NVIDIA GeForce 920MX

NVIDIA GeForce 920MX

Nvidia GeForce 920MX是一款用于笔记本电脑的入门级显卡,于2016年第一季度推出。与旧的920M相比,920MX现在是基于930MX的现代麦克斯韦芯片,但减少了265个着色器的数量(GM108)。根据我们的消息来源,5-12瓦的TDP和对DDR3和GDDR5的支持也被指定。

性能取决于所使用的图形存储器。在我们的测试中,DDR3版本比普通的GeForce 930M略慢(肯定比GeForce 920M快)。因此,GDDR5版本的性能可能略微超过930M。然而,这两个版本都不适合2017年的高要求游戏。要求不高的游戏,如《模拟人生4》,在中高设置下应该是可以玩的(见下文的基准测试)。

由于功耗低,GeForce 920MX也适用于轻薄型笔记本电脑。

ManufacturerNVIDIA
GeForce 900M Series
GeForce 945M 512 @ 0.93 - 1.05 GHz128 Bit @ 2000 MHz
Maxwell GPU (940M, GDDR5) 384 @ 0.95 - 0.99 GHz64 Bit @ 5012 MHz
GeForce 940MX 384 @ 1.12 - 1.24 GHz64 Bit @ 4000 MHz
GeForce 940M 384 @ 1.07 - 1.18 GHz64 Bit @ 2000 MHz
GeForce 930MX 384 @ 0.95 - 1.02 GHz64 Bit @ 2000 MHz
GeForce 930M 384 @ 0.93 - 0.94 GHz64 Bit @ 1800 MHz
GeForce 920MX 256 @ 0.97 - 0.99 GHz64 Bit @ 1800 MHz
GeForce 920M 384 @ 0.95 GHz64 Bit @ 1800 MHz
GeForce 910M 384 @ 0.64 GHz64 Bit @ 2000 MHz
CodenameN16V-GMR
ArchitectureMaxwell
Pipelines256 - unified
Core Speed965 - 993 (Boost) MHz
Memory Speed1800 MHz
Memory Bus Width64 Bit
Memory TypeGDDR5/DDR3
Shared Memoryno
DirectXDirectX 12, Shader 5.0
technology28 nm
FeaturesOptimus, PhysX, Verde Drivers, CUDA, 3D Vision, 3DTV Play, GameWorks
Date of Announcement25.03.2015
Link to Manufacturer Pagehttp://www.geforce.com/hardware/notebook...

Benchmarks

Performance Rating - 3DMark 11 + Fire Strike + Time Spy
7.7 pt (8%)
AMD Radeon HD 8180 -83%
...
AMD Radeon Pro WX 3100 -9%
AMD Radeon HD 8790M -7%
NVIDIA GeForce GT 745M -5%
NVIDIA Quadro K2100M -5%
Intel UHD Graphics Xe G4 48EUs -4%
NVIDIA Quadro M1000M -3%
NVIDIA GeForce GT 640M -1%
NVIDIA GeForce 920MX
NVIDIA GeForce GT 750M 2%
Intel Iris Graphics 540 2%
NVIDIA Quadro M600M 7%
Intel Iris Plus Graphics G4 (Ice Lake 48 EU) 7%
AMD Radeon R7 M275DX 8%
Intel HD Graphics 630 11%
...
0%
100%
3DMark - 3DMark Time Spy Score
472 Points (3%)
3DMark - 3DMark Time Spy Graphics
417 Points (2%)
Intel UHD Graphics 600 -74%
...
Intel HD Graphics 630 -12%
Intel UHD Graphics Xe 16EUs (Tiger Lake-H) -11%
AMD Radeon R7 M360 -2%
NVIDIA GeForce 920MX
Intel UHD Graphics G1 (Ice Lake 32 EU) 1%
Intel Iris Plus Graphics 640 6%
AMD Radeon R7 M445 13%
AMD Radeon RX Vega 6 (Ryzen 2000/3000) 32%
Intel Iris Plus Graphics 650 33%
...
0%
100%
3DMark - 3DMark Ice Storm Unlimited Graphics
min: 98596     avg: 110110     median: 110110 (16%)     max: 121624 Points
3DMark - 3DMark Ice Storm Extreme Graphics
min: 49876     avg: 57473     median: 57473 (8%)     max: 65070 Points
3DMark - 3DMark Cloud Gate Score
min: 5744     avg: 6545     median: 6545 (9%)     max: 7346 Points
3DMark - 3DMark Cloud Gate Graphics
min: 7733     avg: 9114     median: 9113.5 (4%)     max: 10494 Points
3DMark - 3DMark Fire Strike Standard Score
min: 1154     avg: 1337     median: 1336.5 (3%)     max: 1519 Points
3DMark - 3DMark Fire Strike Standard Graphics
min: 1282     avg: 1448     median: 1448 (3%)     max: 1614 Points
3DMark - 3DMark Ice Storm Graphics
min: 73997     avg: 83643     median: 83642.5 (11%)     max: 93288 Points
3DMark 11 - 3DM11 Performance Score
min: 1800     avg: 1993     median: 1983 (5%)     max: 2200 Points
3DMark 11 - 3DM11 Performance GPU
min: 1747     avg: 1823     median: 1835 (3%)     max: 1887 Points
...
AMD Radeon R5 M335 -2%
AMD Radeon R7 (Carrizo) -2%
NVIDIA Quadro K1100M 0%
NVIDIA GeForce 920MX
AMD Radeon R7 M270 2%
AMD Radeon R7 M260 4%
AMD Radeon R7 M260X 4%
Intel Iris Pro Graphics 5200 5%
...
AMD Radeon RX 6800M 2188%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
min: 6584     avg: 7408     median: 7407.5 (7%)     max: 8231 Points
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
min: 5850     avg: 6665     median: 6665 (6%)     max: 7480 Points
ATI Radeon HD 3200 -99%
...
Intel HD Graphics 630 -7%
NVIDIA GeForce 9800M GTS SLI -5%
ATI Mobility Radeon HD 3870 X2 -3%
NVIDIA GeForce GT 640M -1%
NVIDIA GeForce 920MX
AMD Radeon R7 M260X 4%
NVIDIA GeForce 940M 4%
NVIDIA Quadro K1100M 7%
...
0%
100%
3DMark 03 - 3DMark 03 - Standard
30702 Points (16%)
3DMark 05 - 3DMark 05 - Standard
21185 Points (31%)
Intel Graphics Media Accelerator (GMA) 500 -99%
...
NVIDIA GeForce 920MX
AMD Radeon R7 M445 0%
NVIDIA GeForce GT 745M 2%
NVIDIA GeForce GTX 285M SLI 2%
NVIDIA GeForce GTX 950M 8%
...
AMD Radeon RX 6800M 120%
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
min: 10781     avg: 12206     median: 12205.5 (20%)     max: 13630 Points
Unigine Valley 1.0 - Unigine Valley 1.0 DX
8.7 fps (4%)
Unigine Heaven 3.0 - Unigine Heaven 3.0 DX 11
21.2 fps (7%)
Unigine Heaven 3.0 - Unigine Heaven 3.0 OpenGL
20.3 fps (9%)
Unigine Heaven 2.1 - Heaven 2.1 high
min: 26.4     avg: 27.9     median: 27.9 (5%)     max: 29.4 fps
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
min: 2632     avg: 4406     median: 4366 (21%)     max: 6219 points
Cinebench R15
Cinebench R15 OpenGL 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL 64 Bit
min: 36.81     avg: 47.1     median: 47.7 (13%)     max: 56.89 fps
Cinebench R15 OpenGL Ref. Match 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
99.6 % (100%)
GFXBench (DX / GLBenchmark) 2.7
GFXBench 2.7 T-Rex HD Onscreen C24Z16 +
GFXBench (DX / GLBenchmark) 2.7 - GFXBench 2.7 T-Rex HD Onscreen C24Z16
min: 60     avg: 89     median: 89 (3%)     max: 117.9 fps
GFXBench T-Rex HD Offscreen C24Z16 +
GFXBench (DX / GLBenchmark) 2.7 - GFXBench T-Rex HD Offscreen C24Z16
min: 103.1     avg: 115     median: 115.2 (1%)     max: 127.3 fps
GFXBench 3.0 - GFXBench 3.0 Manhattan
min: 58.9     avg: 60.5     median: 60.5 (17%)     max: 62.1 fps
GFXBench 3.0 - GFXBench 3.0 Manhattan Offscreen
min: 55.7     avg: 62.9     median: 62.9 (5%)     max: 70 fps
GFXBench - GFXBench Car Chase Onscreen
min: 33.1     avg: 40.4     median: 40.4 (1%)     max: 47.7 fps
GFXBench - GFXBench Car Chase Offscreen
min: 29.9     avg: 32.7     median: 32.7 (0%)     max: 35.4 fps
LuxMark v2.0 64Bit - LuxMark v2.0 Room GPU
min: 210     avg: 230     median: 230 (1%)     max: 250 Samples/s
LuxMark v2.0 64Bit - LuxMark v2.0 Sala GPU
min: 400     avg: 427     median: 427 (1%)     max: 454 Samples/s
ComputeMark v2.1 - ComputeMark v2.1 Result
min: 1066     avg: 1139     median: 1139 (2%)     max: 1212 points
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

low 1280x720
23.8  fps    + Compare
med. 1920x1080
9.6  fps    + Compare
high 1920x1080
8.1  fps    + Compare
ultra 1920x1080
5.9  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1280x720
17.3  fps    + Compare
med. 1920x1080
8.2  fps    + Compare
high 1920x1080
5  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Fortnite

Fortnite

2018
low 1280x720
76.7  fps    + Compare
med. 1920x1080
21.2  fps    + Compare
high 1920x1080
14.5  fps    + Compare
ultra 1920x1080
11.4  fps    + Compare
» With all tested laptops playable in detail settings low.
low 1280x720
45.4  fps    + Compare
med. 1920x1080
12.8  fps    + Compare
high 1920x1080
10.5  fps    + Compare
ultra 1920x1080
8.9  fps    + Compare
» With all tested laptops playable in detail settings low.
low 1280x720
30.4  fps    + Compare
med. 1920x1080
15.3  fps    + Compare
high 1920x1080
12.2  fps    + Compare
ultra 1920x1080
11.6  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1280x720
53.7  fps    + Compare
med. 1920x1080
33.1  fps    + Compare
high 1920x1080
16.3  fps    + Compare
ultra 1920x1080
11.9  fps    + Compare
» With all tested laptops playable in detail settings low.
low 1280x720
22  fps    + Compare
med. 1920x1080
10  fps    + Compare
high 1920x1080
8  fps    + Compare
ultra 1920x1080
6  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Destiny 2

Destiny 2

2017
low 1280x720
43.6  fps    + Compare
med. 1920x1080
25.9  fps    + Compare
high 1920x1080
23.6  fps    + Compare
ultra 1920x1080
18  fps    + Compare
» With all tested laptops playable in detail settings low.
ELEX

ELEX

2017
low 1280x720
25.1  fps    + Compare
med. 1920x1080
11.9  fps    + Compare
high 1920x1080
9.3  fps    + Compare
ultra 1920x1080
6.4  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1280x720
17.9  fps    + Compare
med. 1920x1080
9.2  fps    + Compare
high 1920x1080
8.1  fps    + Compare
ultra 1920x1080
6.1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1280x720
33  fps    + Compare
med. 1920x1080
13  fps    + Compare
high 1920x1080
9  fps    + Compare
ultra 1920x1080
7  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
FIFA 18

FIFA 18

2017
low 1280x720
110.4  fps    + Compare
med. 1920x1080
63.8  fps    + Compare
high 1920x1080
54.2  fps    + Compare
ultra 1920x1080
50  fps    + Compare
» With all tested laptops playable in detail settings ultra.
F1 2017

F1 2017

2017
low 1280x720
41  fps    + Compare
med. 1920x1080
18  fps    + Compare
high 1920x1080
15  fps    + Compare
ultra 1920x1080
13  fps    + Compare
» With all tested laptops playable in detail settings low.
low 1280x720
86  fps    + Compare
med. 1366x768
81  fps    + Compare
high 1920x1080
69  fps    + Compare
ultra 1920x1080
54  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Dirt 4

Dirt 4

2017
low 1280x720
62.4  fps    + Compare
med. 1920x1080
25.2  fps    + Compare
