Intel Core i3-1005G1

Intel i3-1005G1

英特尔酷睿i3-1005G1是一款基于笔记本电脑和超极本的高效节能双核SoC,基于2019年Mai(Computex)上发布的Ice -Lake-U一代。它集成了两个时钟频率为1.2(基本)-3.4 GHz(单核和双核Turbo)的Sunnycove处理器核心(由于HyperThreading而具有4个线程)。根据英特尔的说法,Sunnycove内核可实现多18%的IPC(每个时钟指令),因此CPU性能应与更高时钟的Whiskey Lake(例如,具有2.3-3.9 GHz的Core i3-8145U)或较早的Core i7- 7660U(2.5-4 GHz双核)相当。

Ice-Lake的最大改进是集成的Gen 11显卡,称为UHD Graphics G1。 Core i3-1005G1集成了最小的GPU,即UHD图形,具有64个CU中的32个以及300-900 MHz的频率。速度更快的型号提供更高的时钟速度(最高1100 MHz),并包括Iris Plus G4和G7。

Ice Lake的其他改进包括AI硬件加速以及芯片中Thunderbolt和Wifi 6的部分集成。集成的DDR4内存控制器支持最高3200 MHz的模块(和LPDDDR4 3733)。

Core i3-1005G1采用Intel全新的10nm工艺生产,应具有与TSMC 7nm工艺相当的性能。 TDP的额定功率为15瓦,因此该CPU可用于轻薄型笔记本电脑(但通常带有风扇)。英特尔为合作商提供13-25瓦的可配置TDP,从而导致性能差异。配置13瓦后,CPU例如根据ark.intel.com,它仅以900 MHz运行。

SeriesIntel Ice Lake
CodenameIce Lake U
Series: Ice Lake Ice Lake U
Intel Core i7-1068G72.3 - 4.1 GHz4 / 88 MB
Intel Core i7-1065G71.3 - 3.9 GHz4 / 88 MB
Intel Core i5-1035G71.2 - 3.7 GHz4 / 86 MB
Intel Core i5-1035G41.1 - 3.7 GHz4 / 86 MB
Intel Core i5-1035G11 - 3.6 GHz4 / 86 MB
Intel Core i5-1034G10.8 - 3.6 GHz4 / 86 MB
» Intel Core i3-1005G11.2 - 3.4 GHz2 / 44 MB
Clock Rate1200 - 3400 MHz
Level 1 Cache96 KB
Level 2 Cache1 MB
Level 3 Cache4 MB
Number of Cores / Threads2 / 4
Power Consumption (TDP = Thermal Design Power)15 Watt
Manufacturing Technology10 nm
FeaturesAVX512, DL Boost, Turbo Boost 2.0
GPUIntel UHD Graphics G1 (Ice Lake 32 EU) (300 - 900 MHz)
64 Bit64 Bit support
Architecturex86
Announcement Date05/29/2019
Product Link (external)Intel Ice Lake i3-1005G1

Benchmarks

Performance Rating - CB R15 + R20 + 7-Zip + X265 + Blender + 3DM11 CPU
36.7 pt (37%)
AMD E1-2100 -90%
...
AMD FX-8350 -9%
Intel Core i5-6287U -7%
Intel Core i7-2860QM -5%
AMD Ryzen 3 1200 -5%
Intel Core i7-6567U -5%
Intel Core i3-1005G1
AMD Ryzen 5 1400 2%
AMD Ryzen 3 1300X 2%
AMD Ryzen 5 3580U 2%
AMD Ryzen 3 2200G 4%
Intel Core i5-8265U 6%
...
AMD Ryzen 9 5950X 170%
0%
100%
Cinebench R20 - Cinebench R20 CPU (Single Core)
min: 338     avg: 381     median: 403 (63%)     max: 403 Points
Cinebench R20 - Cinebench R20 CPU (Multi Core)
min: 848     avg: 899     median: 902 (9%)     max: 948 Points
Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 404     avg: 406     median: 406 (9%)     max: 406.84 Points
0102030405060708090100110120130140150160170180190200210220230240250260270280290300310320330340350360370380390400410Tooltip
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 157     avg: 157     median: 157 (58%)     max: 158.02 Points
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
4.6 Points (9%)
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
1.9 Points (60%)
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
6573 points (59%)
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
14323 points (24%)
wPrime 2.10 - wPrime 2.0 1024m *
440 s (5%)
wPrime 2.10 - wPrime 2.0 32m *
13.9 s (3%)
WinRAR - WinRAR 4.0
2624 points (17%)
7-Zip 18.03 - 7-Zip 18.03 Multli Thread 4 runs
min: 10536     avg: 10871     median: 10942 (9%)     max: 11135 MIPS
7-Zip 18.03 - 7-Zip 18.03 Single Thread 4 runs
min: 3851     avg: 3983     median: 4041 (27%)     max: 4057 MIPS
X264 HD Benchmark 4.0 - x264 Pass 2
25.2 fps (11%)
X264 HD Benchmark 4.0 - x264 Pass 1
135 fps (40%)
HWBOT x265 Benchmark v2.2 - HWBOT x265 4k Preset
min: 3.122     avg: 3.4     median: 3.5 (11%)     max: 3.59 fps
010Tooltip
TrueCrypt - TrueCrypt Serpent
0.2 GB/s (9%)
TrueCrypt - TrueCrypt Twofish
0.4 GB/s (10%)
TrueCrypt - TrueCrypt AES
2.4 GB/s (9%)
Blender 2.79 - Blender 2.79 BMW27 CPU *
min: 1122.9     avg: 1171     median: 1126 (8%)     max: 1264 Seconds
R Benchmark 2.5 - R Benchmark 2.5 *
min: 0.755     avg: 0.8     median: 0.8 (16%)     max: 0.763 sec
3DMark 06 - CPU - 3DMark 06 - CPU
5501 Points (30%)
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
10 s (2%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
22.2 s (1%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
487 s (2%)
3DMark 11 - 3DM11 Performance Physics
min: 4559     avg: 5062     median: 5140 (21%)     max: 5486 Points
3DMark - 3DMark Ice Storm Physics
min: 47838     avg: 47963     median: 47962.5 (31%)     max: 48087 Points
3DMark - 3DMark Ice Storm Extreme Physics
min: 46387     avg: 47239     median: 47238.5 (50%)     max: 48090 Points
3DMark - 3DMark Ice Storm Unlimited Physics
min: 50088     avg: 51165     median: 51165 (53%)     max: 52242 Points
3DMark - 3DMark Cloud Gate Physics
min: 4215     avg: 4272     median: 4287 (11%)     max: 4313 Points
3DMark - 3DMark Fire Strike Standard Physics
min: 6091     avg: 6232     median: 6301 (16%)     max: 6305 Points
3DMark - 3DMark Time Spy CPU
min: 2233     avg: 2358     median: 2357.5 (16%)     max: 2482 Points
Geekbench 4.0 - Geekbench 4.0 64 Bit Single-Core
5042 points (78%)
Geekbench 4.0 - Geekbench 4.0 64 Bit Multi-Core
9847 points (24%)
Geekbench 4.1 - 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
4684 points (64%)
Geekbench 4.1 - 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
8874 points (14%)
Geekbench 5.0 - Geekbench 5.0 64 Bit Single-Core
1108 points (66%)
Geekbench 5.0 - Geekbench 5.0 64 Bit Multi-Core
2146 points (13%)
Geekbench 5.3 - Geekbench 5.1 - 5.3 64 Bit Single-Core
min: 1118     avg: 1140     median: 1139.5 (63%)     max: 1161 points
Geekbench 5.3 - Geekbench 5.1 - 5.3 64 Bit Multi-Core
min: 2153     avg: 2294     median: 2293.5 (14%)     max: 2434 points
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
min: 899     avg: 991     median: 930 (2%)     max: 1144.9 ms
Octane V2 - Octane V2 Total Score
31386 Points (50%)
Power Consumption - Prime95 Power Consumption - external Monitor *
min: 34     avg: 34.5     median: 34.5 (9%)     max: 34.9 Watt
Power Consumption - Cinebench R15 Multi Power Consumption - external Monitor *
min: 31.4     avg: 33.4     median: 33.4 (9%)     max: 35.3 Watt
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

v1.16
