Asus TUF Gaming F15 FX506HM-HN004T

Specifications

Asus TUF Gaming F15 FX506HM-HN004T
Asus TUF Gaming F15 FX506HM-HN004T (TUF Gaming F15 FX506 Series)
Processor
Intel Core i7-11800H 8 x 2.3 - 4.6 GHz, Tiger Lake H45
Graphics adapter
NVIDIA GeForce RTX 3060 Laptop GPU - 6144 MB, Core: 1630 MHz, 95 W TDP + 5 W Dynamic Boost, GDDR6
Memory
16384 MB
, DDR4-3200
Display
15.60 inch 16:9, 1920 x 1080 pixel 141 PPI, IPS, glossy: no, 144 Hz
Mainboard
Intel HM570
Storage
512GB SSD
Connections
3 USB 3.0 / 3.1 Gen1, 1 Thunderbolt, 1 HDMI, Audio Connections: 3.5mm
Networking
10/100/1000 LAN Card (10/100/1000/2500/5000MBit/s), 802.11 a/b/g/n/ac/ax (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/ax = Wi-Fi 6), Bluetooth 5.2
Size
height x width x depth (in mm): 24.5 x 359 x 256
Battery
90 Wh Lithium-Polymer, 4-cell
Operating System
Microsoft Windows 10 Home 64 Bit
Camera
Webcam: HD 720p
Additional features
Speakers: Stereo, Keyboard: Chiclet, Keyboard Light: yes
Weight
2.3 kg
Price
1450 Euro



Pricecompare

Reviews for the Asus TUF Gaming F15 FX506HM-HN004T

ASUS TUF Gaming F15 (FX506, 2021) – capable device with good cooling
Source: Laptop Media English EN→zh-CN
At the end of the day, the ASUS TUF F15 (FX506, 2021) is a good device. Depending on how much money you’re willing to spend on a gaming machine, you can have it as a modest laptop with Core i5-11260H and GeForce RTX 3050 or it could be a decent notebook with Intel Core i9-11900H/Core i7-11800H and an NVIDIA GeForce RTX 3060. As we said earlier, we like the fact that the device design isn’t too intrusive and it doesn’t scream in front of your face “I am a gaming machine”. Maybe you can use it in the park without drawing too much unwanted attention.
Single Review, online available, Very Long, Date: 08/02/2021
ASUS TUF Gaming F15 (FX506, 2021) - disassembly and upgrade options
Source: Laptop Media English
Support, online available, Very Short, Date: 07/23/2021
ASUS TUF F15 Review
Source: Tweakers Dutch NL→zh-CN
Single Review, online available, Medium, Date: 06/16/2021

Comment

NVIDIA GeForce RTX 3060 Laptop GPU:

采用安培GA106芯片的高端笔记本电脑显卡,内核为3072。 TDP从60瓦特到115瓦特不等。



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


i7-11800H:

基于Tiger Lake(H45系列)的高端八核SoC,适用于笔记本电脑和工作站。 8个CPU核心以2.3GHz~4.6GHz的速度运行。 集成UHD显卡GPU可提供32个EU,最高1.45GHz。 此芯片采用第二代 10nm Intel SuperFin 工艺制造。

» Further information can be found in our Comparison of Mobile Processsors.


15.60": 15到16寸是笔记本电脑的标准尺寸,产品型号最为丰富。» To find out how fine a display is, see our DPI List.


2.3 kg: 这是14到16寸的标准笔记本电脑的常见重量。


» Further information can be found in our Notebook Purchase Guide.
