Intel Core i5-13400

Intel i5-13400

英特尔酷睿 i5-13400 是一款顶级的现代快速台式机处理器，属于当前的 Raptor Lake 系列。该处理器于 2023 年初推出，基本频率为 2.5 GHz。在 Turbo 模式下，主频可达 4.6 GHz。与 Alder Lake-S 一样，Raptor Lake-S 也是基于 P 核心和 E 核心相结合的混合设计。因此，英特尔酷睿 i5-13400 提供6 个 P 核心和 4 个 E 核心，总共可以并行处理多达 16 个线程。该处理器继续采用 10 纳米生产工艺（称为 "英特尔 7"）制造。英特尔酷睿 i5-13400 没有可自由选择的倍频。Alder Lake 系列采用的 LGA 1700 插座是其基础。英特尔酷睿 i5-13400 可以基于 Raptor Lake 或 Alder Lake 芯片。不过，最初供应的是 Alder Lake 芯片。

性能

与英特尔酷睿 i5-12400 相比，新酷睿 i5-13400 的 IPC 略有提高。不过，现在还有 4 个 e 核，可支持处理器的多线程性能。这使得英特尔酷睿 i5-13400 达到了英特尔酷睿 i5-12600K 的水平，后者也提供了 16 个线程。

图形单元

英特尔酷睿 i5-13400 是一款集成图形单元的处理器，但它只适合办公用途或非常老式且要求不高的游戏。

功耗

英特尔酷睿 i5-13400 的 TDP 在 PL1 时为 65 瓦。英特尔将 PL2 限制为 148 瓦。如果停用 BIOS 中的功耗限制，则可以永久达到 PL2 值。不过，为此应使用高质量、大功率的散热装置。

SeriesIntel Raptor Lake-S
CodenameRaptor Lake-S

Series: Raptor Lake-S Raptor Lake-S

Intel Core i7-137002.1 - 5.2 GHz16 / 24 cores30 MB L3
Intel Core i5-13400F2.5 - 4.6 GHz10 / 16 cores20 MB L3
Intel Core i5-13400 « 2.5 - 4.6 GHz10 / 16 cores20 MB L3
Clock Rate2500 - 4600 MHz
Level 1 Cache0.1 MB
Level 2 Cache9.5 MB
Level 3 Cache20 MB
Number of Cores / Threads10 / 16
Power Consumption (TDP = Thermal Design Power)65 Watt
Manufacturing Technology10 nm
Die Size257 mm2
Max. Temperature100 °C
SocketLGA 1700
FeaturesIntel SSE4.1, Intel SSE4.2, Intel AVX2
GPUIntel UHD Graphics 730 (Rocket Lake) (300 - 1550 MHz)
64 Bit64 Bit support
Architecturex86
Starting Price$221 U.S.
Announcement Date01/04/2023
Product Link (external)www.intel.de

Benchmarks

Performance Rating - CB R15 + R20 + 7-Zip + X265 + Blender + 3DM11 CPU
42.9 pt (60%)
AMD E1-2100
2.47 -94%
...
AMD Ryzen 7 7840U
42.1 -2%
Intel Core i9-10980XE
42.1 -2%
AMD Ryzen 7 8840U
42.3 -1%
Intel Core i5-13400F
42.5 -1%
Intel Core i5-13450HX
42.6 -1%
AMD Ryzen 7 PRO 7840U
42.7 0%
Intel Core i9-11900K
42.7 0%
AMD Ryzen 7 5800X3D
42.7 0%
AMD Ryzen 7 5700X
42.8 0%
Intel Core i5-13400
42.9
Intel Core i9-13905H
42.9 0%
Intel Core i7-12700H
43.1 0%
AMD Ryzen 5 7640HS
43.2 1%
AMD Ryzen 9 3950X
43.2 1%
Intel Core i7-13620H
43.4 1%
Intel Core i7-12800H
43.4 1%
Intel Core Ultra 9 185H
43.5 1%
Intel Core i7-1370P
43.5 1%
Intel Core i7-12850HX
43.6 2%
...
AMD Ryzen Threadripper PRO 7995WX
72.1 68%
0%
100%
Cinebench R23 - Cinebench R23 Multi Core
15953 Points (15%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD E1-2100
202 -99%
...
AMD Ryzen 9 5900X
15441 -3%
AMD Ryzen 7 5800X
15476 -3%
Intel Core i9-10850K
15538 -3%
AMD Ryzen 9 PRO 7940HS
15603 -2%
Intel Core Ultra 7 165H
15743 -1%
Intel Core i9-10900K
15821 -1%
AMD Ryzen 7 8845HS
15889 0%
Intel Core i7-12700H
15902 0%
Intel Core i5-13400F
15911 0%
Intel Core i5-13400
15953
Intel Core i7-12850HX
16302 2%
AMD Ryzen 7 7840HS
16411 3%
Intel Core Ultra 9 185H
16514 4%
Intel Core i5-13450HX
16575 4%
AMD Ryzen 9 7940HS
16952 6%
AMD Ryzen 9 8945HS
17178 8%
Intel Core i9-13900H
17182 8%
AMD Ryzen 7 7800X3D
17387 9%
Intel Core i5-12600K
17491 10%
...
AMD Ryzen Threadripper PRO 7995WX
107681 575%
0%
100%
Cinebench R23 - Cinebench R23 Single Core
1786 Points (76%)
+ 1 benchmarks and specifications   - Hide comparison chart
Cinebench R20 - Cinebench R20 CPU (Single Core)
688 Points (76%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R20 - Cinebench R20 CPU (Multi Core)
6135 Points (15%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
2358 Points (15%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD A4-1200
31 -99%
...
AMD Ryzen 7 3800XT
2230 -5%
Intel Core i7-12800H
2236 -5%
AMD Ryzen 5 7645HX
2276 -3%
Intel Core i7-11700K
2299 -3%
Intel Core i9-10910
2302 -2%
Intel Core i7-1370P
2316 -2%
Intel Core i5-13500H
2317 -2%
AMD Ryzen 7 5700X
2329 -1%
AMD Ryzen 5 7600
2339 -1%
Intel Core i5-13400
2358
Intel Core i5-13400F
2364 0%
Intel Core i7-13620H
2373 1%
AMD Ryzen 7 5800X3D
2413 2%
Intel Core i5-13450HX
2427 3%
AMD Ryzen 7 PRO 7840HS
2440 3%
Intel Core i7-13700H
2444 4%
Intel Core Ultra 9 185H
2449 4%
Intel Core i9-10850K
2457 4%
Intel Core Ultra 7 155H
2461 4%
...
AMD Ryzen Threadripper PRO 7995WX
15842 572%
0%
100%
012024036048060072084096010801200132014401560168018001920204021602280Tooltip
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
257 Points (77%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD A4-1200
19 -93%
...
AMD Ryzen 9 5900X
252.6 -2%
AMD Ryzen 7 5700X
253 -2%
AMD Ryzen 5 5600X
254 -1%
Intel Core Ultra 7 155H
254.3 -1%
Intel Core i9-13905H
255.3 -1%
Intel Core i7-12700H
255.6 -1%
AMD Ryzen 7 7840U
256.3 0%
Intel Core i9-11900K
256.5 0%
Intel Core i9-12900HK
256.6 0%
Intel Core i5-13400
257
Intel Core i9-12950HX
257.4 0%
Intel Core i7-13700H
259.7 1%
Intel Core i7-12800HX
260 1%
Intel Core i7-12800H
260 1%
Intel Core i7-12850HX
260.5 1%
Intel Core i9-12900H
261.7 2%
Intel Core i7-13620H
261.7 2%
Intel Core i9-12900
262 2%
AMD Ryzen 7 8840U
263 2%
...
Intel Core i9-14900K
332 29%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
27.4 Points (36%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
3.1 Points (77%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
8721 points (53%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
51095 points (37%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
83214 Points (58%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
14142 Points (17%)
+ 1 benchmarks and specifications   + Show comparison chart
wPrime 2.10 - wPrime 2.0 1024m *
452.3 s (5%)
+ 1 benchmarks and specifications   + Show comparison chart
wPrime 2.10 - wPrime 2.0 32m *
3.5 s (1%)
+ 1 benchmarks and specifications   + Show comparison chart
WinRAR - WinRAR 4.0
7979 points (13%)
+ 1 benchmarks and specifications   + Show comparison chart
7-Zip 18.03 - 7-Zip 18.03 Multli Thread 4 runs
59510 MIPS (34%)
+ 1 benchmarks and specifications   + Show comparison chart
7-Zip 18.03 - 7-Zip 18.03 Single Thread 4 runs
5829 MIPS (70%)
+ 1 benchmarks and specifications   + Show comparison chart
X264 HD Benchmark 4.0 - x264 Pass 2
135.8 fps (47%)
+ 1 benchmarks and specifications   + Show comparison chart
X264 HD Benchmark 4.0 - x264 Pass 1
311 fps (72%)
+ 1 benchmarks and specifications   + Show comparison chart
HWBOT x265 Benchmark v2.2 - HWBOT x265 4k Preset
19.1 fps (34%)
+ 1 benchmarks and specifications   + Show comparison chart
051015202530Tooltip
TrueCrypt - TrueCrypt Serpent
1.2 GB/s (0%)
+ 1 benchmarks and specifications   + Show comparison chart
TrueCrypt - TrueCrypt Twofish
2 GB/s (34%)
+ 1 benchmarks and specifications   + Show comparison chart
TrueCrypt - TrueCrypt AES
11.8 GB/s (31%)
+ 1 benchmarks and specifications   + Show comparison chart
Blender - Blender 3.3 Classroom CPU *
336 Seconds (4%)
+ 1 benchmarks and specifications   + Show comparison chart
Blender - Blender 2.79 BMW27 CPU *
206 Seconds (1%)
+ 1 benchmarks and specifications   + Show comparison chart
R Benchmark 2.5 - R Benchmark 2.5 *
0.5 sec (10%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 06 - CPU - 3DMark 06 - CPU
13632 Points (29%)
+ 1 benchmarks and specifications   + Show comparison chart
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
8 s (2%)
+ 1 benchmarks and specifications   + Show comparison chart
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
18 s (1%)
+ 1 benchmarks and specifications   + Show comparison chart
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
427.2 s (2%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
79573 Points (70%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance Physics
23120 Points (63%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Physics
83302 Points (68%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Extreme Physics
82671 Points (67%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Unlimited Physics
89999 Points (76%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Physics
19608 Points (50%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Physics
27135 Points (48%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Time Spy CPU
12948 Points (55%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 5.5 - Geekbench 5.1 - 5.4 64 Bit Single-Core
1795 points (76%)
+ 1 benchmarks and specifications   - Hide comparison chart
Geekbench 5.5 - Geekbench 5.1 - 5.4 64 Bit Multi-Core
12107 points (22%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 5.0 - Geekbench 5.0 64 Bit Single-Core
1706 points (7%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 5.0 - Geekbench 5.0 64 Bit Multi-Core
11801 points (37%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
7683 points (77%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
42509 points (47%)
+ 1 benchmarks and specifications   + Show comparison chart
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
535 ms (1%)
+ 1 benchmarks and specifications   + Show comparison chart
WebXPRT 4 - WebXPRT 4 Score
251 Points (72%)
+ 1 benchmarks and specifications   + Show comparison chart
WebXPRT 3 - WebXPRT 3 Score
306 Points (64%)
+ 1 benchmarks and specifications   + Show comparison chart
CrossMark - CrossMark Overall
1877 Points (72%)
+ 1 benchmarks and specifications   + Show comparison chart
Power Consumption - Prime95 Power Consumption - external Monitor *
229 Watt (39%)
+ 1 benchmarks and specifications   + Show comparison chart
0153045607590105120135150165180195210225240Tooltip
Power Consumption - Cinebench R15 Multi Power Consumption - external Monitor *
196.6 Watt (36%)
+ 1 benchmarks and specifications   + Show comparison chart
0153045607590105120135150165180195Tooltip
Power Consumption - Idle Power Consumption 150cd 1min *
82.8 Watt (92%)
+ 1 benchmarks and specifications   + Show comparison chart
05101520253035404550556065707580Tooltip
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

v1.26
log 25. 07:02:59

#0 no ids found in url (should be separated by "_") +0s ... 0s

#1 not redirecting to Ajax server +0s ... 0s

#2 did not recreate cache, as it is less than 5 days old! Created at Thu, 25 Apr 2024 05:38:32 +0200 +0.001s ... 0.001s

#3 no comparison url found in template nbc.compare_page_2 needed +0.007s ... 0.008s

#4 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.009s

#5 composed specs +0s ... 0.009s

#6 did output specs +0s ... 0.009s

#7 getting avg benchmarks for device 14996 +0.017s ... 0.025s

#8 got single benchmarks 14996 +0.012s ... 0.038s

#9 got avg benchmarks for devices +0s ... 0.038s

#10 min, max, avg, median took s +1.026s ... 1.063s

#11 no comparison url found in template nbc.compare_page_2 needed +0s ... 1.063s

#12 return log +0s ... 1.063s

No reviews found for this CPU (yet).

Please share our article, every link counts!

»移动处理器 对比
所有移动处理器的对比


»移动处理器 基准测试
所有已有笔记本电脑中使用的处理器的基准测试成绩 (桌面处理器或移动处理器)

Other CPUs of the series Raptor Lake-S

» Intel Core i9-13900K
   24x 3 GHz - 5.8 GHz
» Intel Core i7-13700K
   16x 3.4 GHz - 5.4 GHz
» Intel Core i5-13600K
   14x 3.5 GHz - 5.1 GHz
» Intel Core i7-13700
   16x 2.1 GHz - 5.2 GHz
» Intel Core i5-13400F
   10x 2.5 GHz - 4.6 GHz
» Intel Core i5-13400
   10x 2.5 GHz - 4.6 GHz

Surrounding CPUs

+ Intel Core i7-12700K
   12x 2.7 GHz - 5 GHz
+ AMD Ryzen 9 5900X
   12x 3.7 GHz - 4.8 GHz
+ Intel Core i9-10980XE
   18x 3 GHz - 4.6 GHz
+ Intel Core i9-9980XE
   18x 3 GHz - 4.4 GHz
+ Intel Core i5-13400F
   10x 2.5 GHz - 4.6 GHz
» Intel Core i5-13400
   10x 2.5 GHz - 4.6 GHz
- Intel Core i7-12700F
   12x 3.3 GHz - 4.9 GHz
- Intel Core i7-12700
   12x 3.3 GHz - 4.9 GHz
- AMD Ryzen Threadripper 2950X
   16x 3.5 GHz - 4.4 GHz
- Intel Core i5-12600K
   10x 2.8 GHz - 4.9 GHz
- AMD Ryzen 5 7600X
   6x 4.7 GHz - 5.3 GHz
> Notebookcheck中文版（NBC中国） > FAQ / 小提示/ 技术参数 > 移动处理器 —— 基准测试成绩列表 > Intel Raptor Lake-S i5-13400 笔记本处理器
Klaus Hinum (Update: 2023-11-26)
