AMD Radeon HD 8730M

AMD Radeon HD 8730M

AMD Radeon HD 8730M（有时也被称为了ATI Mobility Radeon HD 8730）是DirectX 11.1显卡的笔记本电脑。它是基于火星芯片（GCN架构的28nm）384着色器核心，24 TMUs，16个ROPs。核心主频为650 MHz（700 MHz升压）的，可以访问DDR3 VRAM（1000兆赫）。的Radeon HD 8730M的性能应该是在范围内的GeForce GT 630M和Radeon HD 7670M。当前和要求苛刻的游戏，如“孤岛惊魂3流利的中低的分辨率和细节设置。 384着色器可以使用与OpenCL 1.2通用计算的（8计算单位）。老万亿次芯片相比，基于GCN-火星的体系结构提供了更好的性能，在此框架内。特色的8730M包括通过UVD3视频解码进行解码的MPEG-4 AVC/H.264，VC-1，MPEG-2，和Flash直接从AMD GPU。多视图编解码器（MVC）和MPEG-4的第2部分（DIVX，XVID）的高清视频是目前兼容。 8700M系列还支持集成的GPU和独立显卡之间的自动显卡切换。耐力赛，这项技术取代了AMD的动态切换显卡，是类似于NVIDIA的Optimus。另外，8730M可以直接支持2个连接显示器如果耐力赛被禁止使用Eyefinity技术。的8700M系列的其它特征包括ZeroCore为降低功耗，当显示器关闭和电源选通区域中未使用的芯片断电。 PowerTune允许的显卡的GPU自动超频和降频是在其TDP限制。例如，该芯片可以降频运行时的FurMark和OCCT，但会在某些游戏如“失落的星球”，“孤岛危机”，“生化危机5超频。集成的HD音频处理器能够通过HDMI和DisplayPort（例如，蓝光视频）传输高清音频（TrueHD或DTS Master音频）。此外，现在它可以同时并行多个设备的音频输出与新的离散数字多音频（DDMA）功能。应稍低于HD 7670M的功耗。其结果，适合于13英寸的笔记本电脑或更大8730M。

Radeon HD 8700M Series

Radeon HD 8790M 384 @ 0.85 GHz128 Bit @ 4500 MHz
Radeon HD 8770M 384 @ 0.78 GHz128 Bit @ 4500 MHz
Radeon HD 8550G + HD 8750M Dual Graphics 640 @ 0.72 GHz128 Bit @ 1800 MHz
Radeon HD 8750M 384 @ 0.62 - 0.78 GHz128 Bit @ 2000 - 4000 MHz
Radeon HD 8730M 384 @ 0.65 GHz128 Bit @ 2000 MHz
ArchitectureGCN
Pipelines384 - unified
Core Speed650 MHz
Memory Speed2000 MHz
Memory Bus Width128 Bit
Memory TypeDDR3
Max. Amount of Memory2048 MB
Shared Memoryno
APIDirectX 11.1, Shader 5.0
Transistor Count900 Million
technology28 nm
Notebook Sizemedium sized
Date of Announcement16.11.2012

Benchmarks

Performance Rating - 3DMark 11 + Fire Strike + Time Spy
0.5 pt (2%)
AMD Radeon HD 8180
0.06605 -87%
...
NVIDIA GeForce GT 730M
0.4833 -8%
Intel HD Graphics 630
0.4861 -7%
AMD Radeon R7 M260
0.4861 -7%
AMD Radeon R5 M255
0.4922 -6%
AMD Radeon R6 M255DX
0.508 -3%
AMD Radeon R7 (Carrizo)
0.518 -1%
AMD Radeon R7 M360
0.522 0%
NVIDIA GeForce 825M
0.524 0%
NVIDIA GeForce GT 740M
0.524 0%
AMD Radeon HD 8730M
0.524
NVIDIA GeForce GT 645M
0.525 0%
NVIDIA GeForce 920M
0.529 1%
Intel UHD Graphics 620
0.532 2%
AMD Radeon RX Vega 3
0.534 2%
AMD Radeon R7 M460
0.536 2%
Intel UHD Graphics 24EUs (Alder Lake-N)
0.539 3%
AMD Radeon R7 M440
0.546 4%
Intel UHD Graphics Xe 16EUs (Tiger Lake-H)
0.548 5%
AMD Radeon HD 8690M
0.551 5%
...
NVIDIA GeForce RTX 4090 Laptop GPU
21.1 3927%
max:
NVIDIA GeForce RTX 4090
33.3 6255%
0%
100%
3DMark - 3DMark Cloud Gate Score
5206 Points (6%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Graphics
8054 Points (2%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Score
1073 Points (2%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Graphics
1150 Points (1%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Graphics
45267 Points (5%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance Score
min: 1505     avg: 1508     median: 1507.5 (2%)     max: 1510 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance GPU
min: 1368     avg: 1371     median: 1370.5 (1%)     max: 1373 Points
+ 2 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 6250
171.8 -87%
...
AMD Radeon HD 8670M
1286 -6%
Intel HD Graphics 520
1296 -5%
AMD Radeon HD 8550M
1307 -5%
AMD Radeon HD 6770M
1328 -3%
AMD Radeon HD 7690M XT
1346 -2%
NVIDIA GeForce GT 640M LE
1349 -2%
AMD FirePro M5950
1350 -2%
Intel HD Graphics 530
1355 -1%
AMD Radeon HD 8650G
1361 -1%
AMD Radeon HD 8730M
1371
Intel HD Graphics 6000
1372 0%
NVIDIA GeForce 910M
1413 3%
Intel HD Graphics 5600
1431 4%
AMD Radeon R6 (Carrizo)
1452 6%
Intel UHD Graphics (Jasper Lake 24 EU)
1458 6%
AMD Radeon HD 6850M
1470 7%
AMD Radeon HD 7730M
1478 8%
AMD Radeon HD 6720G2
1479 8%
Intel HD Graphics 620
1499 9%
...
AMD Radeon RX 7900M
59943 4272%
max:
NVIDIA GeForce RTX 4090
106023 7633%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
min: 6292     avg: 6311     median: 6310.5 (2%)     max: 6329 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
min: 5859     avg: 5870     median: 5869.5 (3%)     max: 5880 Points
+ 2 benchmarks and specifications   - Hide comparison chart
ATI Radeon HD 3200
62 -99%
...
AMD FirePro M5950
5560 -5%
AMD Radeon HD 8650G + HD 8570M Dual Graphics
5573 -5%
AMD Radeon HD 7690M XT
5594 -5%
AMD Radeon HD 8550G + HD 8670M Dual Graphics
5595 -5%
NVIDIA GeForce GTX 285M
5631 -4%
NVIDIA Quadro K2000M
5698 -3%
Intel Iris Graphics 6100
5717 -3%
NVIDIA GeForce GT 740M
5735 -2%
AMD Radeon HD 7730M
5833 -1%
AMD Radeon HD 8730M
5870
ATI FirePro M7740
5896 0%
NVIDIA Quadro FX 3800M
5926 1%
Intel UHD Graphics 620
5948 1%
NVIDIA GeForce 830M
5957 1%
AMD Radeon HD 8550G + HD 8750M Dual Graphics
5961 2%
AMD Radeon R7 M265
5977 2%
NVIDIA GeForce GT 730M
5987 2%
NVIDIA GeForce 8800M GTX SLI
5995 2%
AMD Radeon R7 M445
6000 2%
...
NVIDIA GeForce RTX 4090 Laptop GPU
132443 2156%
max:
AMD Radeon RX 7900 XTX
170928 2812%
0%
100%
3DMark 03 - 3DMark 03 - Standard
19016 Points (10%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 05 - 3DMark 05 - Standard
12762 Points (14%)
+ 1 benchmarks and specifications   - Hide comparison chart
Intel Graphics Media Accelerator (GMA) 500
133.4 -99%
...
ATI Mobility Radeon HD 5650
12418 -3%
AMD Radeon HD 8650G
12469 -2%
AMD Radeon HD 7610M
12505 -2%
Intel UHD Graphics (Jasper Lake 16 EU)
12573 -1%
Intel HD Graphics 620
12578 -1%
NVIDIA GeForce GT 330M
12591 -1%
ATI Mobility Radeon HD 4650
12609 -1%
ATI Mobility Radeon HD 4670
12614 -1%
AMD Radeon HD 6630M
12640 -1%
AMD Radeon HD 8730M
12762
ATI Mobility Radeon HD 3870
12885 1%
NVIDIA GeForce 8600M GT SLI
12932 1%
NVIDIA GeForce GT 425M
12975 2%
NVIDIA Quadro NVS 5100M
13125 3%
NVIDIA GeForce 9700M GTS
13125 3%
NVIDIA Quadro FX 880M
13217 4%
ATI Mobility Radeon HD 5165
13284 4%
NVIDIA GeForce GT 525M
13307 4%
NVIDIA GeForce 830M
13441 5%
...
NVIDIA GeForce RTX 4090 Laptop GPU
61850 385%
max:
NVIDIA GeForce RTX 4080 Super
87172 583%
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
min: 8604     avg: 8620     median: 8620 (11%)     max: 8636 Points
+ 2 benchmarks and specifications   + Show comparison chart
Unigine Heaven 3.0 - Unigine Heaven 3.0 DX 11
15.7 fps (5%)
+ 2 benchmarks and specifications   + Show comparison chart
Unigine Heaven 2.1 - Heaven 2.1 high
min: 21.1     avg: 21.2     median: 21.2 (4%)     max: 21.3 fps
+ 2 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 7310
0.6 -97%
...
AMD Radeon HD 6755G2
18.8 -11%
Intel HD Graphics 6000
19.03 -10%
NVIDIA GeForce GT 740M
19.4 -8%
AMD Radeon R7 (Bristol Ridge)
19.5 -8%
AMD Radeon R7 M340
19.8 -7%
AMD Radeon 530
19.95 -6%
AMD Radeon R8 M445DX
20.3 -4%
AMD Radeon HD 7520G + HD 7670M Dual Graphics
20.4 -4%
NVIDIA GeForce GT 730M
20.93 -1%
AMD Radeon HD 8730M
21.2
AMD Radeon RX Vega 3
21.2 0%
AMD Radeon HD 8750M
22 4%
NVIDIA GeForce 920M
22.1 4%
Intel Iris Xe Graphics G7 96EUs
23.1 9%
NVIDIA GeForce GT 645M
23.35 10%
NVIDIA Quadro K1100M
23.4 10%
NVIDIA GeForce GT 640M
23.87 13%
ATI Mobility Radeon HD 5870
24 13%
NVIDIA Quadro K2000M
24 13%
...
NVIDIA Quadro RTX 5000 (Laptop)
532 2409%
0%
100%
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 31.8     avg: 32.3     median: 32.3 (11%)     max: 32.7 fps
+ 2 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Far Cry 3

Far Cry 3

2012
low 1024x768
48  fps    + Compare
med. 1366x768
37.2  fps    + Compare
high 1366x768
18  fps    + Compare
ultra 1920x1080
5.7  fps    + Compare
» With all tested laptops playable in detail settings med..
Assassin´s Creed III

Assassin´s Creed III

2012
med. 1366x768
18.1  fps    + Compare
high 1366x768
16.8  fps    + Compare
ultra 1920x1080
6.8  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Hitman: Absolution

Hitman: Absolution

2012
low 1024x768
15  fps    + Compare
med. 1366x768
14  fps    + Compare
high 1366x768
12  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Call of Duty: Black Ops 2

Call of Duty: Black Ops 2

2012
low 1024x768
72  fps    + Compare
med. 1366x768
47.8  fps    + Compare
high 1366x768
25  fps    + Compare
ultra 1920x1080
17.8  fps    + Compare
» With all tested laptops playable in detail settings med..
Need for Speed: Most Wanted

Need for Speed: Most Wanted

2012
low 1024x768
38.9  fps    + Compare
med. 1366x768
34.4  fps    + Compare
high 1366x768
21.8  fps    + Compare
ultra 1920x1080
13.9  fps    + Compare
» With all tested laptops playable in detail settings low.
Medal of Honor: Warfighter

Medal of Honor: Warfighter

2012
low 1024x768
54  fps    + Compare
med. 1366x768
33  fps    + Compare
high 1366x768
26  fps    + Compare
» With all tested laptops playable in detail settings low.
Dishonored

Dishonored

2012
low 1024x768
69.2  fps    + Compare
med. 1366x768
55.1  fps    + Compare
high 1366x768
49.6  fps    + Compare
ultra 1920x1080
27  fps    + Compare
» With all tested laptops playable in detail settings high.
Fifa 13

Fifa 13

2012
low 1024x768
225  fps    + Compare
med. 1366x768
154  fps    + Compare
high 1366x768
128  fps    + Compare
» With all tested laptops playable in detail settings high.
F1 2012

F1 2012

2012
low 1024x768
32  fps    + Compare
med. 1366x768
29  fps    + Compare
high 1366x768
25  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Borderlands 2

Borderlands 2

2012
low 1024x768
51.6  fps    + Compare
med. 1366x768
40.4  fps    + Compare
high 1366x768
30.5  fps    + Compare
ultra 1920x1080
17.3  fps    + Compare
» With all tested laptops playable in detail settings med..
Guild Wars 2

Guild Wars 2

2012
low 1024x768
51.1  fps    + Compare
high 1366x768
22.3  fps    + Compare
ultra 1920x1080
9.6  fps    + Compare
» With all tested laptops playable in detail settings low.
Counter-Strike: GO

Counter-Strike: GO

2012
low 1024x768
142.4  fps    + Compare
med. 1366x768
105.2  fps    + Compare
high 1366x768
83.4  fps    + Compare
ultra 1920x1080
48.8  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Darksiders II

Darksiders II

2012
med. 1366x768
48.9  fps    + Compare
ultra 1920x1080
27.8  fps    + Compare
» With all tested laptops playable in detail settings med..
Sleeping Dogs

Sleeping Dogs

2012
low 1024x768
49  fps    + Compare
med. 1366x768
28  fps    + Compare
high 1366x768
22  fps    + Compare
» With all tested laptops playable in detail settings low.
Max Payne 3

Max Payne 3

2012
low 1024x768
37  fps    + Compare
med. 1366x768
35  fps    + Compare
» With all tested laptops playable in detail settings low.
Dirt Showdown

Dirt Showdown

2012
low 1024x768
55.2  fps    + Compare
med. 1366x768
37.5  fps    + Compare
high 1366x768
33  fps    + Compare
ultra 1920x1080
14.8  fps    + Compare
» With all tested laptops playable in detail settings med..
Diablo III

Diablo III

2012
low 1024x768
78  fps    + Compare
med. 1366x768
56  fps    + Compare
high 1366x768
51  fps    + Compare
» With all tested laptops playable in detail settings high.
Risen 2: Dark Waters

Risen 2: Dark Waters

2012
low 1024x768
48  fps    + Compare
med. 1366x768
38  fps    + Compare
high 1366x768
22  fps    + Compare
» With all tested laptops playable in detail settings med..
Mass Effect 3

Mass Effect 3

2012
low 1280x720
57  fps    + Compare
high 1366x768
44  fps    + Compare
» With all tested laptops playable in detail settings high.
Alan Wake

Alan Wake

2012
low 1024x768
37  fps    + Compare
med. 1366x768
24.3  fps    + Compare
ultra 1920x1080
11.4  fps    + Compare
» With all tested laptops playable in detail settings low.
Anno 2070

Anno 2070

2011
low 1024x768
79  fps    + Compare
med. 1366x768
46  fps    + Compare
high 1366x768
29  fps    + Compare
» With all tested laptops playable in detail settings med..
The Elder Scrolls V: Skyrim

The Elder Scrolls V: Skyrim

2011
low 1280x720
58  fps    + Compare
med. 1366x768
44  fps    + Compare
high 1366x768
30  fps    + Compare
» With all tested laptops playable in detail settings med..
CoD: Modern Warfare 3

CoD: Modern Warfare 3

2011
low 1024x768
112.9  fps    + Compare
med. 1366x768
74.4  fps    + Compare
high 1366x768
45.7  fps    + Compare
ultra 1920x1080
25.7  fps    + Compare
» With all tested laptops playable in detail settings high.
Battlefield 3

Battlefield 3

2011
low 1024x768
38  fps    + Compare
med. 1366x768
32  fps    + Compare
high 1366x768
27  fps    + Compare
» With all tested laptops playable in detail settings low.
Deus Ex Human Revolution

Deus Ex Human Revolution

2011
low 1024x768
101  fps    + Compare
high 1366x768
47  fps    + Compare
» With all tested laptops playable in detail settings high.
Total War: Shogun 2

Total War: Shogun 2

2011
low 1024x768
125  fps    + Compare
med. 1280x720
33  fps    + Compare
» With all tested laptops playable in detail settings low.
Additional Benchmarks
CPU 1280x1024
14
Mafia 2

Mafia 2

2010
low 800x600
64  fps    + Compare
med. 1024x768
47  fps    + Compare
high 1360x768
38  fps    + Compare
» With all tested laptops playable in detail settings high.
StarCraft 2

StarCraft 2

2010
low 1024x768
94  fps    + Compare
med. 1360x768
27  fps    + Compare
high 1360x768
20  fps    + Compare
» With all tested laptops playable in detail settings low.
Metro 2033

Metro 2033

2010
low 800x600
72  fps    + Compare
med. 1360x768
41  fps    + Compare
high 1600x900
22  fps    + Compare
» With all tested laptops playable in detail settings med..
Battlefield: Bad Company 2

Battlefield: Bad Company 2

2010
low 1024x768
71  fps    + Compare
med. 1366x768
58  fps    + Compare
high 1366x768
42  fps    + Compare
» With all tested laptops playable in detail settings high.
Crysis - GPU Benchmark

Crysis - GPU Benchmark

2007
low 1024x768
35  fps    + Compare
med. 1024x768
31  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Additional Benchmarks
Low 0xAF 0xAA 800x600
46
Crysis - CPU Benchmark

Crysis - CPU Benchmark

2007
low 1024x768
31  fps    + Compare
med. 1024x768
27  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Additional Benchmarks
Low 0xAF 0xAA 800x600
53
lowmed.highultraQHD4K
Far Cry 34837.2185.7
Assassin´s Creed III18.116.86.8
Hitman: Absolution151412
Call of Duty: Black Ops 27247.82517.8
Need for Speed: Most Wanted38.934.421.813.9
Medal of Honor: Warfighter543326
Dishonored69.255.149.627
Fifa 13225154128
F1 2012322925
Borderlands 251.640.430.517.3
Guild Wars 251.122.39.6
Counter-Strike: GO142.4105.283.448.8
Darksiders II48.927.8
Sleeping Dogs492822
Max Payne 33735
Dirt Showdown55.237.53314.8
Diablo III785651
Risen 2: Dark Waters483822
Mass Effect 35744
Alan Wake3724.311.4
Anno 2070794629
The Elder Scrolls V: Skyrim584430
CoD: Modern Warfare 3112.974.445.725.7
Battlefield 3383227
Deus Ex Human Revolution10147
Total War: Shogun 212533
Mafia 2644738
StarCraft 2942720
Metro 2033724122
Battlefield: Bad Company 2715842
Crysis - GPU Benchmark3531
Crysis - CPU Benchmark3127
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps		1
16
10
3		7
19
2
1		14
10
1
1		11
1







For more games that might be playable and a list of all games and graphics cards visit our Gaming List

v1.26
log 05. 15:41:04

#0 no ids found in url (should be separated by "_") +0s ... 0s

#1 not redirecting to Ajax server +0s ... 0s

#2 did not recreate cache, as it is less than 5 days old! Created at Sat, 04 May 2024 05:42:18 +0200 +0.001s ... 0.001s

#3 no comparison url found in template nbc.compare_page_1 needed +0.05s ... 0.051s

#4 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.052s

#5 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.052s

#6 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.052s

#7 composed specs +0s ... 0.052s

#8 did output specs +0s ... 0.052s

#9 start showIntegratedCPUs +0s ... 0.052s

#10 getting avg benchmarks for device 3729 +0.03s ... 0.082s

#11 got single benchmarks 3729 +0.011s ... 0.093s

#12 got avg benchmarks for devices +0s ... 0.093s

#13 min, max, avg, median took s +0.375s ... 0.467s

#14 before gaming benchmark output +0s ... 0.467s

#15 Got 97 rows for game benchmarks. +0.008s ... 0.475s

#16 composed SQL query for gamebenchmarks +0s ... 0.475s

#17 got data and put it in $dataArray +0.023s ... 0.498s

#18 benchmarks composed for output. +0.963s ... 1.461s

#19 no comparison url found in template nbc.compare_page_1 needed +0.003s ... 1.464s

#20 return log +0s ... 1.464s

Please share our article, every link counts!

» Comparison of GPUs
Detailed list of all laptop GPUs sorted by class and performance.

» Benchmark List
Sort and restrict laptop GPUs based on performance in synthetic benchmarks.

» Notebook Gaming List
Playable games for each graphics card and their average FPS results.

Class 1

NVIDIA GeForce RTX 4090 Laptop GPU
NVIDIA RTX 5000 Ada Generation Laptop GPU
Radeon RX 7900M
NVIDIA GeForce RTX 4080 Laptop GPU
NVIDIA RTX 4000 Ada Generation Laptop GPU
NVIDIA RTX 3500 Ada Generation Laptop GPU
GeForce RTX 3080 Ti Laptop GPU
NVIDIA GeForce RTX 4070 Laptop GPU
NVIDIA RTX 3000 Ada Generation Laptop GPU
RTX A5500 Laptop GPU
GeForce RTX 3080 Laptop GPU
Radeon RX 6850M XT
GeForce RTX 3070 Ti Laptop GPU
RTX A4500 Laptop GPU
RTX A5000 Laptop GPU
NVIDIA GeForce RTX 4060 Laptop GPU
NVIDIA RTX 2000 Ada Generation Laptop GPU
Quadro RTX 6000 (Laptop)
Radeon RX 6800M
GeForce RTX 2080 Super Mobile
GeForce RTX 3070 Laptop GPU
RTX A4000 Laptop GPU *

Class 2

Radeon RX 6800S
Radeon RX 7600M XT *
Radeon RX 7700S *
M3 Max 40-Core GPU *
M2 Max 38-Core GPU *
GeForce RTX 2080 Mobile
Radeon RX 6700M
M3 Max 30-Core GPU *
Quadro RTX 5000 (Laptop)
Radeon RX 7600M *
M2 Max 30-Core GPU *
GeForce RTX 3060 Laptop GPU
M1 Max 32-Core GPU *
Radeon RX 7600S
GeForce RTX 2070 Super Mobile
GeForce RTX 2080 Super Max-Q
RTX A3000 Laptop GPU
M1 Max 24-Core GPU *
A770M *
Radeon RX 6650M XT *
M3 Pro 18-Core GPU *
M2 Pro 19-Core GPU *
Radeon RX 6650M
Radeon RX 6600M
Radeon RX 6700S
GeForce RTX 2070 Mobile
Quadro RTX 5000 Max-Q
GeForce RTX 2080 Max-Q
Radeon RX 5700M *
GeForce GTX 1080 Mobile
Quadro RTX 4000 (Laptop)
M3 Pro 14-Core GPU *
M2 Pro 16-Core GPU *
M1 Pro 16-Core GPU *
Radeon PRO W6600M *
GeForce RTX 2070 Super Max-Q
Quadro RTX 4000 Max-Q *
M1 Pro 14-Core GPU *
GeForce RTX 2070 Max-Q *
Radeon RX 6600S *
Quadro P5200
Quadro RTX 3000 (Laptop) *
GeForce RTX 2060 Mobile
Quadro RTX 3000 Max-Q *
GeForce GTX 1080 Max-Q
GeForce GTX 1070 Mobile
GeForce RTX 2060 Max-Q *
Quadro P4200
NVIDIA GeForce RTX 4050 Laptop GPU
Nvidia RTX 1000 Ada Generation Laptop GPU
RTX A2000 Laptop GPU
A730M *
Radeon Pro 5600M *
Radeon RX 5600M
Quadro P5000
GeForce GTX 1660 Ti Mobile
GeForce RTX 3050 Ti Laptop GPU
GeForce RTX 3050 6GB Laptop GPU
A570M *
RTX A1000 Laptop GPU
GeForce GTX 1070 Max-Q
A550M *
Quadro P5000 Max-Q *
GeForce RTX 3050 4GB Laptop GPU
Nvidia RTX 500 Ada Generation Laptop GPU
A530M *
GeForce GTX 1660 Ti Max-Q
RTX A500 Laptop GPU
Radeon RX 6550M *
Radeon RX 6500M
Radeon RX 6550S *
GeForce GTX 980 (Laptop)
Quadro M5500
Quadro P4000
Quadro T2000 (Laptop) *
GeForce GTX 1060 Mobile
GeForce GTX 1650 Ti Mobile
A370M *
Radeon RX 5500M
Radeon Pro 5500M *
Quadro P4000 Max-Q
Quadro P3200
Radeon RX 580X (Laptop) *
Radeon RX 580 (Laptop)
Radeon RX 6450M *
GeForce RTX 2050 Mobile
GeForce MX570 *
Radeon RX 6300M *
GeForce GTX 1650 Mobile
Radeon Pro 5300M
Radeon RX 5300M
Quadro P3000
GeForce GTX 1060 Max-Q
Quadro P3000 Max-Q *
GeForce GTX 1650 Ti Max-Q *
Quadro T2000 Max-Q *
Radeon Pro WX 7100 *
Radeon RX 570X (Laptop) *
Radeon RX 570 (Laptop) *
Radeon RX 470 (Laptop) *
GeForce GTX 1650 Max-Q *
T1200 Laptop GPU *
Quadro T1000 (Laptop) *
Quadro T1000 Max-Q *
A310 *
Arc 8-Cores *
A350M *
Arc 7-Cores *
T600 Laptop GPU *
T550 Laptop GPU *

Class 3

GeForce GTX 980M
Vega M GH
Quadro M5000M
Radeon Pro Vega 20
Radeon 780M *
GeForce MX550
GeForce GTX 1050 Ti Mobile
Radeon 680M
Quadro P2000
Quadro P2000 Max-Q
Quadro M4000M
GeForce GTX 970M
T500 Laptop GPU *
GeForce MX450 *
Radeon R9 M395X
GeForce GTX 1050 Ti Max-Q *
Radeon Pro Vega 16
Vega M GL / 870
WX Vega M GL
Radeon R9 M485X
Quadro M3000M
GeForce GTX 1050 Mobile
FirePro W7170M
Radeon R9 M395
GeForce GTX 1050 Max-Q *
Radeon 760M *
Radeon Radeon Steam Deck 8CU
Radeon 660M
Radeon Pro WX 4150 *
GeForce GTX 965M
Radeon RX 560X (Laptop)
Radeon RX 560 (Laptop)
Quadro M2200
Radeon RX 460 (Laptop)
Quadro P1000
Radeon R9 M390
Xe MAX
Radeon Pro 560X
Radeon Pro 560
Radeon Pro 460
Radeon Pro WX 4130 *
Iris Xe G7 96EUs
GeForce MX350
GeForce GTX 960M
Quadro M1200
Quadro P620 *
Radeon RX 550X (Laptop)
Radeon RX 550 (Laptop)
Radeon RX 640
Radeon Pro WX 3200 *
Radeon Pro 555X
Radeon Pro 555
Radeon Pro 455
Quadro P600
GeForce MX250
GeForce MX330
GeForce MX150
Iris Xe G7 80EUs
Graphics 4-Core *
Quadro M2000M
Radeon RX 540X *
Radeon Pro WX 2100 *
Radeon RX 540 *
Radeon Pro WX 3100 *
GeForce GTX 950M
Radeon Pro 450
Radeon 630
Radeon 540X *
Radeon R9 M470X *
Radeon R9 M385X
Quadro P520
Quadro M1000M
Quadro M620 *
GeForce 945M
Quadro P500 *
UHD Graphics 64EUs
Iris Plus Graphics G7 (Ice Lake 64 EU) *
Vega 10 *
Iris Pro Graphics P580
Iris Pro Graphics 580
Radeon R9 M470 *
FirePro W5170M *
Radeon R9 M370X
Vega 9
FirePro W5130M
UHD Graphics Xe G4 48EUs *
UHD Graphics 32EUs
UHD Graphics Xe 32EUs (Tiger Lake-H) *
UHD Graphics 750
Radeon 740M *
GeForce MX230
Vega 8 *
Vega 7
Radeon R7 M465
Iris Pro Graphics 6200
GeForce MX130
GeForce 940MX
Quadro M520
Vega 8
GeForce 940M
Iris Plus Graphics G4 (Ice Lake 48 EU)
GeForce 930MX
Quadro M600M
FirePro W4190M
Radeon R9 M375
Iris Plus Graphics 655
Radeon R7 M445
Quadro M500M
Iris Plus Graphics 650
GeForce 930M
Iris Graphics 550
Radeon 530
Radeon 625
Vega 6 *
Iris Plus Graphics 645
GeForce MX110 *
Iris Plus Graphics 640
GeForce 920MX
Iris Graphics 540
UHD Graphics 24EUs (Alder Lake-N) *
Radeon R7 (Bristol Ridge) *
Radeon R7 M460 *
Radeon R7 M360
GeForce 920M
Radeon R8 M445DX
Radeon 620
Radeon R7 M440
Radeon R7 M340
Radeon 520
Radeon 610
Radeon Graphics (Ryzen 7000)
Radeon 610M *
Vega 6 *
Vega 5 *
UHD Graphics G1 (Ice Lake 32 EU)
UHD Graphics Xe 16EUs (Tiger Lake-H) *
UHD Graphics G7 (Lakefield GT2 64 EU)
HD Graphics 530
Radeon R5 (Bristol Ridge)
UHD Graphics 620
HD Graphics 620
Adreno 690 *
Adreno 685 *
Adreno 680 *
Radeon HD 8730M
Radeon R5 M330
Radeon R5 M430
Vega 3 *
GeForce 910M
HD Graphics 520
Iris Graphics 6100
UHD Graphics G4 (Lakefield GT1 48 EU) *

Class 4

UHD Graphics 730
Radeon R5 M320 *
Radeon R5 M315 *
Radeon R5 M420 *
Vega 2 *
Radeon R5 (Stoney Ridge)
HD Graphics 6000
UHD Graphics (Jasper Lake 32 EU) *
UHD Graphics 617
UHD Graphics 615
UHD Graphics (Jasper Lake 24 EU) *
HD Graphics 615
HD Graphics 515
UHD Graphics 610
HD Graphics 610
HD Graphics 510
UHD Graphics (Jasper Lake 16 EU)
UHD Graphics 605
HD Graphics 505
HD Graphics 5300
Radeon R4 (Stoney Ridge)
Radeon R5 (Beema/Carrizo-L)
Radeon R4 (Beema)
Radeon R3 (Mullins/Beema)
Radeon R2 (Stoney Ridge)
HD Graphics (Broadwell)
UHD Graphics 600
HD Graphics 500
HD Graphics 405 (Braswell)
HD Graphics (Braswell)
HD Graphics 400 (Braswell)

Class 5

Radeon R2 (Mullins/Beema/Carrizo-L)
Radeon R6 (Mullins)

* Approximate position of the graphics adapter
