NVIDIA GeForce RTX 3060 Laptop GPU
Nvidia GeForce RTX 3060 Mobile（适用于笔记本电脑、GN20-E3、Max-P）是2021年初笔记本电脑的第三个安培显卡。 基于GA106安培芯片，提供6GB GDDR6图形内存和192位内存总线。 支持PCIe 4.0，可提供60瓦特或115瓦特(TGP)的不同版本。 作为封装，笔记本电脑的显卡使用GB5-256，芯片大小为40x40mm。 GPU 支持 eDP 1.4b 连接内部监视器。
Max-Q 变体（以前用于低功耗变体）已不存在，但所有 OEM 都可以选择实施 Max-Q 技术（动态 Boost、Whisper Mode）。
性能取决于笔记本电脑的TGP设置和冷却。 平均而言，它与以前的 GeForce RTX 2070 Super Mobile 相似，因此最适合 QHD 游戏（非常苛刻的游戏）。 像《星球大战》中队这样的要求较低的游戏可以在4K内进行，并且可以最大限度地设定细节。 类似的RTX 3060 Ti台式机卡速度非常快。
GA106芯片提供3,840个FP32ALU，其中一半可以执行INT32指令（1,920个INT32ALU）。 移动 RTX 3060 仅支持芯片上的所有 3840 个核心。 如果使用 Turing，则所有着色器都可以执行 FP32 或 INT32 指令。 Nvidia还改善了芯片上的光线跟踪和张量核。 安培芯片还包括改进的第 5代视频编码器 (H.264和 H.265的 NVENC)和第 7代解码器 (包括 AV1的各种格式 )。
GA106芯片由Samsung以8nm（8N）制造，与TSMC的7nm节点（AMD、专业GA100安培芯片等）相比，性能差很多。
| GeForce RTX 3000 Series | |
| Codename | GN20-E3 GA106 |
| Architecture | Ampere |
| Pipelines | 3840 - unified |
| TMUs | 120 |
| ROPs | 48 |
| Raytracing Cores | 30 |
| Tensor / AI Cores | 120 |
| Core Speed | 817 - 1702 (Boost) MHz |
| Memory Speed | 14000 effective = 1750 MHz |
| Memory Bus Width | 192 Bit |
| Memory Type | GDDR6 |
| Max. Amount of Memory | 6 GB |
| Shared Memory | no |
| Memory Bandwidth | 336 GB/s |
| API | DirectX 12_2, Shader 7.0, OpenGL 4.6 |
| Power Consumption | 115 Watt (60 - 115 Watt TGP) |
| technology | 8 nm |
| PCIe | 4.0 |
| Displays | HDMI 2.1, DisplayPort 1.4a |
| Features | NVIDIA DLSS, NVIDIA Reflex, Resizable BAR, NVIDIA Broadcast, NVIDIA Ansel, NVIDIA ShadowPlay®, NVIDIA G-SYNC®, Advanced Optimus, Nvidia Max-Q, Dynamic Boost |
| Notebook Size | large |
| Date of Announcement | 04.01.2021 |
Benchmarks
Performance Rating - 3DMark 11 + Fire Strike + Time Spy
32.4 pt (35%)
Intel HD Graphics (Bay Trail) -97%
...
AMD Radeon RX Vega M GH -11%
NVIDIA GeForce GTX 780M SLI -10%
NVIDIA Quadro RTX 5000 Max-Q -8%
NVIDIA GeForce RTX 2070 Super Max-Q -8%
NVIDIA GeForce GTX 980 (Laptop) -4%
NVIDIA GeForce RTX 3060 Laptop GPU
...
3DMark - 3DMark Time Spy Score
min: 6529 avg: 8089 median: 8264 (43%) max: 9677 Points
| GPU TDP ? | TDP 65 W | TDP 70 W | TDP 75 W | TDP 80 W | TDP 85 W | TDP 95 W | TDP 100 W | TDP 105 W | TDP 120 W | TDP 125 W | TDP 130 W | TDP 140 W |
|---|
| 90% | 73% | 79% | 82% | 80% | 80% | 81% | 91% | 87% | 93% | 91% | 93% | 100% |
Intel UHD Graphics 605 -98%
...
NVIDIA Quadro RTX 4000 Max-Q -17%
NVIDIA Quadro RTX 5000 Max-Q -10%
NVIDIA Quadro RTX 4000 (Laptop) -9%
NVIDIA GeForce RTX 2070 Super Max-Q -6%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce RTX 2070 Super Mobile 3%
...
3DMark - 3DMark Time Spy Graphics
min: 6437 avg: 7982 median: 8068.5 (37%) max: 9174 Points
| GPU TDP ? | TDP 65 W | TDP 70 W | TDP 75 W | TDP 80 W | TDP 85 W | TDP 95 W | TDP 100 W | TDP 105 W | TDP 120 W | TDP 125 W | TDP 130 W | TDP 140 W |
|---|
| 92% | 73% | 80% | 83% | 82% | 81% | 85% | 92% | 89% | 96% | 94% | 97% | 100% |
Intel UHD Graphics 605 -99%
...
NVIDIA Quadro RTX 4000 Max-Q -15%
NVIDIA GeForce GTX 1080 Mobile -14%
NVIDIA Quadro RTX 4000 (Laptop) -9%
NVIDIA Quadro RTX 5000 Max-Q -7%
NVIDIA GeForce RTX 2070 Super Max-Q -7%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce RTX 2070 Super Mobile 3%
NVIDIA GeForce RTX 2080 Super Mobile 29%
...
3DMark - 3DMark Ice Storm Unlimited Graphics
min: 116696 avg: 339251 median: 360476 (48%) max: 519354 Points
| GPU TDP 100 W | TDP 120 W | TDP 130 W |
|---|
| 100% | 59% | 51% |
NVIDIA Quadro K5100M -99%
...
NVIDIA GeForce GTX 1050 Max-Q -6%
NVIDIA Quadro M5000M -4%
NVIDIA GeForce GTX 1050 Ti Max-Q -4%
NVIDIA Quadro P2000 Max-Q -4%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA Quadro P2000 3%
AMD Radeon RX Vega M GH 5%
NVIDIA Quadro P4000 9%
NVIDIA GeForce GTX 980 (Laptop) 9%
...
3DMark - 3DMark Ice Storm Extreme Graphics
304456 Points (42%)
Intel HD Graphics (Bay Trail) -98%
...
AMD Radeon HD 8970M Crossfire -21%
NVIDIA Quadro M5000M -17%
AMD Radeon RX Vega M GH -7%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce GTX 1080 Mobile 1%
3DMark - 3DMark Cloud Gate Score
min: 28859 avg: 44282 median: 44523 (54%) max: 58475 Points
| GPU TDP ? | TDP 70 W | TDP 75 W | TDP 80 W | TDP 85 W | TDP 95 W | TDP 105 W | TDP 120 W | TDP 125 W | TDP 130 W | TDP 140 W |
|---|
| 73% | 62% | 83% | 84% | 84% | 76% | 64% | 98% | 86% | 92% | 100% |
Intel Graphics Media Accelerator (GMA) 4500MHD -100%
...
NVIDIA Quadro RTX 4000 (Laptop) -12%
NVIDIA Quadro P5200 -2%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce RTX 2070 Super Mobile 2%
NVIDIA GeForce RTX 2070 Super Max-Q 3%
...
3DMark - 3DMark Cloud Gate Graphics
min: 33126 avg: 102208 median: 109734 (45%) max: 136275 Points
| GPU TDP ? | TDP 70 W | TDP 75 W | TDP 80 W | TDP 85 W | TDP 95 W | TDP 105 W | TDP 120 W | TDP 125 W | TDP 130 W | TDP 140 W |
|---|
| 60% | 36% | 77% | 59% | 89% | 84% | 60% | 100% | 63% | 91% | 79% |
Intel Graphics Media Accelerator (GMA) 4500MHD -100%
...
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA Quadro P5200 4%
NVIDIA GeForce RTX 2070 Super Max-Q 15%
NVIDIA Quadro RTX 4000 (Laptop) 16%
...
3DMark - 3DMark Fire Strike Standard Score
min: 15376 avg: 18273 median: 18451 (46%) max: 21179 Points
| GPU TDP ? | TDP 65 W | TDP 70 W | TDP 75 W | TDP 80 W | TDP 85 W | TDP 95 W | TDP 100 W | TDP 105 W | TDP 120 W | TDP 125 W | TDP 130 W | TDP 140 W |
|---|
| 92% | 78% | 78% | 84% | 85% | 84% | 87% | 86% | 92% | 92% | 94% | 96% | 100% |
...
NVIDIA Quadro P5200 -9%
NVIDIA Quadro RTX 5000 Max-Q -8%
NVIDIA Quadro RTX 4000 (Laptop) -7%
NVIDIA GeForce GTX 1080 Mobile -7%
NVIDIA GeForce RTX 2070 Super Max-Q -1%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce RTX 2070 Super Mobile 2%
NVIDIA GeForce RTX 2080 Super Mobile 18%
...
3DMark - 3DMark Fire Strike Standard Graphics
min: 16956 avg: 20260 median: 20346.5 (38%) max: 23109 Points
| GPU TDP ? | TDP 65 W | TDP 70 W | TDP 75 W | TDP 80 W | TDP 85 W | TDP 95 W | TDP 100 W | TDP 105 W | TDP 120 W | TDP 125 W | TDP 130 W | TDP 140 W |
|---|
| 94% | 78% | 81% | 84% | 83% | 85% | 89% | 82% | 93% | 91% | 92% | 98% | 100% |
...
NVIDIA Quadro P5200 -9%
NVIDIA Quadro RTX 4000 (Laptop) -7%
NVIDIA Quadro RTX 5000 Max-Q -2%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce RTX 2070 Super Max-Q 0%
NVIDIA GeForce GTX 1080 Mobile 5%
NVIDIA GeForce RTX 2070 Super Mobile 8%
NVIDIA GeForce RTX 2080 Super Mobile 23%
...
3DMark - 3DMark Ice Storm Graphics
min: 124176 avg: 199105 median: 140124 (19%) max: 333015 Points
| GPU TDP 85 W | TDP 125 W | TDP 130 W |
|---|
| 37% | 42% | 100% |
Intel Graphics Media Accelerator (GMA) 4500MHD -97%
...
NVIDIA Quadro K5100M -15%
AMD Radeon R9 M295X -9%
NVIDIA GeForce RTX 3060 Laptop GPU
AMD Radeon 680M 1%
AMD Radeon R9 M395 2%
AMD FirePro M6100 8%
NVIDIA Quadro M4000M 10%
...
3DMark - 3DMark Night Raid
44997 Points (54%)
Intel UHD Graphics 600 -96%
...
NVIDIA GeForce RTX 3060 Laptop GPU
3DMark - 3DMark Night Raid Graphics Score
86045 Points (48%)
Intel UHD Graphics 600 -98%
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
3DMark 11 - 3DM11 Performance Score
min: 14164 avg: 22393 median: 22357.5 (45%) max: 28541 Points
| GPU TDP ? | TDP 65 W | TDP 70 W | TDP 75 W | TDP 80 W | TDP 85 W | TDP 95 W | TDP 100 W | TDP 105 W | TDP 120 W | TDP 125 W | TDP 130 W | TDP 140 W |
|---|
| 85% | 79% | 84% | 78% | 73% | 80% | 79% | 89% | 66% | 86% | 84% | 88% | 100% |
...
NVIDIA Quadro RTX 5000 Max-Q -5%
NVIDIA Quadro RTX 4000 (Laptop) -4%
NVIDIA Quadro P5200 -3%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce RTX 2070 Super Max-Q 3%
NVIDIA GeForce RTX 2070 Super Mobile 6%
...
3DMark 11 - 3DM11 Performance GPU
min: 13799 avg: 26202 median: 26722 (38%) max: 30772 Points
| GPU TDP ? | TDP 65 W | TDP 70 W | TDP 75 W | TDP 80 W | TDP 85 W | TDP 95 W | TDP 100 W | TDP 105 W | TDP 120 W | TDP 125 W | TDP 130 W | TDP 140 W |
|---|
| 89% | 77% | 84% | 82% | 74% | 83% | 87% | 93% | 68% | 94% | 91% | 97% | 100% |
...
NVIDIA Quadro RTX 4000 Max-Q -10%
NVIDIA Quadro P5200 -4%
NVIDIA Quadro RTX 4000 (Laptop) -3%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA Quadro RTX 5000 Max-Q 2%
NVIDIA GeForce RTX 2070 Super Max-Q 3%
NVIDIA GeForce GTX 1080 Mobile 7%
NVIDIA GeForce RTX 2070 Super Mobile 12%
...
3DMark 06 3DMark 06 - Standard 1280x1024 +min: 37418 avg: 41961 median: 41960.5 (63%) max: 46503 Points
| GPU TDP 100 W | TDP 105 W |
|---|
| 100% | 80% |
...
NVIDIA Quadro RTX 5000 Max-Q -3%
NVIDIA GeForce RTX 2080 Super Mobile 0%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce RTX 2070 Super Mobile 3%
NVIDIA GeForce RTX 2070 Super Max-Q 3%
NVIDIA Quadro P5200 6%
...
Cinebench R10 Cinebench R10 Shading (32bit) +Cinebench R10 - Cinebench R10 Shading (32bit)
min: 4955 avg: 9518 median: 9518 (40%) max: 14081 points
| GPU TDP ? | TDP 130 W |
|---|
| 35% | 100% |
Intel Graphics Media Accelerator (GMA) 500 -100%
...
NVIDIA GeForce GTX 980 (Laptop) -4%
Intel UHD Graphics G1 (Ice Lake 32 EU) -1%
AMD FirePro W4190M 0%
NVIDIA GeForce RTX 3060 Laptop GPU
AMD FirePro W7170M 0%
Intel Iris Graphics 550 0%
AMD FirePro W4170M 1%
AMD FirePro W5130M 1%
AMD Radeon Pro WX Vega M GL 2%
Intel Iris Plus Graphics 640 2%
AMD Radeon RX 550X (Laptop) 2%
...
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 77 avg: 108.5 median: 108.5 (40%) max: 140 fps
| GPU TDP ? | TDP 130 W |
|---|
| 100% | 55% |
Intel Graphics Media Accelerator (GMA) 4500MHD -99%
...
NVIDIA Quadro P2000 Max-Q -8%
AMD Radeon Pro 460 -5%
AMD Radeon HD 8970M Crossfire -5%
NVIDIA Quadro M5000M -3%
NVIDIA Quadro P4000 -3%
NVIDIA GeForce RTX 3060 Laptop GPU
AMD Radeon Pro WX Vega M GL 0%
NVIDIA Quadro P1000 2%
NVIDIA Quadro P600 5%
AMD Radeon 680M 5%
NVIDIA Quadro RTX 3000 Max-Q 7%
NVIDIA Quadro P3200 12%
AMD Radeon RX Vega M GH 14%
...
Cinebench R15
Cinebench R15 OpenGL 64 Bit +Cinebench R15 - Cinebench R15 OpenGL 64 Bit
min: 99.5 avg: 167.1 median: 167 (45%) max: 219 fps
| GPU TDP ? | TDP 65 W | TDP 70 W | TDP 75 W | TDP 80 W | TDP 85 W | TDP 95 W | TDP 100 W | TDP 105 W | TDP 120 W | TDP 125 W | TDP 130 W | TDP 140 W |
|---|
| 100% | 96% | 99% | 91% | 74% | 97% | 86% | 79% | 92% | 52% | 70% | 81% | 94% |
Intel Graphics Media Accelerator (GMA) 4500MHD -100%
...
AMD Radeon RX Vega M GH -14%
NVIDIA Quadro P620 -5%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA Quadro P3200 0%
NVIDIA T500 Laptop GPU 1%
NVIDIA GeForce RTX 2080 Super Mobile 7%
NVIDIA Quadro P2000 8%
...
Cinebench R15 OpenGL Ref. Match 64 Bit +Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
99.6 % (100%)
| GPU TDP ? | TDP 65 W | TDP 70 W | TDP 75 W | TDP 80 W | TDP 85 W | TDP 95 W | TDP 100 W | TDP 105 W | TDP 120 W | TDP 125 W | TDP 130 W | TDP 140 W |
|---|
| 100% | 100% | 100% | 100% | 100% | 100% | 100% | 100% | 100% | 100% | 100% | 100% | 100% |
...
NVIDIA Quadro K620M 0%
NVIDIA Quadro K5100M 0%
NVIDIA GeForce GTX 780M 0%
NVIDIA GeForce GTX 1050 Max-Q 0%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA Quadro P3200 0%
NVIDIA Quadro RTX 4000 (Laptop) 0%
...
Power Consumption - Furmark Stress Test Power Consumption - external Monitor *
min: 103 avg: 146.3 median: 147 (23%) max: 202 Watt
| GPU TDP 65 W | TDP 70 W | TDP 75 W | TDP 85 W | TDP 95 W | TDP 100 W | TDP 105 W | TDP 115 W | TDP 125 W | TDP 130 W | TDP 140 W |
|---|
| 116% | 116% | 113% | 108% | 110% | 105% | 106% | 101% | 102% | 104% | 100% |
...
NVIDIA Quadro P4000 Max-Q -17%
NVIDIA Quadro RTX 5000 Max-Q -14%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA Quadro RTX 4000 Max-Q 2%
NVIDIA GeForce RTX 2070 Super Mobile 20%
...
Acer Aspire Nitro 5 AN515-55-57GF : Ø118.1 (116-129)
Schenker XMG Core 17 (Early 2021) : Ø168.5 (163-172)
Alienware m15 R5 Ryzen Edition : Ø170 (166-181)
Lenovo Legion 5 Pro 16IAH7H : Ø176 (172.3-207)
Power Consumption - The Witcher 3 Power Consumption - external Monitor *
min: 108 avg: 145.5 median: 143.5 (20%) max: 185 Watt
| GPU TDP 65 W | TDP 70 W | TDP 75 W | TDP 80 W | TDP 85 W | TDP 95 W | TDP 100 W | TDP 105 W | TDP 115 W | TDP 125 W | TDP 130 W | TDP 140 W |
|---|
| 113% | 115% | 114% | 115% | 110% | 110% | 108% | 108% | 100% | 105% | 107% | 102% |
...
NVIDIA Quadro P3200 -23%
NVIDIA Quadro RTX 5000 Max-Q -15%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA Quadro RTX 4000 Max-Q 5%
NVIDIA GeForce RTX 2070 Super Max-Q 5%
...
NVIDIA GeForce GTX 1080 Mobile 51%
Acer Aspire Nitro 5 AN515-55-57GF : Ø124.5 (119-138)
Alienware m15 R5 Ryzen Edition : Ø164.2 (161-170)
Schenker XMG Core 17 (Early 2021) : Ø169.8 (161-178)
Lenovo Legion 5 Pro 16IAH7H : Ø191 (186.1-207)
Power Consumption - Witcher 3 Power Consumption *
min: 111 avg: 150 median: 148.5 (33%) max: 195 Watt
| GPU TDP 65 W | TDP 70 W | TDP 75 W | TDP 80 W | TDP 85 W | TDP 95 W | TDP 100 W | TDP 105 W | TDP 115 W | TDP 120 W | TDP 125 W | TDP 130 W | TDP 140 W |
|---|
| 127% | 130% | 129% | 131% | 118% | 121% | 115% | 114% | 100% | 111% | 107% | 111% | 104% |
Intel UHD Graphics 605 -92%
...
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA Quadro RTX 5000 Max-Q 1%
NVIDIA GeForce RTX 2070 Super Max-Q 4%
NVIDIA Quadro RTX 4000 (Laptop) 6%
NVIDIA Quadro RTX 4000 Max-Q 12%
...
