Intel Core i5-1140G7

Intel i5-1140G7

英特尔酷睿i5-1140G7是基于2021年初推出的Tiger Lake-U Generation (UP4)的笔记本电脑和Ultra Book的能效四核SoC。 4个Willow Cove处理器内核(Hyper-Threading支持8个线程)。 保证的基本时钟速度因TDP设定而异,范围为0.8(7WTDP)~1.8GHz(15WTDP)。 涡轮时钟速度为4.2GHz(一个核心)。所有核心最高可达3.5GHz。

此外,基于全新Gen 12体系结构的集成Xe显卡和80EU。 与以前的Iris Plus G7(冰湖)相比,性能显著提高。 在 i5-1140G7中,96个 EU中的 80个使用 400~1100MHz的时钟。 GPU 和 CPU 可以同时使用 8 MB 的 L3 高速缓存。

此外,Tiger Lake SoCs还添加了PCIe 4支持(4通道)、AI硬件加速、Thunderbolt 4/USB 4和Wi-Fi 6的部分集成到芯片中。 i5-1140G7还支持管理功能博锐。

芯片在英特尔改进的 10nm+ 工艺(称为 SuperFin)中生产,与 TSMC 的 7nm 工艺(例如,Ryzen 4000 系列)相同。

UP4系列的动作范围为7~是15瓦特。 因此,处理器非常适合超薄、轻巧的笔记本电脑、敞篷和平板电脑。

SeriesIntel Tiger Lake
CodenameTiger Lake UP4
Series: Tiger Lake Tiger Lake UP4
Intel Core i7-1180G72.2 - 4.6 GHz4 / 812 MB
Intel Core i7-1160G72.1 - 4.4 GHz4 / 812 MB
» Intel Core i5-1140G71.8 - 4.2 GHz4 / 88 MB
Intel Core i5-1130G71.8 - 4 GHz4 / 88 MB
Intel Core i3-1120G41.1 - 3.5 GHz4 / 88 MB
Intel Core i3-1110G42.5 - 3.9 GHz2 / 46 MB
Clock Rate1800 - 4200 MHz
Level 1 Cache320 KB
Level 2 Cache5 MB
Level 3 Cache8 MB
Number of Cores / Threads4 / 8
Power Consumption (TDP = Thermal Design Power)15 Watt
Manufacturing Technology10 nm
Max. Temperature100 °C
SocketBGA1598
FeaturesDL Boost, GNA, Wi-Fi 6 (Gig+), Thunderbolt 4, LPDDR4x-4266
GPUIntel Iris Xe Graphics G7 80EUs (400 - 1100 MHz)
64 Bit64 Bit support
Architecturex86
Announcement Date09/02/2020
Product Link (external)Intel Tiger Lake i5-1140G7

Benchmarks

- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
