AMD Radeon RX Vega 5

AMD Vega 5

AMD Radeon RX Vega 5是笔记本电脑的集成GPU。 用于2020年初上市的Ryzen 34000 APU。 GPU 基于 Vega 体系结构(第五代 GCN),具有 5 个 CU(= 320 着色器),最高 1400 MHz 时钟。 性能取决于已配置的 TDP(启动时为 12~25W)、时钟、冷却和内存配置。 GPU采用高速双通道DDR4-3200 RAM(与DDR4-2133单通道相反,也可使用)。

Vega 体系结构比 Polaris 生成更高级,现在支持 DirectX 12 功能级别 12_1。 有关 Raven Ridge 体系结构的详细信息,请参见本公司的专稿。

性能必须略低于旧 Radeon RX Vega 6(6CU,但时钟速度较低)。 因此,只有FIFA 20或F1 2019等几款现代游戏才能以最低限度的详细设定运行。

采用7纳米工艺和智能节能功能,功耗相对较低(AMD),显卡也可用于超薄、轻巧的笔记本电脑。

RX Vega 4000/5000 Series
Vega 8 512 @ 2.1 GHz
Vega 7 448 @ 1.8 GHz
Vega 6 384 @ 0.4 - 1.5 GHz
Vega 5 320 @ 1.4 GHz
CodenameVega
ArchitectureVega
Pipelines320 - unified
Core Speed1400 (Boost) MHz
Shared Memoryno
APIDirectX 12_1
Power Consumption15 Watt
technology7 nm
FeaturesTiled Rasterization, Shared Memory (up to Dual-Channel DDR4-2400)
Date of Announcement07.01.2020
CPU in Vega 5GPU Base SpeedGPU Boost / Turbo
AMD Ryzen 3 PRO 4450U4 x 2500 MHz, 15 W? MHz1400 MHz
AMD Ryzen 3 4300U4 x 2700 MHz, 15 W? MHz1400 MHz
min. - max.? MHz1400 MHz

Benchmarks

Performance Rating - 3DMark 11 + Fire Strike + Time Spy
7.9 pt (9%)
Intel HD Graphics (Bay Trail) -88%
...
NVIDIA GeForce 945M -8%
AMD Radeon RX Vega 10 -7%
AMD Radeon RX Vega 8 (Ryzen 2000/3000) -5%
AMD Radeon Pro WX 3200 -3%
AMD Radeon RX Vega 5
AMD Radeon R9 M280X 3%
AMD Radeon RX Vega 9 4%
NVIDIA GeForce GTX 760M 6%
NVIDIA GeForce GTX 1050 Max-Q 9%
...
0%
100%
3DMark - 3DMark Time Spy Score
825 Points (4%)
3DMark - 3DMark Time Spy Graphics
733 Points (3%)
Intel UHD Graphics 605 -85%
...
NVIDIA Quadro M600M -14%
Intel UHD Graphics Xe 750 32EUs (Rocket Lake) -13%
Intel Iris Plus Graphics G4 (Ice Lake 48 EU) -13%
AMD Radeon RX Vega 8 (Ryzen 2000/3000) -8%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) -5%
AMD Radeon RX Vega 10 -1%
AMD Radeon RX Vega 5
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) 2%
Intel UHD Graphics Xe G4 48EUs 2%
AMD Radeon 540X 9%
Intel UHD Graphics 770 (Alder Lake) 9%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 10%
AMD Radeon Pro WX 3100 12%
...
0%
100%
3DMark - 3DMark Ice Storm Unlimited Graphics
128628 Points (17%)
3DMark - 3DMark Ice Storm Extreme Graphics
70871 Points (10%)
3DMark - 3DMark Cloud Gate Score
12224 Points (15%)
3DMark - 3DMark Cloud Gate Graphics
18282 Points (7%)
3DMark - 3DMark Fire Strike Standard Score
min: 2231     avg: 2232     median: 2231.5 (5%)     max: 2232 Points
3DMark - 3DMark Fire Strike Standard Graphics
2438 Points (4%)
3DMark - 3DMark Ice Storm Graphics
100438 Points (13%)
3DMark - 3DMark Night Raid
8978 Points (11%)
3DMark - 3DMark Night Raid Graphics Score
10222 Points (6%)
3DMark 11 - 3DM11 Performance Score
3763 Points (8%)
3DMark 11 - 3DM11 Performance GPU
3535 Points (5%)
...
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) -7%
NVIDIA GeForce 945M -6%
AMD Radeon R9 M375 -6%
NVIDIA GeForce GTX 760M -4%
AMD Radeon RX Vega 8 (Ryzen 2000/3000) -3%
AMD Radeon RX Vega 10 -1%
AMD Radeon RX Vega 5
AMD Radeon R7 M275DX 1%
NVIDIA GeForce GTX 670MX 1%
NVIDIA Quadro K3100M 1%
NVIDIA GeForce GTX 560M SLI 2%
AMD Radeon R9 M370X 3%
AMD Radeon Pro WX 3100 4%
...
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
11704 Points (3%)
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
10234 Points (8%)
ATI Radeon HD 3200 -99%
...
ATI Mobility Radeon HD 4870 X2 -4%
AMD Radeon RX Vega 10 -3%
NVIDIA GeForce GTX 280M SLI -3%
AMD Radeon Pro WX 3100 -1%
AMD Radeon RX Vega 5
AMD Radeon 540X 1%
NVIDIA GeForce GTX 285M SLI 3%
AMD FirePro M5100 3%
AMD Radeon HD 7850M 5%
NVIDIA Quadro M600M 7%
...
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
15564 Points (24%)
Unigine Valley 1.0 - Unigine Valley 1.0 DX
7.3 fps (3%)
Unigine Heaven 3.0 - Unigine Heaven 3.0 DX 11
26.2 fps (9%)
Unigine Heaven 3.0 - Unigine Heaven 3.0 OpenGL
24.6 fps (11%)
Unigine Heaven 2.1 - Heaven 2.1 high
36.2 fps (7%)
...
AMD FirePro W5130M -1%
AMD Radeon RX Vega 5
Intel Iris Plus Graphics G4 (Ice Lake 48 EU) 1%
AMD Radeon RX Vega 6 (Ryzen 4000/5000) 2%
AMD Radeon Pro WX 3100 2%
NVIDIA GeForce GT 755M 4%
AMD FirePro M5100 8%
...
0%
100%
Cinebench R15
Cinebench R15 OpenGL 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL 64 Bit
59.6 fps (16%)
Cinebench R15 OpenGL Ref. Match 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
98 % (98%)
GFXBench (DX / GLBenchmark) 2.7
GFXBench 2.7 T-Rex HD Onscreen C24Z16 +
GFXBench (DX / GLBenchmark) 2.7 - GFXBench 2.7 T-Rex HD Onscreen C24Z16
147.4 fps (4%)
GFXBench T-Rex HD Offscreen C24Z16 +
GFXBench (DX / GLBenchmark) 2.7 - GFXBench T-Rex HD Offscreen C24Z16
164.8 fps (1%)
GFXBench 3.0 - GFXBench 3.0 Manhattan
65.2 fps (18%)
GFXBench 3.0 - GFXBench 3.0 Manhattan Offscreen
67.2 fps (5%)
GFXBench - GFXBench 5.0 Aztec Ruins High Tier Onscreen
34.4 fps (22%)
GFXBench - GFXBench 5.0 Aztec Ruins High Tier Offscreen
21.2 fps (7%)
GFXBench - GFXBench 5.0 Aztec Ruins Normal Tier Onscreen
53.1 fps (26%)
GFXBench - GFXBench 5.0 Aztec Ruins Normal Tier Offscreen
55.7 fps (7%)
GFXBench - GFXBench Car Chase Onscreen
41 fps (1%)
GFXBench - GFXBench Car Chase Offscreen
21.4 fps (0%)
LuxMark v2.0 64Bit - LuxMark v2.0 Room GPU
377 Samples/s (2%)
LuxMark v2.0 64Bit - LuxMark v2.0 Sala GPU
678 Samples/s (1%)
ComputeMark v2.1 - ComputeMark v2.1 Result
2134 points (4%)
Power Consumption - Furmark Stress Test Power Consumption - external Monitor *
42.7 Watt (7%)
Clock Speed - GPU Clock Speed Furmark
1400 MHz (55%)
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

low 1280x720
64.1  fps    + Compare
med. 1920x1080
24  fps    + Compare
high 1920x1080
15.2  fps    + Compare
» With all tested laptops playable in detail settings low.
low 1280x720
32.3  fps    + Compare
med. 1920x1080
12.2  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1280x720
40.6  fps    + Compare
med. 1920x1080
18.5  fps    + Compare
high 1920x1080
15.6  fps    + Compare
» With all tested laptops playable in detail settings low.
low 1280x720
28.8  fps    + Compare
med. 1920x1080
13.2  fps    + Compare
high 1920x1080
8  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
med. 1920x1080
18.3  fps    + Compare
high 1920x1080
14.3  fps    + Compare
ultra 1920x1080
12.3  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1280x720
31.5  fps    + Compare
med. 1920x1080
16.1  fps    + Compare
high 1920x1080
14  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1280x720
28.3  fps    + Compare
med. 1920x1080
17  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
GRID 2019

GRID 2019

2019
low 1280x720
46.7  fps    + Compare
med. 1920x1080
22.2  fps    + Compare
high 1920x1080
13.9  fps    + Compare
» With all tested laptops playable in detail settings low.
low 1280x720
24  fps    + Compare
med. 1920x1080
13  fps    + Compare
high 1920x1080
12  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
FIFA 20

FIFA 20

2019
low 1280x720
92.5  fps    + Compare
med. 1920x1080
66  fps    + Compare
high 1920x1080
58  fps    + Compare
ultra 1920x1080
49.3  fps    + Compare
» With all tested laptops playable in detail settings ultra.
low 1280x720
37.5  fps    + Compare
med. 1920x1080
14.8  fps    + Compare
high 1920x1080
9  fps    + Compare
» With all tested laptops playable in detail settings low.
Additional Benchmarks
Very Low Overall Quality (DX11) 1920x1080
21.8
Control

Control

2019
low 1280x720
31.4  fps    + Compare
med. 1920x1080
9.6  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
F1 2019

F1 2019

2019
low 1280x720
53  fps    + Compare
med. 1920x1080
22  fps    + Compare
high 1920x1080
20  fps    + Compare
ultra 1920x1080
18  fps    + Compare
» With all tested laptops playable in detail settings low.
low 1280x720
43.3  fps    + Compare
med. 1920x1080
12.5  fps    + Compare
high 1920x1080
8  fps    + Compare
» With all tested laptops playable in detail settings low.
Rage 2

Rage 2

2019
low 1280x720
29.6  fps    + Compare
med. 1920x1080
12.8  fps    + Compare
high 1920x1080
10.5  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Anno 1800

Anno 1800

2019
low 1280x720
45.4  fps    + Compare
med. 1920x1080
14.8  fps    + Compare
high 1920x1080
8.5  fps    + Compare
» With all tested laptops playable in detail settings low.
low 1280x720
32  fps    + Compare
