NVIDIA GeForce GTX 1070 Mobile

NVIDIA GeForce GTX 1070 Mobile

在2016中旬,Nvidia GeForce GTX 1070是第二快的Pascal基准显卡。它有两个版本,包括1920个着色器的桌面版本(详细信息请参阅这里)以及2048个着色器和更低时钟频率的移动版本。这两款显卡均基于削减后的GP104芯片(如GTX 1080),采用台积电16纳米级FinFET工艺制造。

与GTX1080相比,GTX1070具有更少的CUDA内核(2048与2560),时钟频率稍低(最大的Boost1645和1733)。GTX 1070采用较慢的GDDR5图形内存,而不是新的GDDR5X,但仍是8GB。热设计功耗也降低了,据传比前一代GTX 980M高了10瓦。

对于轻薄型笔记本电脑,Nvidia为轻薄型笔记本电脑提供了一款名为GTX 1070的Max-Q版本,其热设计功耗较低,性能也低。可惜的是,这个变化便随着相同的命名————GTX 1070,很难从表面上看出来它的性能。

它的性能取决于笔记本电脑的散热方式。如果有了一个良好的风扇系统,笔记本电脑的性能将能与桌面级GTX 1070(公版)相当。Nvidia声称合作伙伴解决方案版本的性能可能会降低10%。在我们的各种笔记本电脑的基准测试中,与GTX 1080桌面版本的合作伙伴型号相比,其性能降低了5%到14%,时钟频率稍微更高一些。

平均来说,GTX 1070比旧款移动版GeForce GTX 980快了20%左右,因此也是第二快的移动显卡(非SLI)。因此,WQHD和4K游戏能够在高设置下运行(请参阅下面的游戏基准)。

GP104芯片采用台积电16纳米FinFET工艺制造,提供了一系列新功能。DisplayPort 1.4,HDMI 2.0b,HDR,同时多投影(对称多处理),改进的H.265视频编解码器(用于PlayReady 3.0)只是其中一部分改进。更多相关的详细信息,请参阅详细Pascal架构文章。

根据Nvidia的规定,GTX 1070的功耗是115瓦TGP,因此略高于旧款的GeForce GTX 980M。这导致配备GTX 1070显卡游戏笔记本电脑将会变得非常笨重。后来发布的GTX 1070的Max-Q版本仅使用80-90瓦TGP,因此更适合轻薄型笔记本电脑。

ManufacturerNVIDIA
GeForce GTX 1000 Series
GeForce GTX 1080 Ti 3584 @ 1481 - 1600 MHz352 Bit @ 11000 MHz
GeForce GTX 1080 SLI (Laptop) 5120 @ 1556 - 1733 MHz256 Bit @ 10000 MHz
GeForce GTX 1070 SLI (Desktop) 3840 @ 1506 - 1683 MHz256 Bit @ 8000 MHz
GeForce GTX 1070 SLI (Laptop) 4096 @ 1443 - 1645 MHz256 Bit @ 8000 MHz
GeForce GTX 1080 (Desktop) 2560 @ 1607 - 1733 MHz256 Bit @ 10000 MHz
GeForce GTX 1080 Mobile 2560 @ 1566 - 1733 MHz256 Bit @ 10000 MHz
GeForce GTX 1070 Ti (Desktop) 2432 @ 1607 - 1683 MHz256 Bit @ 8000 MHz
GeForce GTX 1070 (Desktop) 1920 @ 1506 - 1683 MHz256 Bit @ 8000 MHz
GeForce GTX 1080 Max-Q 2560 @ 1101 - 1290 - 1278 - 1468 MHz256 Bit @ 10000 MHz
GeForce GTX 1070 Mobile 2048 @ 1443 - 1645 MHz256 Bit @ 8000 MHz
GeForce GTX 1070 Max-Q 2048 @ 1101 - 1215 - 1265 - 1379 MHz256 Bit @ 8000 MHz
GeForce GTX 1060 (Desktop) 1280 @ 1506 - 1708 MHz192 Bit @ 8000 MHz
GeForce GTX 1060 Mobile 1280 @ 1404 - 1670 MHz192 Bit @ 8000 MHz
GeForce GTX 1060 Max-Q 1280 @ 1063 - 1265 - 1341 - 1480 MHz192 Bit @ 8000 MHz
GeForce GTX 1050 Ti Mobile 768 @ 1493 - 1620 MHz128 Bit @ 7000 MHz
GeForce GTX 1050 Ti (Desktop) 768 @ 1290 - 1392 MHz128 Bit @ 7008 MHz
GeForce GTX 1050 Ti Max-Q 768 @ 1151 – 1290 - 1290 – 1417 MHz128 Bit @ 7000 MHz
GeForce GTX 1050 (Desktop) 640 @ 1354 - 1455 MHz128 Bit @ 7008 MHz
GeForce GTX 1050 Mobile 640 @ 1354 - 1493 MHz128 Bit @ 7000 MHz
GeForce GTX 1050 Max-Q 640 @ 999 - 1189 - 1139 - 1328 MHz128 Bit @ 7000 MHz
GeForce GT 1030 (Desktop) 384 @ 1228 - 1670 MHz64 Bit @ 6000 MHz
CodenameN17E-G2
ArchitecturePascal
Pipelines2048 - unified
Core Speed1443 - 1645 (Boost) MHz
Memory Speed8000 MHz
Memory Bus Width256 Bit
Memory TypeGDDR5
Max. Amount of Memory8192 MB
Shared Memoryno
DirectXDirectX 12_1
Transistor Count7200 Million
technology16 nm
FeaturesMulti-Projection, VR Ready, G-SYNC, Vulkan, Multi Monitor
Notebook Sizelarge
Date of Announcement01.09.2016
Link to Manufacturer PageLink: http://www.nvidia.de/graphics-card...

Benchmarks

Performance Rating - 3DMark 11 + Fire Strike + Time Spy
49.6 pt (51%)
Intel HD Graphics (Bay Trail) -97%
...
NVIDIA GeForce GTX 970 -9%
NVIDIA GeForce GTX 980 (Laptop) -9%
NVIDIA GeForce GTX 1660 (Desktop) -5%
AMD Radeon RX 570 (Desktop) 0%
NVIDIA GeForce GTX 1070 Mobile
AMD Radeon RX 480 (Desktop) 1%
AMD Radeon RX 580 (Desktop) 1%
AMD Radeon R9 Fury 2%
NVIDIA GeForce GTX 1660 Ti (Desktop) 7%
NVIDIA GeForce GTX 1660 Super (Desktop) 9%
...
0%
100%
3DMark - Time Spy Score 2560x1440
min: 4729     avg: 5253     median: 5268 (36%)     max: 5773 Points
3DMark - Time Spy Graphics 2560x1440
min: 5145     avg: 5464     median: 5485 (37%)     max: 5743 Points
3DMark - Ice Storm Unlimited Graphics Score 1280x720 offscreen
min: 246743     avg: 341959     median: 338057 (64%)     max: 410191 Points
3DMark - Ice Storm Extreme Graphics 1920x1080
min: 116033     avg: 222639     median: 231131 (32%)     max: 368933 Points
3DMark - Cloud Gate Standard Score 1280x720
min: 22639     avg: 28539     median: 27920 (42%)     max: 37519 Points
3DMark - Cloud Gate Standard Graphics 1280x720
min: 64973     avg: 99208     median: 101041 (52%)     max: 125922 Points
3DMark - Fire Strike Score 1920x1080
min: 11779     avg: 13906     median: 13797.5 (47%)     max: 15909 Points
3DMark - Fire Strike Graphics 1920x1080
min: 15718     avg: 17228     median: 17236.5 (42%)     max: 19059 Points
3DMark - Ice Storm Standard Graphics 1280x720
min: 117135     avg: 255910     median: 265442 (35%)     max: 424321 Points
3DMark 11 - Performance 1280x720
min: 11913     avg: 16930     median: 16939.5 (44%)     max: 19481 points
3DMark 11 - Performance GPU 1280x720
min: 13760     avg: 22405     median: 22575.5 (44%)     max: 25604 points
...
NVIDIA GeForce GTX 1660 (Desktop) -8%
NVIDIA GeForce GTX 1660 Super (Desktop) -5%
NVIDIA GeForce GTX 1660 Ti (Desktop) -1%
NVIDIA GeForce GTX 1070 Mobile
NVIDIA Quadro RTX 4000 Max-Q 5%
NVIDIA Quadro RTX 4000 (Laptop) 6%
NVIDIA Quadro P5200 12%
AMD Radeon Pro Vega 56 14%
...
0%
100%
3DMark Vantage
P Result 1280x1024 +
P GPU no PhysX 1280x1024 +
3DMark 03 - Standard 1024x768
141639 Points (74%)
3DMark 05 - Standard 1024x768
33386 Points (63%)
3DMark 06 Standard 1280x1024 +
Unigine Valley 1.0 - Extreme HD DirectX 1920x1080
min: 79.3     avg: 82.5     median: 82.5 (49%)     max: 85.7 fps
SPECviewperf 11
Siemens NX 1920x1080 +
Tcvis 1920x1080 +
SolidWorks 1920x1080 +
Pro/ENGINEER 1920x1080 +
Maya 1920x1080 +
Lightwave 1920x1080 +
Ensight 1920x1080 +
Catia 1920x1080 +
SPECviewperf 12
Solidworks (sw-03) 1900x1060 +
Siemens NX (snx-02) 1900x1060 +
Showcase (showcase-01) 1900x1060 +
Medical (medical-01) 1900x1060 +
Maya (maya-04) 1900x1060 +
Energy (energy-01) 1900x1060 +
Creo (creo-01) 1900x1060 +
Catia (catia-04) 1900x1060 +
Cinebench R10 Shading 32Bit +
Cinebench R11.5 OpenGL 64Bit +
Cinebench R15
OpenGL 64Bit +
Ref. Match 64Bit +
GFXBench 3.0 - Manhattan Offscreen OGL off screen
299 fps (48%)
GFXBench 3.0 - Manhattan Onscreen OGL on screen
59.9 fps (16%)
LuxMark v2.0 64Bit - Room GPUs-only
min: 2277     avg: 2849     median: 2409 (25%)     max: 4730 Samples/s
LuxMark v2.0 64Bit - Sala GPUs-only
min: 2419     avg: 3972     median: 4097 (38%)     max: 4706 Samples/s
ComputeMark v2.1 - Normal, Score 1024x600
min: 1350     avg: 11365     median: 12369.5 (44%)     max: 13299 Points
Power Consumption - Witcher 3 ultra - Power Consumption *
min: 154     avg: 179     median: 179.5 (39%)     max: 206 Watt
Clock Speed - GPU Clock Witcher 3 ultra
min: 1544     avg: 1664     median: 1670 (87%)     max: 1797 MHz
Clock Speed - GPU Clock Speed Furmark 1.19 GPU Stress Test 1280x720
1265 MHz (73%)
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Gears Tactics

Gears Tactics

2020
low 1280x720
220  fps    + Compare
med. 1920x1080
161  fps    + Compare
high 1920x1080
105  fps    + Compare
ultra 1920x1080
70.9  fps    + Compare
QHD 2560x1440
46.2  fps    + Compare
4K 3840x2160
25.3  fps    + Compare
» With all tested laptops playable in detail settings ultra.
low 1280x720
194  fps    + Compare
med. 1920x1080
128  fps    + Compare
high 1920x1080
115  fps    + Compare
ultra 1920x1080
112  fps    + Compare
QHD 2560x1440
75.5  fps    + Compare
4K 3840x2160
39  fps    + Compare
» With all tested laptops playable in detail settings ultra.
low 1280x720
184  fps    + Compare
med. 1920x1080
97.5  fps    + Compare
high 1920x1080
79.1  fps    + Compare
