Apple M1 Pro 8-Core

Apple M1 Pro 8-Core

苹果M1 Pro 8核是苹果公司的一个片上系统（SoC），在2021年底的MacBook Pro 14和16英寸机型中发现。它提供了芯片中10个可用的8个核心，分为6个性能核心（P-cores，频率600-3220 MHz）和4个节能核心（E-cores，频率600-2064 MHz）。这些内核与苹果M1的内核类似。

大内核（代号为Firestorm）提供192KB指令缓存，128KB数据缓存和24MB共享二级缓存（高于M1的12MB）。四个高效核心（代号Icestorm）要小得多，只提供128 KB指令缓存、64 KB数据缓存和4 MB共享缓存。最后，该SoC包括由GPU共享的16MB系统级缓存。效率核心（E集群）的时钟频率为600-2064 MHz，性能核心（P集群）为600-3228 MHz。

芯片旁边的统一内存（16或32GB LPDDR5-6400）由一个256位内存控制器连接，可供GPU和CPU使用。

M1 Pro中的集成显卡提供14个内核（在芯片的16个内核中）。

此外，SoC还集成了一个快速的16核神经引擎，一个安全飞地（例如用于加密），一个统一的内存架构，Thunderbolt 4控制器，一个ISP，以及媒体去除和编码器（包括ProRes）。

M1 Pro在台积电以5纳米制造，集成了337亿个晶体管。该芯片的峰值功耗被宣传为CPU密集型任务的30W左右。

SeriesApple Apple M-Series
Series: Apple M-Series
Apple M1 Max0 - 3.22 GHz10 / 1048 MB
Apple M1 Pro2.06 - 3.22 GHz10 / 1024 MB
» Apple M1 Pro 8-Core0 - 3.22 GHz8 / 816 MB
Apple M22.42 - 3.48 GHz8 / 8
Apple M12.06 - 3.2 GHz8 / 816 MB
Clock Rate <=3220 MHz
Level 1 Cache2.3 MB
Level 2 Cache28 MB
Level 3 Cache16 MB
Number of Cores / Threads8 / 8
Transistor Count33700 Million
Manufacturing Technology5 nm
FeaturesARMv8 Instruction Set
GPUApple M1 Pro 14-Core GPU ( - 1296 MHz)
64 Bit64 Bit support
ArchitectureARM
Announcement Date10/18/2021

Benchmarks

Cinebench R23 - Cinebench R23 Multi Core
9581 Points (16%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R23 - Cinebench R23 Single Core
1531 Points (76%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
1320 Points (14%)
+ 1 benchmarks and specifications   + Show comparison chart
0701402102803504204905606307007708409109801050112011901260Tooltip
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
210 Points (72%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 5.3 - Geekbench 5.1 - 5.4 64 Bit Single-Core
1769 points (87%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 5.3 - Geekbench 5.1 - 5.4 64 Bit Multi-Core
9942 points (35%)
+ 1 benchmarks and specifications   + Show comparison chart
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
407.2 ms (0%)
+ 1 benchmarks and specifications   + Show comparison chart
Sunspider - Sunspider 1.0 Total Score *
76.7 ms (1%)
+ 1 benchmarks and specifications   + Show comparison chart
Octane V2 - Octane V2 Total Score
65528 Points (68%)
+ 1 benchmarks and specifications   + Show comparison chart
WebXPRT 3 - WebXPRT 3 Score
343 Points (91%)
+ 1 benchmarks and specifications   + Show comparison chart
CrossMark - CrossMark Overall
1490 Points (65%)
+ 1 benchmarks and specifications   + Show comparison chart
Power Consumption - Geekbench 5.4 Power Consumption 150cd *
14.8 Watt (66%)
+ 1 benchmarks and specifications   + Show comparison chart
0510152025303540Tooltip
Power Consumption - Idle Power Consumption 150cd *
5.4 Watt (20%)
+ 1 benchmarks and specifications   + Show comparison chart
012345Tooltip
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
