AMD Steam Deck OLED APU

AMD 定制 APU 0405 是 Steam Deck OLED 游戏机中的一款 6 纳米芯片。这款 CPU 被 Valve 称为 "6 纳米 AMD APU"，提供四个 Zen 2 内核，主频为 2.4 - 3.6 GHz。

CPU 性能类似于较早的 AMD Ryzen 3 4300U同样拥有四个 Zen 2 内核（无 SMT），但时钟频率略高（2.7 - 3.7 GHz），通常散热效果更好。与仍采用 7 纳米制造工艺的 LCD 版本相比，性能几乎没有变化。

集成 GPU 采用现代 RDNA 2 架构，有 8 个 CU，可以说介于 Radeon 660M 和 680M 之间。

芯片由台积电（TSMC）公司采用 N6 工艺（6 纳米）制造，TDP 为 15 瓦。在软件中，APU 的功耗最高可降至 4 瓦，从而大幅延长电池寿命。

Series	AMD Renoir (Ryzen 4000 APU)
Codename	Van Gogh (Custom)
Clock Rate	2400 - 3500 MHz
Level 1 Cache	256 KB
Level 2 Cache	2 MB
Level 3 Cache	4 MB
Number of Cores / Threads	4 / 8 4 x 3.6 GHz AMD Zen 2
Power Consumption (TDP = Thermal Design Power)	15 Watt
Manufacturing Technology	6 nm
Features	DDR4-3200/LPDDR4-4266 RAM, PCIe 3, MMX, SSE, SSE2, SSE3, SSSE3, SSE4A, SSE4.1, SSE4.2, AVX, AVX2, BMI2, ABM, FMA, ADX, SMEP, SMAP, CPB, AES-NI, RDRAND, RDSEED, SHA, SME
GPU	AMD Radeon Steam Deck 8CU (1000 - 1600 MHz)
64 Bit	64 Bit support
Architecture	x86
Announcement Date	11/09/2023
Product Link (external)	www.steamdeck.com

Benchmarks

Cinebench R23 - Cinebench R23 Multi Core

3984 Points (4%)

+ 1 benchmarks and specifications - Hide comparison chart

Model	CPU	GPU	RAM	Value
Valve Steam Deck 1 TB OLED	Steam Deck OLED APU 15 W / 15 W	Radeon Radeon Steam Deck 8CU	16 GB	3984

AMD E1-2100

202 -95%

...

AMD Ryzen 3 4300U

3571 -10%

Qualcomm Snapdragon 8cx Gen 3

3603 -10%

AMD Ryzen 7 2700U

3603 -10%

Intel Core i7-1065G7

3615 -9%

Intel Core i5-8259U

3792 -5%

Intel Core i5-1035G4

3800 -5%

Intel Core i7-10510U

3866 -3%

AMD Ryzen 7 3750H

3897 -2%

AMD Ryzen 5 3550H

3930 -1%

AMD Steam Deck OLED APU

3984

Intel Core i5-1035G1

4027 1%

4033 1%

4049 2%

4079 2%

4112 3%

4311 8%

Intel Core i5-8400H

4657 17%

Intel Core i5-1135G7

4724 19%

Intel Core i5-1145G7

4880 22%

...

AMD Ryzen 9 7945HX3D

32782 723%

max:

AMD Ryzen Threadripper PRO 7995WX

107681 2603%

100%

Cinebench R20 - Cinebench R20 CPU (Single Core)

357 Points (40%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Valve Steam Deck 1 TB OLED	Steam Deck OLED APU 15 W / 15 W	Radeon Radeon Steam Deck 8CU	16 GB	357

Cinebench R20 - Cinebench R20 CPU (Multi Core)

1521 Points (4%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Valve Steam Deck 1 TB OLED	Steam Deck OLED APU 15 W / 15 W	Radeon Radeon Steam Deck 8CU	16 GB	1521

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit

689 Points (4%)

+ 1 benchmarks and specifications - Hide comparison chart

Model	CPU	GPU	RAM	Value
Valve Steam Deck 1 TB OLED	Steam Deck OLED APU 15 W / 15 W	Radeon Radeon Steam Deck 8CU	16 GB	689

AMD A4-1200

31 -96%

...

Intel Core i7-4800MQ

648 -6%

AMD Ryzen 7 3700U

648 -6%

Intel Core i7-4810MQ

650 -6%

AMD Ryzen Embedded V1605B

654 -5%

AMD Ryzen 7 PRO 3700U

658 -4%

Intel Core i5-1035G7

662 -4%

Intel Core i7-10510U

666 -3%

Intel Core i7-5850HQ

667 -3%

Intel Core i7-6700HQ

671 -3%

AMD Steam Deck OLED APU

689

AMD Ryzen 5 3580U

693 1%

Intel Core i7-4980HQ

694 1%

696 1%

703 2%

707 3%

708 3%

Intel Core i7-7820HQ

710 3%

Intel Core i5-8305G

710 3%

Intel Core i7-6770HQ

711 3%

...

AMD Ryzen 9 7945HX3D

5600 713%

max:

AMD Ryzen Threadripper PRO 7995WX

15842 2199%

100%

7-Zip 18.03 - 7-Zip 18.03 Multli Thread 4 runs

19684 MIPS (11%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Valve Steam Deck 1 TB OLED	Steam Deck OLED APU 15 W / 15 W	Radeon Radeon Steam Deck 8CU	16 GB	19684

7-Zip 18.03 - 7-Zip 18.03 Single Thread 4 runs

3653 MIPS (44%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Valve Steam Deck 1 TB OLED	Steam Deck OLED APU 15 W / 15 W	Radeon Radeon Steam Deck 8CU	16 GB	3653

Geekbench 6.2 - Geekbench 6.2 Single-Core

1348 points (41%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Valve Steam Deck 1 TB OLED	Steam Deck OLED APU 15 W / 15 W	Radeon Radeon Steam Deck 8CU	16 GB	1348

Geekbench 6.2 - Geekbench 6.2 Multi-Core

4587 points (18%)

+ 1 benchmarks and specifications - Hide comparison chart

Model	CPU	GPU	RAM	Value
Valve Steam Deck 1 TB OLED	Steam Deck OLED APU 15 W / 15 W	Radeon Radeon Steam Deck 8CU	16 GB	4587

Intel Celeron N4500

662 -86%

...

Intel Pentium Gold 4425Y

763 -83%

Intel Pentium Silver N6005

1332 -71%

1660 -64%

2024 -56%

2803 -39%

2958 -36%

3012 -34%

3181 -31%

4090 -11%

AMD Steam Deck OLED APU

4587

Intel Core i3-N305

4798 5%

Intel Core i5-8400H

4963 8%

Intel Core i3-1215U

5213 14%

Intel Core i5-10300H

5340 16%

AMD Ryzen 5 PRO 7530U

5548 21%

Intel Core i7-11390H

5630 23%

AMD Ryzen 7 5700U

5901 29%

Intel Core i5-11400H

6317 38%

AMD Ryzen 7 PRO 7730U

6336 38%

...

Apple M3 Max 16-Core

21254 363%

max:

AMD Ryzen Threadripper PRO 7995WX

25365 453%

100%

Geekbench 5.5 - Geekbench 5.1 - 5.4 64 Bit Single-Core

1486 points (63%)

+ 1 benchmarks and specifications - Hide comparison chart

Model	CPU	GPU	RAM	Value
Valve Steam Deck 1 TB OLED	Steam Deck OLED APU 15 W / 15 W	Radeon Radeon Steam Deck 8CU	16 GB	1486

AMD E1-2100

125 -92%

...

1460 -2%

1464 -1%

1467 -1%

1471 -1%

1477 -1%

AMD Ryzen 7 PRO 6850H

1478 -1%

Intel Core i5-11400H

1478 -1%

AMD Ryzen 7 7730U

1480 0%

AMD Ryzen 9 5900HS

1485 0%

AMD Steam Deck OLED APU

1486

AMD Ryzen 7 PRO 6850U

1489 0%

1492 0%

1493 0%

1497 1%

1502 1%

1507 1%

1511 2%

1520 2%

1520 2%

...

Apple M3 Pro 11-Core

2331 57%

100%

Geekbench 5.5 - Geekbench 5.1 - 5.4 64 Bit Multi-Core

4457 points (8%)

+ 1 benchmarks and specifications - Hide comparison chart

Model	CPU	GPU	RAM	Value
Valve Steam Deck 1 TB OLED	Steam Deck OLED APU 15 W / 15 W	Radeon Radeon Steam Deck 8CU	16 GB	4457

AMD E1-2100

238.5 -95%

...

Intel Core i7-8557U

4119 -8%

Intel Core i7-10610U

4134 -7%

Intel Core i7-1065G7

4215 -5%

Intel Core i5-10400H

4332 -3%

Intel Core i7-10810U

4350 -2%

Intel Core i5-10300H

4351 -2%

Intel Core i5-8400H

4352 -2%

Intel Core i5-9300HF

4370 -2%

Intel Core i7-1068G7

4449 0%

AMD Steam Deck OLED APU

4457

Intel Core i5-1038NG7

4564 2%

Intel Core i5-11300H

4642 4%

AMD Ryzen 5 PRO 4650U

4646 4%

4663 5%

4680 5%

4774 7%

4802 8%

4820 8%

Intel Core i7-8850H

4908 10%

...

Apple M3 Max 16-Core

22938 415%

max:

AMD Ryzen Threadripper PRO 7995WX

55811 1152%

100%

WebXPRT 4 - WebXPRT 4 Score

107 Points (31%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Valve Steam Deck 1 TB OLED	Steam Deck OLED APU 15 W / 15 W	Radeon Radeon Steam Deck 8CU Chrome 121.0.6167.85	16 GB	107

CrossMark - CrossMark Overall

840 Points (32%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Valve Steam Deck 1 TB OLED	Steam Deck OLED APU 15 W / 15 W	Radeon Radeon Steam Deck 8CU	16 GB	840

Power Consumption - Prime95 Power Consumption - external Monitor *

26.1 Watt (5%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Valve Steam Deck 1 TB OLED	Steam Deck OLED APU 15 W / 15 W	Radeon Radeon Steam Deck 8CU	16 GB	26.1

show legend

Power Consumption - Idle Power Consumption - external Monitor *

6.5 Watt (4%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Valve Steam Deck 1 TB OLED	Steam Deck OLED APU 15 W / 15 W	Radeon Radeon Steam Deck 8CU	16 GB	6.48

show legend

- Range of benchmark values for this graphics card

- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
