeon RX 6700S
GeForce RTX 2070 Mobile
Quadro RTX 5000 Max-Q
GeForce RTX 2080 Max-Q
Radeon RX 5700M *
GeForce GTX 1080 Mobile
Quadro RTX 4000 (Laptop)
M3 Pro 14-Core GPU *
M2 Pro 16-Core GPU *
M1 Pro 16-Core GPU *
Radeon PRO W6600M *
GeForce RTX 2070 Super Max-Q
Quadro RTX 4000 Max-Q *
M1 Pro 14-Core GPU *
GeForce RTX 2070 Max-Q *
Radeon RX 6600S *
Quadro P5200
Quadro RTX 3000 (Laptop) *
GeForce RTX 2060 Mobile
Quadro RTX 3000 Max-Q *
GeForce GTX 1080 Max-Q
GeForce GTX 1070 Mobile
GeForce RTX 2060 Max-Q *
Quadro P4200
NVIDIA GeForce RTX 4050 Laptop GPU
Nvidia RTX 1000 Ada Generation Laptop GPU
RTX A2000 Laptop GPU
A730M *
Radeon Pro 5600M *
Radeon RX 5600M
Quadro P5000
GeForce GTX 1660 Ti Mobile
GeForce RTX 3050 Ti Laptop GPU
GeForce RTX 3050 6GB Laptop GPU
A570M *
RTX A1000 Laptop GPU
GeForce GTX 1070 Max-Q
A550M *
Quadro P5000 Max-Q *
GeForce RTX 3050 4GB Laptop GPU
Nvidia RTX 500 Ada Generation Laptop GPU
A530M *
GeForce GTX 1660 Ti Max-Q
RTX A500 Laptop GPU
Radeon RX 6550M *
Radeon RX 6500M
Radeon RX 6550S *
GeForce GTX 980 (Laptop)
Quadro M5500
Quadro P4000
Quadro T2000 (Laptop) *
GeForce GTX 1060 Mobile
GeForce GTX 1650 Ti Mobile
A370M *
Radeon RX 5500M
Radeon Pro 5500M *
Quadro P4000 Max-Q
Quadro P3200
Radeon RX 580X (Laptop) *
Radeon RX 580 (Laptop)
Radeon RX 6450M *
GeForce RTX 2050 Mobile
GeForce MX570 *
Radeon RX 6300M *
GeForce GTX 1650 Mobile
Radeon Pro 5300M
Radeon RX 5300M
Quadro P3000
GeForce GTX 1060 Max-Q
Quadro P3000 Max-Q *
GeForce GTX 1650 Ti Max-Q *
Quadro T2000 Max-Q *
Radeon Pro WX 7100 *
Radeon RX 570X (Laptop) *
Radeon RX 570 (Laptop) *
Radeon RX 470 (Laptop) *
GeForce GTX 1650 Max-Q *
T1200 Laptop GPU *
Quadro T1000 (Laptop) *
Quadro T1000 Max-Q *
A310 *
Arc 8-Cores *
A350M *
Arc 7-Cores *
T600 Laptop GPU *
T550 Laptop GPU *

Class 3

GeForce GTX 980M
Vega M GH
Quadro M5000M
Radeon Pro Vega 20
Radeon 780M *
GeForce MX550
GeForce GTX 1050 Ti Mobile
Radeon 680M
Quadro P2000
Quadro P2000 Max-Q
Quadro M4000M
GeForce GTX 970M
T500 Laptop GPU *
GeForce MX450 *
Radeon R9 M395X
GeForce GTX 1050 Ti Max-Q *
Radeon Pro Vega 16
Vega M GL / 870
WX Vega M GL
Radeon R9 M485X
Quadro M3000M
GeForce GTX 1050 Mobile
FirePro W7170M
Radeon R9 M395
GeForce GTX 1050 Max-Q *
Radeon 760M *
Radeon Radeon Steam Deck 8CU
Radeon 660M
Radeon Pro WX 4150 *
GeForce GTX 965M
Radeon RX 560X (Laptop)
Radeon RX 560 (Laptop)
Quadro M2200
Radeon RX 460 (Laptop)
Quadro P1000
Radeon R9 M390
Xe MAX
Radeon Pro 560X
Radeon Pro 560
Radeon Pro 460
Radeon Pro WX 4130 *
Iris Xe G7 96EUs
GeForce MX350
GeForce GTX 960M
Quadro M1200
Quadro P620 *
Radeon RX 550X (Laptop)
Radeon RX 550 (Laptop)
Radeon RX 640
Radeon Pro WX 3200 *
Radeon Pro 555X
Radeon Pro 555
Radeon Pro 455
Quadro P600
GeForce MX250
GeForce MX330
GeForce MX150
Iris Xe G7 80EUs
Graphics 4-Core *
Quadro M2000M
Radeon RX 540X *
Radeon Pro WX 2100 *
Radeon RX 540 *
Radeon Pro WX 3100 *
GeForce GTX 950M
Radeon Pro 450
Radeon 630
Radeon 540X *
Radeon R9 M470X *
Radeon R9 M385X
Quadro P520
Quadro M1000M
Quadro M620 *
GeForce 945M
Quadro P500 *
UHD Graphics 64EUs
Iris Plus Graphics G7 (Ice Lake 64 EU) *
Vega 10 *
Iris Pro Graphics P580
Iris Pro Graphics 580
Radeon R9 M470 *
FirePro W5170M *
Radeon R9 M370X
Vega 9
FirePro W5130M
UHD Graphics Xe G4 48EUs *
UHD Graphics 32EUs
UHD Graphics Xe 32EUs (Tiger Lake-H) *
UHD Graphics 750
Radeon 740M *
GeForce MX230
Vega 8 *
Vega 7
Radeon R7 M465
Iris Pro Graphics 6200
GeForce MX130
GeForce 940MX
Quadro M520
Vega 8
GeForce 940M
Iris Plus Graphics G4 (Ice Lake 48 EU)
GeForce 930MX
Quadro M600M
FirePro W4190M
Radeon R9 M375
Iris Plus Graphics 655
Radeon R7 M445
Quadro M500M
Iris Plus Graphics 650
GeForce 930M
Iris Graphics 550
Radeon 530
Radeon 625
Vega 6 *
Iris Plus Graphics 645
GeForce MX110 *
Iris Plus Graphics 640
GeForce 920MX
Iris Graphics 540
UHD Graphics 24EUs (Alder Lake-N) *
Radeon HD 8750M
Radeon R7 (Bristol Ridge) *
Radeon R7 M460 *
Radeon R7 M360
GeForce 920M
Radeon R8 M445DX
Radeon 620
Radeon R7 M440
Radeon R7 M340
Radeon 520
Radeon 610
Radeon Graphics (Ryzen 7000)
Radeon 610M *
Vega 6 *
Vega 5 *
UHD Graphics G1 (Ice Lake 32 EU)
UHD Graphics Xe 16EUs (Tiger Lake-H) *
UHD Graphics G7 (Lakefield GT2 64 EU)
HD Graphics 530
Radeon R5 (Bristol Ridge)
UHD Graphics 620
HD Graphics 620
Adreno 690 *
Adreno 685 *
Adreno 680 *
Radeon R5 M330
Radeon R5 M430
Vega 3 *
GeForce 910M
HD Graphics 520
Iris Graphics 6100
UHD Graphics G4 (Lakefield GT1 48 EU) *

Class 4

UHD Graphics 730
Radeon R5 M320 *
Radeon R5 M315 *
Radeon R5 M420 *
Vega 2 *
Radeon R5 (Stoney Ridge)
HD Graphics 6000
UHD Graphics (Jasper Lake 32 EU) *
UHD Graphics 617
UHD Graphics 615
UHD Graphics (Jasper Lake 24 EU) *
HD Graphics 615
HD Graphics 515
UHD Graphics 610
HD Graphics 610
HD Graphics 510
UHD Graphics (Jasper Lake 16 EU)
UHD Graphics 605
HD Graphics 505
HD Graphics 5300
Radeon R4 (Stoney Ridge)
Radeon R5 (Beema/Carrizo-L)
Radeon R4 (Beema)
Radeon R3 (Mullins/Beema)
Radeon R2 (Stoney Ridge)
HD Graphics (Broadwell)
UHD Graphics 600
HD Graphics 500
HD Graphics 405 (Braswell)
HD Graphics (Braswell)
HD Graphics 400 (Braswell)

Class 5

Radeon R2 (Mullins/Beema/Carrizo-L)
Radeon R6 (Mullins)

* Approximate position of the graphics adapter
