AMD Radeon HD 7420G

AMD的Radeon HD7420G或HD7420G是三位一体从AMD的APU（A4-4300M）处理器的图形卡。这，减少着色器计数/时钟速度是低范围的版本将被刊登在了A4系列。应根据VLIW4架构的Radeon HD 6900系列桌面显卡和最有可能不会提供一个专门的图形存储器。三位一体得名由于这样的事实，它由三个不同的体系结构零件。 CPU内核的基础上的打桩机架构的（推土机继任者），北方群岛GPU核心（HD 6900系列计算机）和视频处理引擎和多显示器连接新南群岛（HD 7900系列GPU架构的GPU核心） 。集成UVD3视频解码器（的Avivo HD）允许多视图编解码器（MVC）的全解码，MPEG-4第2部分（DIVX，XVID），MPEG-4 AVC/H.264高清视频和Adobe Flash。的表现应该在的范围内的Llano基于HD6620G。 APU还在生产32nm和最A4系列零件应归入一个35瓦的TDP，HD7420G13-14英寸向上的笔记本电脑最适合。

Radeon HD 7000G Series

Radeon HD 7660G 384 @ 0.5 - 0.69 GHz
Radeon HD 7620G 384 @ 0.36 - 0.5 GHz
Radeon HD 7640G 256 @ 0.5 - 0.69 GHz
Radeon HD 7600G 384 @ 0.32 - 0.42 GHz
Radeon HD 7500G 256 @ 0.33 - 0.42 GHz
Radeon HD 7520G 192 @ 0.5 - 0.69 GHz
Radeon HD 7420G 128 @ 0.48 - 0.66 GHz
Radeon HD 7400G 192 @ 0.33 - 0.42 GHz
CodenameTrinity
ArchitectureTerascale 3
Pipelines128 - unified
Core Speed480 - 655 (Boost) MHz
Shared Memoryyes
APIDirectX 11, Shader 5.0, OpenGL 4.2
technology32 nm
Notebook Sizemedium sized
Date of Announcement01.06.2012
CPU in Radeon HD 7420GGPU Base SpeedGPU Boost / Turbo
AMD A4-4300M2 x 2500 MHz, 35 W480 MHz655 MHz

Benchmarks

Performance Rating - 3DMark 11 + Fire Strike + Time Spy
0.2 pt (0%)
AMD Radeon HD 8180
0.06605 -58%
...
AMD Radeon HD 8210
0.1034 -34%
AMD Radeon HD 8250
0.1155 -26%
Intel HD Graphics 405 (Braswell)
0.1159 -26%
Intel HD Graphics (Braswell)
0.1189 -24%
Intel HD Graphics (Ivy Bridge)
0.1301 -17%
AMD Radeon HD 8240
0.1332 -15%
Intel HD Graphics 2500
0.1449 -7%
AMD Radeon HD 7400G
0.149 -5%
AMD Radeon HD 8280
0.1494 -4%
AMD Radeon HD 7420G
0.1562
AMD Radeon HD 8330
0.1599 2%
Intel HD Graphics (Haswell)
0.1651 6%
Intel HD Graphics 500
0.1651 6%
AMD Radeon R2 (Mullins/Beema/Carrizo-L)
0.1699 9%
AMD Radeon HD 8350G
0.1767 13%
AMD Radeon HD 8400
0.1827 17%
Intel HD Graphics 505
0.1859 19%
AMD Radeon R3 (Mullins/Beema)
0.1911 22%
Intel HD Graphics 4200
0.1966 26%
...
NVIDIA GeForce RTX 4090 Laptop GPU
21.1 13408%
max:
NVIDIA GeForce RTX 4090
33.3 21219%
0%
100%
3DMark - 3DMark Cloud Gate Score
1963 Points (2%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Graphics
2717 Points (1%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Score
332 Points (1%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Graphics
343 Points (0%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Graphics
32636 Points (4%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance Score
501 Points (1%)
+ 2 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance GPU
453 Points (0%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 6250
171.8 -62%
...
AMD Radeon HD 8210
344.5 -24%
Intel HD Graphics 2500
349 -23%
NVIDIA GeForce GT 415M
379 -16%
Intel HD Graphics (Braswell)
389.9 -14%
AMD Radeon HD 7400G
415 -8%
NVIDIA GeForce 410M
415.3 -8%
AMD Radeon HD 8250
422.5 -7%
AMD Radeon HD 8240
427.5 -6%
AMD Radeon HD 6450M
443 -2%
AMD Radeon HD 7420G
453
AMD Radeon HD 6480G
467 3%
Intel HD Graphics 405 (Braswell)
469.1 4%
AMD Radeon R2 (Mullins/Beema/Carrizo-L)
471.7 4%
Intel HD Graphics 500
478.6 6%
Intel HD Graphics (Haswell)
479.6 6%
AMD Radeon HD 6520G
492 9%
AMD Radeon HD 8280
496 9%
NVIDIA GeForce GT 520M
499.8 10%
NVIDIA GeForce 610M
513 13%
...
AMD Radeon RX 7900M
59943 13132%
max:
NVIDIA GeForce RTX 4090
106023 23305%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
1718 Points (0%)
+ 2 benchmarks and specifications   + Show comparison chart
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
1484 Points (1%)
+ 1 benchmarks and specifications   - Hide comparison chart
ATI Radeon HD 3200
62 -96%
...
NVIDIA GeForce 9600M GT
1192 -20%
AMD Radeon HD 8240
1247 -16%
AMD Radeon HD 6480G
1282 -14%
AMD Radeon HD 6520G
1295 -13%
Intel HD Graphics (Braswell)
1328 -11%
Intel HD Graphics 3000
1331 -10%
Intel HD Graphics 2500
1369 -8%
NVIDIA GeForce GT 130M
1379 -7%
AMD Radeon HD 7600G
1380 -7%
AMD Radeon HD 7420G
1484
NVIDIA GeForce 9650M GS
1486 0%
AMD Radeon HD 6470M
1504 1%
NVIDIA GeForce 410M
1507 2%
AMD Radeon R3 (Mullins/Beema)
1512 2%
AMD Radeon HD 8330
1513 2%
AMD Radeon HD 7470M
1516 2%
NVIDIA GeForce 9700M GT
1535 3%
AMD Radeon HD 6620G
1535 3%
NVIDIA GeForce 320M
1543 4%
...
NVIDIA GeForce RTX 4090 Laptop GPU
132443 8825%
max:
AMD Radeon RX 7900 XTX
170928 11418%
0%
100%
3DMark 03 - 3DMark 03 - Standard
10934 Points (6%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
min: 3476     avg: 3751     median: 3751 (5%)     max: 4026 Points
+ 2 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Gaming graphics
6 Points (76%)
+ 1 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Graphics
4.9 Points (62%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
min: 3769     avg: 4220     median: 4220 (3%)     max: 4671 points
+ 2 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 13.35     avg: 13.9     median: 13.9 (5%)     max: 14.45 fps
+ 2 benchmarks and specifications   + Show comparison chart
Cinebench R15
Cinebench R15 OpenGL 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL 64 Bit
13.1 fps (1%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R15 OpenGL Ref. Match 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
98 % (98%)
+ 1 benchmarks and specifications   + Show comparison chart
LuxMark v2.0 64Bit - LuxMark v2.0 Room GPU
35 Samples/s (0%)
+ 1 benchmarks and specifications   + Show comparison chart
LuxMark v2.0 64Bit - LuxMark v2.0 Sala GPU
67 Samples/s (0%)
+ 1 benchmarks and specifications   + Show comparison chart
ComputeMark v2.1 - ComputeMark v2.1 Result
332 points (0%)
+ 1 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Dirt 4

Dirt 4

2017
low 1280x720
15.5  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Farming Simulator 17

Farming Simulator 17

2016
low 1280x720
42.4  fps    + Compare
med. 1366x768
26.6  fps    + Compare
» With all tested laptops playable in detail settings low.
World of Warships

World of Warships

2015
low 1366x768
26.1  fps    + Compare
med. 1366x768
18  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Metal Gear Solid V

Metal Gear Solid V

2015
low 1024x768
23.3  fps    + Compare
med. 1366x768
18.3  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Dota 2 Reborn

Dota 2 Reborn

2015
low 1280x720
33.8  fps    + Compare
med. 1366x768
17.3  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Dirt Rally

Dirt Rally

2015
low 1024x768
38.6  fps    + Compare
med. 1366x768
14.6  fps    + Compare
» With all tested laptops playable in detail settings low.
Battlefield Hardline

Battlefield Hardline

2015
low 1024x768
9.5  fps    + Compare
med. 1366x768
8.6  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Sims 4

Sims 4

2014
low 1024x768
88.7  fps    + Compare
med. 1366x768
19.7  fps    + Compare
» With all tested laptops playable in detail settings low.
F1 2013

F1 2013

2013
low 1024x768
18  fps    + Compare
med. 1366x768
15  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Total War: Rome II

Total War: Rome II

2013
low 1024x768
23.3  fps    + Compare
med. 1366x768
16.6  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Saints Row IV

Saints Row IV

2013
low 1280x720
11.7  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Company of Heroes 2

Company of Heroes 2

2013
low 1024x768
8.2  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
GRID 2

GRID 2

2013
low 1024x768
28.9  fps    + Compare
med. 1366x768
17.2  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Metro: Last Light

Metro: Last Light

2013
low 1024x768
10.3  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
BioShock Infinite

BioShock Infinite

2013
low 1280x720
26.1  fps    + Compare
med. 1366x768
13  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
StarCraft II: Heart of the Swarm

StarCraft II: Heart of the Swarm

2013
low 1024x768
91.5  fps    + Compare
med. 1366x768
28.2  fps    + Compare
high 1366x768
14.9  fps    + Compare
» With all tested laptops playable in detail settings low.
Tomb Raider

Tomb Raider

2013
low 1024x768
28.7  fps    + Compare
med. 1366x768
14.9  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Dead Space 3

Dead Space 3

2013
low 1024x768
49.6  fps    + Compare
med. 1366x768
18.4  fps    + Compare
» With all tested laptops playable in detail settings low.
Far Cry 3

Far Cry 3

2012
low 1024x768
14  fps    + Compare
med. 1366x768
11  fps    + Compare
high 1366x768
10  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Assassin´s Creed III

Assassin´s Creed III

2012
med. 1366x768
10  fps    + Compare
high 1366x768
8.5  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Hitman: Absolution

Hitman: Absolution

2012
low 1024x768
12  fps    + Compare
med. 1366x768
10  fps    + Compare
high 1366x768
4  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Medal of Honor: Warfighter

Medal of Honor: Warfighter

2012
low 1024x768
14  fps    + Compare
med. 1366x768
12  fps    + Compare
high 1366x768
9  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Fifa 13

Fifa 13

2012
low 1024x768
82  fps    + Compare
med. 1366x768
54  fps    + Compare
high 1366x768
34  fps    + Compare
» With all tested laptops playable in detail settings med..
F1 2012

F1 2012

2012
low 1024x768
19  fps    + Compare
med. 1366x768
18  fps    + Compare
high 1366x768
15  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Borderlands 2

Borderlands 2

2012
low 1024x768
24  fps    + Compare
med. 1366x768
18  fps    + Compare
high 1366x768
11  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Counter-Strike: GO

Counter-Strike: GO

2012
low 1024x768
52  fps    + Compare
med. 1366x768
39  fps    + Compare
high 1366x768
31  fps    + Compare
» With all tested laptops playable in detail settings med..
Darksiders II

Darksiders II

2012
med. 1366x768
22  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Sleeping Dogs

Sleeping Dogs

2012
low 1024x768
11  fps    + Compare
med. 1366x768
6  fps    + Compare
high 1366x768
3  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Max Payne 3

Max Payne 3

2012
low 1024x768
12  fps    + Compare
med. 1366x768
11  fps    + Compare
high 1366x768
8  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Diablo III

Diablo III

2012
low 1024x768
39.7 42 ~ 41 fps    + Compare
med. 1366x768
24 26.4 ~ 25 fps    + Compare
high 1366x768
13 21.4 ~ 17 fps    + Compare
» With all tested laptops playable in detail settings low.
Risen 2: Dark Waters

Risen 2: Dark Waters

2012
low 1024x768
16  fps    + Compare
med. 1366x768
10  fps    + Compare
high 1366x768
8  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Mass Effect 3

Mass Effect 3

2012
low 1280x720
21  fps    + Compare
high 1366x768
16  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Alan Wake

Alan Wake

2012
low 1024x768
16  fps    + Compare
med. 1366x768
10  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Anno 2070

Anno 2070

2011
low 1024x768
39.9 45 ~ 42 fps    + Compare
med. 1366x768
15.8 17 ~ 16 fps    + Compare
high 1366x768
12  fps    + Compare
» With all tested laptops playable in detail settings low.
The Elder Scrolls V: Skyrim

The Elder Scrolls V: Skyrim

2011
low 1280x720
22.3 25 ~ 24 fps    + Compare
med. 1366x768
14.3 16 ~ 15 fps    + Compare
high 1366x768
10 11 ~ 11 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Battlefield 3

Battlefield 3

2011
low 1024x768
16  fps    + Compare
med. 1366x768
11  fps    + Compare
high 1366x768
7  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Deus Ex Human Revolution

Deus Ex Human Revolution

2011
low 1024x768
42  fps    + Compare
high 1366x768
15  fps    + Compare
» With all tested laptops playable in detail settings low.
Total War: Shogun 2

Total War: Shogun 2

2011
low 1024x768
55  fps    + Compare
med. 1280x720
12  fps    + Compare
» With all tested laptops playable in detail settings low.
Additional Benchmarks
CPU 1280x1024
7
Call of Duty: Black Ops

Call of Duty: Black Ops

2010
low 800x600
31  fps    + Compare
med. 1024x768
23  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
StarCraft 2

StarCraft 2

2010
low 1024x768
100  fps    + Compare
med. 1360x768
22  fps    + Compare
high 1360x768
17  fps    + Compare
» With all tested laptops playable in detail settings low.
Metro 2033

Metro 2033

2010
low 800x600
27  fps    + Compare
med. 1360x768
16  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Battlefield: Bad Company 2

Battlefield: Bad Company 2

2010
low 1024x768
32  fps    + Compare
med. 1366x768
25  fps    + Compare
high 1366x768
16  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Crysis - GPU Benchmark

Crysis - GPU Benchmark

2007
low 1024x768
35  fps    + Compare
med. 1024x768
15  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Additional Benchmarks
Low 0xAF 0xAA 800x600
52
Crysis - CPU Benchmark

Crysis - CPU Benchmark

2007
low 1024x768
21  fps    + Compare
med. 1024x768
13  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Additional Benchmarks
Low 0xAF 0xAA 800x600
50
lowmed.highultraQHD4K
Dirt 415.5
Farming Simulator 1742.426.6
World of Warships26.118
Metal Gear Solid V23.318.3
Dota 2 Reborn33.817.3
Dirt Rally38.614.6
Battlefield Hardline9.58.6
Sims 488.719.7
F1 20131815
Total War: Rome II23.316.6
Saints Row IV11.7
Company of Heroes 28.2
GRID 228.917.2
Metro: Last Light10.3
BioShock Infinite26.113
StarCraft II: Heart of the Swarm91.528.214.9
Tomb Raider28.714.9
Dead Space 349.618.4
Far Cry 3141110
Assassin´s Creed III108.5
Hitman: Absolution12104
Medal of Honor: Warfighter14129
Fifa 13825434
F1 2012191815
Borderlands 2241811
Counter-Strike: GO523931
Darksiders II22
Sleeping Dogs1163
Max Payne 312118
Diablo III412517
Risen 2: Dark Waters16108
Mass Effect 32116
Alan Wake1610
Anno 2070421612
The Elder Scrolls V: Skyrim241511
Battlefield 316117
Deus Ex Human Revolution4215
Total War: Shogun 25512
Call of Duty: Black Ops3123
StarCraft 21002217
Metro 20332716
Battlefield: Bad Company 2322516
Crysis - GPU Benchmark3515
Crysis - CPU Benchmark2113
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps		26
12
4
36
2

18
2










For more games that might be playable and a list of all games and graphics cards visit our Gaming List

v1.26
log 22. 10:55:32

#0 no ids found in url (should be separated by "_") +0s ... 0s

#1 not redirecting to Ajax server +0s ... 0s

#2 did not recreate cache, as it is less than 5 days old! Created at Mon, 22 Apr 2024 05:40:21 +0200 +0.001s ... 0.001s

#3 no comparison url found in template nbc.compare_page_1 needed +0.062s ... 0.064s

#4 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.064s

#5 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.064s

#6 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.065s

#7 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.065s

#8 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.065s

#9 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.066s

#10 composed specs +0s ... 0.066s

#11 did output specs +0s ... 0.066s

#12 start showIntegratedCPUs +0s ... 0.066s

#13 getting avg benchmarks for device 3267 +0.028s ... 0.094s

#14 got single benchmarks 3267 +0.014s ... 0.108s

#15 got avg benchmarks for devices +0s ... 0.108s

#16 min, max, avg, median took s +0.387s ... 0.495s

#17 before gaming benchmark output +0s ... 0.495s

#18 Got 108 rows for game benchmarks. +0.006s ... 0.501s

#19 composed SQL query for gamebenchmarks +0s ... 0.501s

#20 got data and put it in $dataArray +0.031s ... 0.532s

#21 benchmarks composed for output. +0.887s ... 1.418s

#22 no comparison url found in template nbc.compare_page_1 needed +0.003s ... 1.421s

#23 return log +0s ... 1.421s

No reviews found for this graphics card.

Please share our article, every link counts!

» Comparison of GPUs
Detailed list of all laptop GPUs sorted by class and performance.

» Benchmark List
Sort and restrict laptop GPUs based on performance in synthetic benchmarks.

» Notebook Gaming List
Playable games for each graphics card and their average FPS results.

Class 1

NVIDIA GeForce RTX 4090 Laptop GPU
NVIDIA RTX 5000 Ada Generation Laptop GPU
Radeon RX 7900M
NVIDIA GeForce RTX 4080 Laptop GPU
NVIDIA RTX 4000 Ada Generation Laptop GPU
NVIDIA RTX 3500 Ada Generation Laptop GPU
GeForce RTX 3080 Ti Laptop GPU
NVIDIA GeForce RTX 4070 Laptop GPU
NVIDIA RTX 3000 Ada Generation Laptop GPU
RTX A5500 Laptop GPU
GeForce RTX 3080 Laptop GPU
Radeon RX 6850M XT
GeForce RTX 3070 Ti Laptop GPU
RTX A4500 Laptop GPU
RTX A5000 Laptop GPU
NVIDIA GeForce RTX 4060 Laptop GPU
NVIDIA RTX 2000 Ada Generation Laptop GPU
Quadro RTX 6000 (Laptop)
Radeon RX 6800M
GeForce RTX 2080 Super Mobile
GeForce RTX 3070 Laptop GPU
RTX A4000 Laptop GPU *

Class 2

Radeon RX 6800S
Radeon RX 7600M XT *
Radeon RX 7700S *
M3 Max 40-Core GPU *
M2 Max 38-Core GPU *
GeForce RTX 2080 Mobile
Radeon RX 6700M
M3 Max 30-Core GPU *
Quadro RTX 5000 (Laptop)
Radeon RX 7600M *
M2 Max 30-Core GPU *
GeForce RTX 3060 Laptop GPU
M1 Max 32-Core GPU *
Radeon RX 7600S
GeForce RTX 2070 Super Mobile
GeForce RTX 2080 Super Max-Q
RTX A3000 Laptop GPU
M1 Max 24-Core GPU *
A770M *
Radeon RX 6650M XT *
M3 Pro 18-Core GPU *
M2 Pro 19-Core GPU *
Radeon RX 6650M
Radeon RX 6600M
Radeon RX 6700S
GeForce RTX 2070 Mobile
Quadro RTX 5000 Max-Q
GeForce RTX 2080 Max-Q
Radeon RX 5700M *
GeForce GTX 1080 Mobile
Quadro RTX 4000 (Laptop)
M3 Pro 14-Core GPU *
M2 Pro 16-Core GPU *
M1 Pro 16-Core GPU *
Radeon PRO W6600M *
GeForce RTX 2070 Super Max-Q
Quadro RTX 4000 Max-Q *
M1 Pro 14-Core GPU *
GeForce RTX 2070 Max-Q *
Radeon RX 6600S *
Quadro P5200
Quadro RTX 3000 (Laptop) *
GeForce RTX 2060 Mobile
Quadro RTX 3000 Max-Q *
GeForce GTX 1080 Max-Q
GeForce GTX 1070 Mobile
GeForce RTX 2060 Max-Q *
Quadro P4200
NVIDIA GeForce RTX 4050 Laptop GPU
Nvidia RTX 1000 Ada Generation Laptop GPU
RTX A2000 Laptop GPU
A730M *
Radeon Pro 5600M *
Radeon RX 5600M
Quadro P5000
GeForce GTX 1660 Ti Mobile
GeForce RTX 3050 Ti Laptop GPU
GeForce RTX 3050 6GB Laptop GPU
A570M *
RTX A1000 Laptop GPU
GeForce GTX 1070 Max-Q
A550M *
Quadro P5000 Max-Q *
GeForce RTX 3050 4GB Laptop GPU
Nvidia RTX 500 Ada Generation Laptop GPU
A530M *
GeForce GTX 1660 Ti Max-Q
RTX A500 Laptop GPU
Radeon RX 6550M *
Radeon RX 6500M
Radeon RX 6550S *
GeForce GTX 980 (Laptop)
Quadro M5500
Quadro P4000
Quadro T2000 (Laptop) *
GeForce GTX 1060 Mobile
GeForce GTX 1650 Ti Mobile
A370M *
Radeon RX 5500M
Radeon Pro 5500M *
Quadro P4000 Max-Q
Quadro P3200
Radeon RX 580X (Laptop) *
Radeon RX 580 (Laptop)
Radeon RX 6450M *
GeForce RTX 2050 Mobile
GeForce MX570 *
Radeon RX 6300M *
GeForce GTX 1650 Mobile
Radeon Pro 5300M
Radeon RX 5300M
Quadro P3000
GeForce GTX 1060 Max-Q
Quadro P3000 Max-Q *
GeForce GTX 1650 Ti Max-Q *
Quadro T2000 Max-Q *
Radeon Pro WX 7100 *
Radeon RX 570X (Laptop) *
Radeon RX 570 (Laptop) *
Radeon RX 470 (Laptop) *
GeForce GTX 1650 Max-Q *
T1200 Laptop GPU *
Quadro T1000 (Laptop) *
Quadro T1000 Max-Q *
A310 *
Arc 8-Cores *
A350M *
Arc 7-Cores *
T600 Laptop GPU *
T550 Laptop GPU *

Class 3

GeForce GTX 980M
Vega M GH
Quadro M5000M
Radeon Pro Vega 20
Radeon 780M *
GeForce MX550
GeForce GTX 1050 Ti Mobile
Radeon 680M
Quadro P2000
Quadro P2000 Max-Q
Quadro M4000M
GeForce GTX 970M
T500 Laptop GPU *
GeForce MX450 *
Radeon R9 M395X
GeForce GTX 1050 Ti Max-Q *
Radeon Pro Vega 16
Vega M GL / 870
WX Vega M GL
Radeon R9 M485X
Quadro M3000M
GeForce GTX 1050 Mobile
FirePro W7170M
Radeon R9 M395
GeForce GTX 1050 Max-Q *
Radeon 760M *
Radeon Radeon Steam Deck 8CU
Radeon 660M
Radeon Pro WX 4150 *
GeForce GTX 965M
Radeon RX 560X (Laptop)
Radeon RX 560 (Laptop)
Quadro M2200
Radeon RX 460 (Laptop)
Quadro P1000
Radeon R9 M390
Xe MAX
Radeon Pro 560X
Radeon Pro 560
Radeon Pro 460
Radeon Pro WX 4130 *
Iris Xe G7 96EUs
GeForce MX350
GeForce GTX 960M
Quadro M1200
Quadro P620 *
Radeon RX 550X (Laptop)
Radeon RX 550 (Laptop)
Radeon RX 640
Radeon Pro WX 3200 *
Radeon Pro 555X
Radeon Pro 555
Radeon Pro 455
Quadro P600
GeForce MX250
GeForce MX330
GeForce MX150
Iris Xe G7 80EUs
Graphics 4-Core *
Quadro M2000M
Radeon RX 540X *
Radeon Pro WX 2100 *
Radeon RX 540 *
Radeon Pro WX 3100 *
GeForce GTX 950M
Radeon Pro 450
Radeon 630
Radeon 540X *
Radeon R9 M470X *
Radeon R9 M385X
Quadro P520
Quadro M1000M
Quadro M620 *
GeForce 945M
Quadro P500 *
UHD Graphics 64EUs
Iris Plus Graphics G7 (Ice Lake 64 EU) *
Vega 10 *
Iris Pro Graphics P580
Iris Pro Graphics 580
Radeon R9 M470 *
FirePro W5170M *
Radeon R9 M370X
Vega 9
FirePro W5130M
UHD Graphics Xe G4 48EUs *
UHD Graphics 32EUs
UHD Graphics Xe 32EUs (Tiger Lake-H) *
UHD Graphics 750
Radeon 740M *
GeForce MX230
Vega 8 *
Vega 7
Radeon R7 M465
Iris Pro Graphics 6200
GeForce MX130
GeForce 940MX
Quadro M520
Vega 8
GeForce 940M
Iris Plus Graphics G4 (Ice Lake 48 EU)
GeForce 930MX
Quadro M600M
FirePro W4190M
Radeon R9 M375
Iris Plus Graphics 655
Radeon R7 M445
Quadro M500M
Iris Plus Graphics 650
GeForce 930M
Iris Graphics 550
Radeon 530
Radeon 625
Vega 6 *
Iris Plus Graphics 645
GeForce MX110 *
Iris Plus Graphics 640
GeForce 920MX
Iris Graphics 540
UHD Graphics 24EUs (Alder Lake-N) *
Radeon R7 (Bristol Ridge) *
Radeon R7 M460 *
Radeon R7 M360
GeForce 920M
Radeon R8 M445DX
Radeon 620
Radeon R7 M440
Radeon R7 M340
Radeon 520
Radeon 610
Radeon Graphics (Ryzen 7000)
Radeon 610M *
Vega 6 *
Vega 5 *
UHD Graphics G1 (Ice Lake 32 EU)
UHD Graphics Xe 16EUs (Tiger Lake-H) *
UHD Graphics G7 (Lakefield GT2 64 EU)
HD Graphics 530
Radeon R5 (Bristol Ridge)
UHD Graphics 620
HD Graphics 620
Adreno 690 *
Adreno 685 *
Adreno 680 *
Radeon R5 M330
Radeon R5 M430
Vega 3 *
GeForce 910M
HD Graphics 520
Iris Graphics 6100
UHD Graphics G4 (Lakefield GT1 48 EU) *

Class 4

UHD Graphics 730
Radeon R5 M320 *
Radeon R5 M315 *
Radeon R5 M420 *
Vega 2 *
Radeon R5 (Stoney Ridge)
HD Graphics 6000
UHD Graphics (Jasper Lake 32 EU) *
UHD Graphics 617
UHD Graphics 615
UHD Graphics (Jasper Lake 24 EU) *
HD Graphics 615
HD Graphics 515
UHD Graphics 610
HD Graphics 610
HD Graphics 510
UHD Graphics (Jasper Lake 16 EU)
UHD Graphics 605
HD Graphics 505
HD Graphics 5300
Radeon R4 (Stoney Ridge)
Radeon R5 (Beema/Carrizo-L)
Radeon R4 (Beema)
Radeon R3 (Mullins/Beema)
Radeon R2 (Stoney Ridge)
HD Graphics (Broadwell)
UHD Graphics 600
HD Graphics 500
HD Graphics 405 (Braswell)
HD Graphics (Braswell)
HD Graphics 400 (Braswell)
Radeon HD 7420G

Class 5

Radeon R2 (Mullins/Beema/Carrizo-L)
Radeon R6 (Mullins)

* Approximate position of the graphics adapter
