AMD Ryzen 5 PRO 3500U

AMD R5 PRO 3500U

AMD Ryzen 5 PRO 3500U是于2019年4月发布的用于商用笔记本电脑的移动SoC。它将主频为2.1-3.7 GHz的四个Zen +内核(8个线程)与带有8个CU(512个着色器)的Radeon RX Vega 8图形卡相结合,显卡频率高达1200 MHz。该SoC的额定功耗为15瓦TDP,适用于中型笔记本电脑。与类似的消费型Ryzen 5 3500U相比,PRO机型具有额外的管理和安全功能(例如全内存加密)以及更长的保修/可用性。

Picasso SoC使用Zen +微体系结构并进行了一些细微的改进,从而可以将IPS(每频性能)提高3%。此外,12nm工艺允许以相似的功耗获得更高的频率。

集成的双通道内存控制器最多支持DDR4-2400内存。由于毕加索APU的功能与Raven Ridge的前代产品相同,因此,我们推荐参考Raven Ridge文章。

AMD表示,毕加索APU比以前的产品快8%。因此,Ryzen 5 3500U应该领先于Ryzen 5 PRO 2500U(2-3.6 GHz),几乎与Ryzen 7 PRO 2700U(2.2-3.8 GHz)相当。

SeriesAMD Picasso (Ryzen 3000 APU)
CodenameZen+
Series: Picasso (Ryzen 3000 APU) Zen+
AMD Ryzen 7 3780U2.3 - 4 GHz4 / 84 MB
AMD Ryzen 7 3750H2.3 - 4 GHz4 / 84 MB
AMD Ryzen 7 3700U2.3 - 4 GHz4 / 84 MB
AMD Ryzen 7 PRO 3700U2.3 - 4 GHz4 / 84 MB
AMD Ryzen 5 3550H2.1 - 3.7 GHz4 / 84 MB
AMD Ryzen 5 3500U2.1 - 3.7 GHz4 / 84 MB
» AMD Ryzen 5 PRO 3500U2.1 - 3.7 GHz4 / 84 MB
AMD Ryzen 5 3580U2.1 - 3.7 GHz4 / 84 MB
AMD Ryzen 3 3300U2.1 - 3.5 GHz4 / 44 MB
AMD Ryzen 3 PRO 3300U2.1 - 3.5 GHz4 / 44 MB
AMD Ryzen 3 3250U2.6 - 3.5 GHz2 / 44 MB
AMD Ryzen 3 3200U2.6 - 3.5 GHz2 / 44 MB
AMD Athlon Silver 3050U2.3 - 3.2 GHz2 / 24 MB
Clock Rate2100 - 3700 MHz
Level 1 Cache384 KB
Level 2 Cache2 MB
Level 3 Cache4 MB
Number of Cores / Threads4 / 8
Power Consumption (TDP = Thermal Design Power)15 Watt
Transistor Count4500 Million
Manufacturing Technology12 nm
SocketAM4
FeaturesXFR, FMA3, SSE 4.2, AVX2, SMT
GPUAMD Radeon RX Vega 8 (Ryzen 2000/3000) ( - 1200 MHz)
64 Bit64 Bit support
Architecturex86
Announcement Date04/08/2019
Product Link (external)AMD Picasso (Ryzen 3000 APU) R5 PRO 3500U

Benchmarks

Performance Rating - CB R15 + R20 + 7-Zip + X265 + Blender + 3DM11 CPU
36.5 pt (37%)
AMD E1-2100 -90%
...
AMD FX-8350 -8%
Intel Core i5-6287U -7%
Intel Core i7-6567U -5%
AMD Ryzen 3 1200 -5%
Intel Core i7-2860QM -5%
AMD Ryzen 5 PRO 3500U
AMD Ryzen 7 2700U 1%
AMD Ryzen 3 1300X 2%
AMD Ryzen 5 1400 2%
AMD Ryzen 5 3580U 2%
AMD Ryzen 3 2200G 4%
...
0%
100%
Cinebench R20 - Cinebench R20 CPU (Single Core)
min: 354     avg: 362     median: 361.5 (56%)     max: 369 Points
Cinebench R20 - Cinebench R20 CPU (Multi Core)
min: 1328     avg: 1339     median: 1338.5 (13%)     max: 1349 Points
Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 611     avg: 624     median: 624 (14%)     max: 637 Points
03570105140175210245280315350385420455490525560595630610.73605.66604.28603.42577.79573.47573.79573.12573.37573.39574.16572.05573.96575.74573.98572.01571.96569.82574.45575.81573.37571.78573.39574.17573.58572.87573.03573.05573.89573.89574.65574.09576.04572.86573.96574.32574.05574.08572.91572.82575.38572.2574.09573.8572.79572.57571.7572.46573.92572.12636.74575.44557.06559.97558.2557.82557.33556.01558.14557.26558.79557.93558.02558.17557.8556.94557.79556.79557.76557.79557.32557.55557.56552.37547.56Tooltip
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 140     avg: 142     median: 142 (52%)     max: 144 Points
7-Zip 18.03 - 7-Zip 18.03 Multli Thread 4 runs
min: 15910     avg: 16221     median: 16220.5 (13%)     max: 16531 MIPS
7-Zip 18.03 - 7-Zip 18.03 Single Thread 4 runs
min: 3432     avg: 3474     median: 3474 (23%)     max: 3516 MIPS
HWBOT x265 Benchmark v2.2 - HWBOT x265 4k Preset
min: 3.36     avg: 3.5     median: 3.5 (11%)     max: 3.6 fps
012345670.481.682.182.923.563.854.494.464.855.045.375.395.565.735.765.855.975.8666.086.136.066.26.186.216.196.256.286.226.336.326.276.326.386.366.376.376.256.156.095.945.925.865.75.715.65.545.525.425.445.425.315.265.265.185.25.175.075.095.065.034.954.954.944.914.884.914.94.884.934.954.954.884.894.84.84.754.784.774.744.74.734.74.694.654.624.634.624.584.564.584.574.534.54.474.44.374.44.384.354.374.354.324.314.34.34.34.244.264.234.214.24.214.24.194.144.164.164.134.14.14.064.054.024.044.024.013.983.963.973.963.943.953.943.943.923.913.893.93.893.883.853.863.853.833.823.813.793.83.773.783.763.743.723.733.733.713.693.73.693.673.663.663.653.663.653.633.643.633.633.613.63.593.583.563.573.573.553.543.553.533.533.513.523.523.53.493.493.483.483.473.473.463.453.453.453.453.453.433.443.443.433.423.433.423.423.423.413.423.423.423.413.423.413.413.423.413.423.423.413.43.43.413.413.43.393.43.43.43.393.393.393.393.43.393.393.43.393.393.413.43.43.43.413.413.413.413.423.423.413.433.423.433.433.453.463.483.493.493.53.513.523.533.533.523.533.533.523.523.523.523.533.523.513.523.523.523.513.513.513.523.513.53.513.513.53.53.513.513.513.53.493.493.473.483.483.483.473.483.483.473.473.473.473.463.463.463.463.463.463.463.453.463.453.463.453.453.443.453.443.443.443.453.453.443.443.443.443.433.443.433.443.433.433.433.433.433.423.433.433.423.423.433.423.423.423.423.433.423.423.413.413.413.413.413.43.43.43.413.43.43.43.43.393.43.43.393.393.393.393.393.393.383.393.393.383.383.383.383.373.383.373.383.383.373.373.383.373.373.383.373.383.383.373.373.373.373.373.373.373.373.373.363.363.363.363.363.363.363.353.353.343.353.343.343.333.333.333.333.323.323.323.313.313.33.33.293.293.293.293.293.283.283.283.273.273.273.273.273.253.253.253.253.243.243.243.233.233.233.213.213.213.213.213.23.213.23.23.213.23.23.213.23.213.213.213.223.223.233.233.243.243.253.263.263.273.283.283.283.293.33.33.313.313.323.323.333.333.333.343.343.343.343.343.343.343.343.333.343.333.343.333.343.343.343.343.343.343.343.343.333.343.343.343.333.333.333.343.343.333.343.343.333.333.333.333.333.333.333.333.333.333.333.333.323.323.323.323.323.323.323.323.323.323.313.323.323.313.313.313.313.313.313.313.313.313.313.313.313.313.313.33.313.33.33.33.33.293.293.293.293.293.293.283.283.273.273.273.273.273.273.273.273.263.263.273.263.263.263.253.263.253.253.253.253.253.253.253.253.253.253.243.253.243.243.243.243.243.243.233.243.233.233.233.233.233.233.233.223.223.223.223.223.223.223.223.223.223.223.223.223.223.223.223.213.223.213.213.213.213.213.213.23.23.23.23.23.193.23.193.193.183.183.183.183.183.173.173.173.173.173.173.173.163.163.163.163.153.153.153.153.153.153.153.153.153.143.153.143.143.143.143.143.143.143.143.143.143.133.143.143.143.133.143.143.143.133.133.133.133.133.123.123.123.123.123.123.113.113.113.113.113.113.113.113.13.13.13.13.13.13.13.093.093.093.093.093.093.093.093.093.093.083.093.093.083.083.083.083.083.083.073.083.073.073.073.073.063.063.063.063.063.063.063.063.063.063.063.053.053.053.053.053.053.053.053.043.053.053.053.053.053.063.063.063.073.073.083.083.083.083.093.093.13.13.13.113.113.123.123.123.133.133.133.143.143.153.153.153.163.163.163.163.173.173.173.183.183.183.183.193.193.193.23.23.23.23.213.213.223.223.223.223.233.233.233.233.243.243.243.243.253.253.253.253.253.263.263.263.263.263.273.273.273.273.283.283.283.283.293.293.293.293.293.33.33.33.33.313.313.313.313.323.323.323.323.323.333.333.333.343.343.343.353.353.363.360.612.013.053.534.274.625.365.435.786.086.136.476.486.656.676.86.797.056.957.117.217.187.397.267.337.47.327.417.337.357.437.437.397.467.216.96.926.826.756.596.596.436.476.256.276.246.186.056.045.985.915.855.775.795.745.645.645.575.545.525.585.565.535.575.65.625.535.545.455.455.395.435.415.395.335.355.325.255.255.25.195.155.185.155.095.085.045.014.974.964.954.914.934.94.874.854.864.854.834.784.84.784.734.724.684.684.654.664.654.624.64.64.64.564.554.514.534.514.494.474.474.454.434.444.414.424.44.384.374.374.354.344.314.324.314.34.284.274.274.254.264.234.244.234.214.24.194.174.194.174.154.164.154.134.124.124.124.094.14.074.084.074.054.044.054.034.024.0344.024.013.993.983.973.973.973.963.943.953.943.933.923.913.93.93.883.893.893.873.873.873.863.873.873.843.853.853.833.833.843.823.843.833.833.823.833.823.833.823.833.833.833.813.833.833.823.813.823.813.83.83.793.813.83.793.83.83.783.783.83.83.793.813.813.793.813.83.813.813.813.83.823.823.813.823.823.823.833.823.843.843.843.863.873.883.93.93.923.933.943.953.943.953.933.943.943.943.943.933.943.943.933.943.933.923.933.923.923.923.913.923.913.913.913.93.913.93.93.93.893.873.883.883.883.873.883.873.873.863.873.863.863.863.853.863.853.853.853.853.853.843.853.843.843.833.843.833.833.843.833.843.833.823.823.823.823.813.823.823.813.823.813.813.823.813.813.83.83.813.813.83.83.813.813.83.793.793.793.783.793.783.783.783.783.773.773.763.773.773.763.763.763.753.763.763.753.763.753.753.743.743.743.743.733.743.743.733.733.733.733.733.723.733.733.733.723.733.723.723.723.723.723.723.73.73.713.713.73.73.73.73.73.73.693.693.683.683.673.673.663.663.663.653.653.653.643.633.633.623.623.613.623.613.63.63.593.583.593.583.583.573.563.563.563.553.563.553.543.553.543.543.533.513.523.513.513.53.513.513.53.53.513.53.53.53.53.513.513.513.523.523.533.543.553.553.563.573.573.583.593.63.63.613.613.623.633.633.643.643.653.653.643.643.643.643.643.653.643.653.643.643.643.643.643.643.643.643.643.643.643.643.643.643.633.633.643.643.643.633.633.633.633.633.633.633.623.633.633.623.623.623.623.623.613.623.623.613.613.613.613.613.613.63.613.613.63.63.63.63.63.63.593.63.63.593.593.593.593.593.583.593.593.583.583.583.573.573.573.573.573.573.563.563.553.553.553.553.543.553.543.543.543.543.533.533.523.533.523.523.523.523.523.523.513.513.513.513.513.513.513.53.53.53.53.493.53.493.493.493.493.493.493.483.483.483.483.483.483.483.483.473.473.473.473.473.473.473.473.473.473.463.473.463.463.463.463.463.463.463.463.453.453.453.443.443.443.433.433.433.433.423.423.423.423.413.413.413.413.413.413.43.43.43.43.393.393.393.393.393.383.383.393.383.383.383.383.383.383.383.383.383.383.383.373.373.373.373.373.373.373.373.373.373.373.363.363.363.353.353.353.353.343.343.343.343.343.333.333.333.333.333.333.333.333.333.323.323.323.323.313.323.313.313.313.313.313.313.33.33.33.33.33.33.33.33.33.293.293.293.293.283.283.283.283.283.283.283.283.273.273.273.273.273.273.263.263.263.263.273.273.273.273.283.283.283.293.293.33.33.33.33.313.313.323.323.333.333.333.343.343.343.343.353.353.353.363.363.373.373.383.383.383.393.393.43.43.43.43.413.413.413.423.423.423.423.433.433.433.443.443.443.453.453.453.463.463.463.463.473.473.473.473.473.483.483.483.493.493.493.53.53.53.513.513.513.513.523.523.523.523.533.533.533.543.543.543.553.553.553.553.563.563.563.573.573.583.583.593.59Tooltip
Blender 2.79 - Blender 2.79 BMW27 CPU *
min: 786     avg: 796     median: 795.5 (6%)     max: 805 Seconds
R Benchmark 2.5 - R Benchmark 2.5 *
0.8 sec (17%)
3DMark 11 - 3DM11 Performance Physics
min: 5150     avg: 5781     median: 5781 (21%)     max: 6412 Points
3DMark - 3DMark Ice Storm Physics
43514 Points (28%)
3DMark - 3DMark Cloud Gate Physics
min: 5629     avg: 5860     median: 5859.5 (15%)     max: 6090 Points
3DMark - 3DMark Fire Strike Standard Physics
min: 8547     avg: 8809     median: 8808.5 (22%)     max: 9070 Points
3DMark - 3DMark Time Spy CPU
min: 2595     avg: 2638     median: 2638 (18%)     max: 2681 Points
Geekbench 4.1 - 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
3820 points (48%)
Geekbench 4.1 - 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
10419 points (16%)
Geekbench 5.3 - Geekbench 5.1 - 5.3 64 Bit Single-Core
863 points (46%)
Geekbench 5.3 - Geekbench 5.1 - 5.3 64 Bit Multi-Core
2824 points (17%)
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
min: 1097     avg: 1211     median: 1211.1 (2%)     max: 1325.1 ms
Octane V2 - Octane V2 Total Score
min: 27185     avg: 27437     median: 27437 (41%)     max: 27689 Points
WebXPRT 3 - WebXPRT 3 Score
142 Points (48%)
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

v1.16

Reviews for the AMD Picasso (Ryzen 3000 APU) R5 PRO 3500U processor

Lenovo Ideapad S145-15API-81UT001 (AMD Vega 8, 15.60")
» Lenovo Ideapad S145-15API-81UT001 - External Review

Lenovo ThinkPad T495-20NKS01Y00 (AMD Vega 8, 14.00")
» 联想ThinkPad T495笔记本电脑评测:配备AMD处理器的商务本,屏幕续航双升级 - Review
» Lenovo ThinkPad T495-20NKS01Y00 - External Review

»移动处理器 对比
所有移动处理器的对比


»移动处理器 基准测试
所有已有笔记本电脑中使用的处理器的基准测试成绩 (桌面处理器或移动处理器)
