AMD Radeon RX 470 (Desktop)

AMD Radeon RX 470 (Desktop)

AMD Radeon RX 470是一块主流桌面式显卡。它在2016年8月中旬公布,基于Polaris 10芯片,和同门师兄Radeon RX 480相同。不过这块显卡只有2048个着色单元(32个CU,128个TMU),相比RX 480的2304(36个CU,144个TMU)。它的核心频率为926 - 1206MHz,4或8 GB GDDR5显存(256位)频率为1650 MHz,同样相比较低。

由于芯片有所缩水,RX 470比RX 480慢约10%,只能达到英伟达GeForce GTX 970的水平。2016年的大型游戏通常可以在全高清分辨率和最高设置下运行。

AMD设计的Radeon RX 470的TDP为120瓦,使用一个6针电源接口就足够了。

ManufacturerAMD
Radeon RX 400 Series
Radeon RX 480 2304 @ 1.12 - 1.27 GHz256 Bit @ 8000 MHz
Radeon RX 470 (Desktop) 2048 @ 0.93 - 1.21 GHz256 Bit @ 6600 MHz
Radeon RX 470 (Laptop) 2048 @ 0.93 - 1.21 GHz256 Bit @ 7000 MHz
Radeon RX 460 (Desktop) 896 @ 1.09 - 1.2 GHz128 Bit @ 7000 MHz
CodenamePolaris 10 Pro
ArchitecturePolaris
Pipelines2048 - unified
Core Speed926 - 1206 (Boost) MHz
Memory Speed6600 MHz
Memory Bus Width256 Bit
Memory TypeGDDR5
Max. Amount of Memory8192 MB
Shared Memoryno
DirectXDirectX 12
technology14 nm
FeaturesDisplayPort 1.3 HBR / 1.4 HDR Ready, HDMI 2.0b, AMD FreeSync
Date of Announcement04.08.2016

Benchmarks

3DMark - 3DMark Time Spy Score
3756 Points (21%)
3DMark - 3DMark Time Spy Graphics
3624 Points (19%)
3DMark - 3DMark Ice Storm Unlimited Graphics
380689 Points (60%)
3DMark - 3DMark Cloud Gate Score
min: 16841     avg: 21727     median: 21727 (29%)     max: 26613 Points
3DMark - 3DMark Cloud Gate Graphics
min: 66398     avg: 68475     median: 68475 (34%)     max: 70552 Points
3DMark - 3DMark Fire Strike Standard Score
min: 8931     avg: 9507     median: 9507 (28%)     max: 10083 Points
3DMark - 3DMark Fire Strike Standard Graphics
min: 11869     avg: 11885     median: 11884.5 (27%)     max: 11900 Points
3DMark 11 - 3DM11 Performance Score
min: 12328     avg: 13832     median: 13831.5 (36%)     max: 15335 Points
3DMark 11 - 3DM11 Performance GPU
min: 17511     avg: 17625     median: 17624.5 (30%)     max: 17738 Points
...
NVIDIA Quadro P4000 Max-Q -10%
NVIDIA Quadro P3200 -8%
NVIDIA GeForce GTX 980 (Laptop) -3%
AMD Radeon R9 Nano -2%
NVIDIA GeForce GTX 1060 (Desktop) -2%
AMD Radeon R9 Fury 0%
AMD Radeon RX 470 (Desktop)
AMD Radeon RX 480 (Desktop) 2%
NVIDIA Quadro RTX 3000 Max-Q 4%
AMD Radeon RX 570 (Desktop) 8%
AMD Radeon RX 580 (Desktop) 9%
...
0%
100%
Unigine Valley 1.0 - Unigine Valley 1.0 DX
min: 47.2     avg: 47.3     median: 47.3 (26%)     max: 47.4 fps
LuxMark v2.0 64Bit - LuxMark v2.0 Room GPU
1440 Samples/s (15%)
LuxMark v2.0 64Bit - LuxMark v2.0 Sala GPU
3020 Samples/s (20%)
ComputeMark v2.1 - ComputeMark v2.1 Result
9044 points (20%)
Power Consumption - Furmark Stress Test Power Consumption - external Monitor *
313 Watt (62%)
Power Consumption - The Witcher 3 Power Consumption - external Monitor *
250 Watt (50%)
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

F1 2020

F1 2020

2020
ultra 1920x1080
73.8  fps    + Compare
QHD 2560x1440
53.4  fps    + Compare
» With all tested laptops playable in detail settings ultra.
high 1920x1080
76  fps    + Compare
ultra 1920x1080
47.6  fps    + Compare
QHD 2560x1440
35.9  fps    + Compare
» With all tested laptops playable in detail settings ultra.
low 1280x720
113  fps    + Compare
med. 1920x1080
74  fps    + Compare
high 1920x1080
68  fps    + Compare
ultra 1920x1080
63  fps    + Compare
QHD 2560x1440
46  fps    + Compare
4K 3840x2160
24  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Strange Brigade

Strange Brigade

2018
low 1280x720
245 fps  fps    + Compare
med. 1920x1080
105 fps
