NVIDIA Quadro P3000

NVIDIA Quadro P3000

英伟达Quadro P3000是笔记本电脑的移动高端工作站显卡。类似于消费级别的GeForce GTX 1060(笔记本版),它是基于GP106芯片,拥有1280个着色器。显卡专为Kaby Lake一代而设计,是Quadro M3000M(Maxwell)的后继产品。但是,P3000配备了6 GB GDDR5视频内存(带宽较低),而GTX 1060则提供3或6 GB。时钟频率范围从1088 MHz(基础)到1215 MHz(超频)到1240 MHz(最大)。

Quadro显卡提供经过认证的驱动程序,针对专业应用程序(CAD,DCC,医疗,勘探和可视化应用程序)的稳定性和性能进行了优化。因此,在这些领域的性能比相应的消费级别的显卡相比要好得多。

性能

理论性能应该与GTX 1060相当(如果时钟频率没有受到大的削弱),所以它应该比以前的M3000M快得多。

能耗

根据英伟达的消息,Quadro P5000的功耗为75瓦TGP(含内存)或55.3瓦TDP,因此该卡适用于15英寸以上的笔记本电脑。

ManufacturerNVIDIA
Quadro P Series
Quadro P5200 2560 @ 1316 - 1569 (Boost) MHz256 Bit @ 7216 MHz
Quadro P4200 2304 256 Bit @ 7800 MHz
Quadro P5000 2048 @ 1164 - 1506 (Boost) MHz256 Bit @ 6006 MHz
Quadro P5000 Max-Q 2048 @ 1101 - 1366 (Boost) MHz256 Bit @ 6006 MHz
Quadro P4000 1792 @ 1202 - 1228 (Boost) MHz256 Bit @ 6006 MHz
Quadro P4000 Max-Q 1792 @ 1113 - 1240 (Boost) MHz256 Bit @ 6006 MHz
Quadro P3200 1792 @ 1202 - 1228 (Boost) MHz192 Bit @ 7008 MHz
Quadro P3000 1280 @ 1088 - 1215 (Boost) MHz192 Bit @ 7008 MHz
Quadro P3000 Max-Q 1280 @ 1075 - 1240 (Boost) MHz192 Bit @ 7008 MHz
Quadro P1000 512 @ 1493 - 1519 (Boost) MHz128 Bit @ 6008 MHz
CodenameN17E-Q1
ArchitecturePascal
Pipelines1280 - unified
Core Speed1088 - 1215 (Boost) MHz
Memory Speed7008 MHz
Memory Bus Width192 Bit
Memory TypeGDDR5
Max. Amount of Memory16384 MB
Shared Memoryno
DirectXDirectX 12_1, Shader 5.0
technology16 nm
FeaturesOptimus, PhysX, 3D Vision Pro, nView, Optimus
Notebook Sizelarge
Date of Announcement11.01.2017
Link to Manufacturer Pagehttp://www.nvidia.com/object/quadro-for-...

Benchmarks

3DMark - Time Spy Score 2560x1440
2999 Points (28%)
3DMark - Time Spy Graphics 2560x1440
2864 Points (22%)
3DMark - Ice Storm Unlimited Graphics Score 1280x720 offscreen
min: 316202     avg: 331998     median: 331998 (70%)     max: 347794 Points
3DMark - Ice Storm Extreme Graphics 1920x1080
121766 Points (17%)
3DMark - Cloud Gate Standard Score 1280x720
min: 24508     avg: 24681     median: 24681 (50%)     max: 24854 Points
3DMark - Cloud Gate Standard Graphics 1280x720
min: 61574     avg: 63331.5     median: 63331.5 (34%)     max: 65089 Points
3DMark - Fire Strike Score 1920x1080
min: 8003     avg: 8155.5     median: 8155.5 (30%)     max: 8308 Points
3DMark - Fire Strike Graphics 1920x1080
min: 9022     avg: 9255.5     median: 9255.5 (23%)     max: 9489 Points
3DMark - Ice Storm Standard Graphics 1280x720
126996 Points (17%)
3DMark 11 - Performance 1280x720
min: 10738     avg: 11351     median: 11229 (37%)     max: 12086 points
3DMark 11 - Performance GPU 1280x720
min: 11162     avg: 12583.3     median: 12105 (24%)     max: 14483 points
...
NVIDIA Quadro M4000M -18%
NVIDIA GeForce GTX 960 -14%
NVIDIA Quadro M5000M -5%
NVIDIA Quadro P3000
AMD Radeon HD 8970M Crossfire 5%
NVIDIA GeForce GTX 780M SLI 12%
AMD Radeon RX Vega M GH 14%
AMD Radeon RX 580 (Laptop) 21%
NVIDIA Quadro P4000 23%
...
NVIDIA GeForce GTX 1070 SLI (Desktop) 239%
0%
100%
3DMark Vantage
P Result 1280x1024 +
P GPU no PhysX 1280x1024 +
3DMark 06 Standard 1024x768 +
Unigine Valley 1.0 - Extreme HD DirectX 1920x1080
50.9 fps (35%)
SPECviewperf 11
Siemens NX 1920x1080 +
Tcvis 1920x1080 +
SolidWorks 1920x1080 +
Pro/ENGINEER 1920x1080 +
Maya 1920x1080 +
Lightwave 1920x1080 +
Ensight 1920x1080 +
Catia 1920x1080 +
SPECviewperf 12
Solidworks (sw-03) 1900x1060 +
Siemens NX (snx-02) 1900x1060 +
Showcase (showcase-01) 1900x1060 +
Medical (medical-01) 1900x1060 +
Maya (maya-04) 1900x1060 +
Energy (energy-01) 1900x1060 +
Creo (creo-01) 1900x1060 +
Catia (catia-04) 1900x1060 +
Cinebench R10 Shading 32Bit +
Cinebench R11.5 OpenGL 64Bit +
Cinebench R15
OpenGL 64Bit +
Ref. Match 64Bit +
GFXBench (DX / GLBenchmark) 2.7
T-Rex HD Offscreen C24Z16 1920x1080 +
T-Rex HD Onscreen C24Z16 +
GFXBench 3.0 - Manhattan Offscreen OGL off screen
328.6 fps (60%)
GFXBench 3.0 - Manhattan Onscreen OGL on screen
60 fps (16%)
LuxMark v2.0 64Bit - Room GPUs-only
min: 1805     avg: 1814.5     median: 1814.5 (34%)     max: 1824 Samples/s
LuxMark v2.0 64Bit - Sala GPUs-only
min: 3317     avg: 3351.5     median: 3351.5 (32%)     max: 3386 Samples/s
ComputeMark v2.1 - Normal, Score 1024x600
min: 6501     avg: 6556     median: 6556 (29%)     max: 6611 Points
Power Consumption - FurMark 1.19 GPU Stress Test - Power Consumption (external Monitor) 1280x720 *
82.7 Watt (22%)
Power Consumption - The Witcher 3 Power Consumption (external Monitor) ultra 1920x1080 *
84.5 Watt (20%)
Power Consumption - Witcher 3 ultra - Power Consumption *
min: 89.1     avg: 101.8     median: 101.8 (22%)     max: 114.4 Watt
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailled information on the benchmark results, click on the fps number.

Prey

Prey

2017
ultra 1920x1080
89.3  fps    + Compare
» With all tested laptops playable in detail settings ultra.
low 1280x720
84  fps    + Compare
med. 1920x1080
41.2  fps    + Compare
high 1920x1080
28.7  fps    + Compare
ultra 1920x1080
25.4  fps    + Compare
3840x2160
9.6  fps    + Compare
