Apple MacBook Pro 16 M4 Max 评测 - M4 Max 是最快的移动处理器之一
Apple 新款 M4 Max 的顶级配置增加了两个性能核心和速度极快的显卡。然而，MacBook Pro 16 的散热却拖了 M4 Max 的后腿，使其无法充分发挥潜力。是时候采用新的机箱设计了吗？
Apple M4 Max 16-Core, M4 Max 40-Core GPU, 16.2", 2.1 kgApple M4 Max 40-Core GPU
Apple M4 Max GPU（40 核）是内置在 16 核M4 MaxSoC 中的集成图形适配器。 16 核Apple M4 Max SoC 中内置的集成图形适配器。.它有 40 个 "内核"，可访问至少 48 GB 快速 546 GB/s LPDDR5x 封装 RAM（取决于配置）。与 2024 年发布的图形适配器一样，它的硬件支持光线追踪、网格着色和其他现代技术。它还支持分辨率高达 "8K "的外部显示器，并能对 h.264、h.265 和 AV1 等几种流行的视频编解码器进行硬件解码。
性能
其游戏性能与 GeForce RTX 4070 笔记本电脑.请记住，很少有游戏是专门为Apple silicon Macs 编译的，这意味着大多数游戏必须通过模拟层运行。因此，有些游戏在显示时会出现视觉假象，或者根本无法启动。
功耗
考虑到所提供的功率，我们预计 iGPU 在重负载时的功耗将超过 45 W。
与Apple M4 Max 芯片的其他部分一样，集成图形适配器也是采用 "第二代 3 纳米 "台积电工艺制造的，这种工艺到 2024 年底仍是最先进的。
Apple M4 Series
| |||||||||||||||||||
| iGPU | Integrated Graphics | ||||||||||||||||||
| Pipelines | 40 - unified | ||||||||||||||||||
| Raytracing Cores | 40 | ||||||||||||||||||
| Memory Speed | 8533 MHz | ||||||||||||||||||
| Memory Type | LPDDR5x-8533 | ||||||||||||||||||
| Shared Memory | yes | ||||||||||||||||||
| Memory Bandwidth | 546 GB/s | ||||||||||||||||||
| Power Consumption | 75 Watt | ||||||||||||||||||
| Man. Technology | 3 nm | ||||||||||||||||||
| Notebook Size | large | ||||||||||||||||||
| Date of Announcement | 30.10.2024 | ||||||||||||||||||
| Predecessor | M3 Max 40-Core GPU | ||||||||||||||||||
| ||||||||
Benchmarks
3DMark - 3DMark Steel Nomad
3621 Points (25%)
3DMark - 3DMark Steel Nomad Light
min: 13989 avg: 14211 median: 14210.5 (32%) max: 14432 Points
3DMark - 3DMark Wild Life Extreme Unlimited
37434 Points (43%)
Blender - Blender 3.3 Classroom METAL *
17.8 Seconds (2%)
Cinebench R15 OpenGL 64 Bit +
Cinebench R15 OpenGL Ref. Match 64 Bit +
GFXBench - GFXBench 5.0 4K Aztec Ruins High Tier Offscreen
231.7 fps (87%)
GFXBench - GFXBench 5.0 Aztec Ruins High Tier Offscreen
516 fps (93%)
...
Apple M1 Max 32-Core GPU
Apple M4 Max 40-Core GPU
0%
100%
GFXBench - GFXBench 5.0 Aztec Ruins Normal Tier Offscreen
1302 fps (96%)
GFXBench - GFXBench Car Chase Offscreen
941 fps (89%)
GFXBench 3.1 - GFXBench Manhattan ES 3.1 Offscreen
1647 fps (35%)
GFXBench 3.0 - GFXBench 3.0 Manhattan Offscreen
2400 fps (100%)
GFXBench T-Rex HD Offscreen C24Z16 +
Geekbench 6.5 - Geekbench 6.5 GPU OpenCL
116455 points (30%)
Geekbench 6.5 - Geekbench 6.5 GPU Metal
179746 points (81%)
Power Consumption - Cyberpunk 2077 Power Consumption 150cd *
116.2 Watt (32%)
Power Consumption - Cyberpunk 2077 Power Consumption - external Monitor *
min: 107.2 avg: 113.3 median: 113.3 (14%) max: 119.3 Watt
Power Consumption - Power Efficiency - Cyberpunk 2077 ultra
min: 0.4496 avg: 0.6 median: 0.6 (2%) max: 0.657 fps per Watt
- Range of benchmark values
- Average benchmark values
* Smaller numbers mean a higher performance
- Average benchmark values* Smaller numbers mean a higher performance
Game Benchmarks
The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.
Total War Pharaoh
2023
Cyberpunk 2077
2023low 1920x1080
med. 1920x1080
high 1920x1080
ultra 1920x1080
QHD 2560x1440
4K 3840x2160
» With all tested laptops playable in detail settings ultra.
Additional Benchmarks
30min Start Ultra Preset (FSR off) 1920x1080
Baldur's Gate 3
2023
The Witcher 3
2015| low | med. | high | ultra | QHD | 4K | |
|---|---|---|---|---|---|---|
| Assassin's Creed Shadows | 58 | 53 | 48 | 33 | 29 | 20 |
| Total War Pharaoh | 74.1 | 61.8 | 56.1 | 56 | 56 | 50 |
| Cyberpunk 2077 | 93 | 79 | 72 | 66 | 48 | 22 |
| Baldur's Gate 3 | 164 | 131 | 101 | 99 | 69 | 35 |
| Shadow of the Tomb Raider | 167 | 143 | 129 | 94 | 51 | |
| The Witcher 3 | 157 | 107 | 78 | 61 | ||
| low | med. | high | ultra | QHD | 4K | < 30 fps < 60 fps < 120 fps ≥ 120 fps | 1 2 1 | 1 2 2 | 2 2 2 | 2 3 1 | 1 2 3 | 2 3 1 |
For more games that might be playable and a list of all games and graphics cards visit our Gaming List
