Intel Core i7-7Y75

Intel i7-7Y75

英特尔酷睿i7-7Y75是基于对Kaby Lake架构的高能效平板电脑和被动冷却的笔记本双核处理器,在2016年8月底公布。该处理器提供两个主频为 1.3-3.6 GHz的处理核心(2核Turbo加速频率尚未公布)。由于支持超线程技术,这款处理器可以同时执行多达四个线程。该芯片还集成了英特尔高清显卡615,双通道内存控制器(DDR3L / LPDDR3)以及VP9和H.265视频解码编码器。它仍然采用14纳米FinFET工艺生产。

架构

英特尔基本上采用与Skylake处理器相同的架构设计,因此单位频率性能应该变化很小。只有Speed-Shift技术的电压和时钟速度的动态调整得到了改进,采用更成熟的14纳米工艺制造,使得它可以实现更高的频率和比以前更高的功效。

性能

尽管改变了名称,酷睿i7-7Y75的前身是酷睿m7-6Y75(SKYLAKE微架构的Y系列),因此这颗处理器由于热设计功率较低性能低于其他的酷睿i处理器。由于其较高的Turbo加速频率,7Y75有时可以达到接近15瓦处理器的短期高负荷和单线程性能表现,但在持续负载中时钟频率将明显下降。该处理器仍然适用于要求苛刻的应用以及多任务处理。

图形

这款处理器中集成的英特尔高清显卡615具备和前代高清显卡515一样的24个执行单元(EU),主频300到1050MHz。它的性能很大程度上取决于热设计功率限制以及内存配置,使用高速双通道LPDDR3-1866内存,这块显卡在一些情况下可以与高清显卡520竞争,但也可能在其他情况下慢得多。2016年的最新游戏将只能在最低设置下运行。

与Skylake不同的是Kaby Lake现在支持硬件解码10 位色深的H.265/HEVC Main 10视频,同时支持谷歌VP9编码。

功耗

该芯片采用14纳米制程FinFET工艺制造,这进一步提高了它的能效。Y系列的芯片的常见热设计功率是4.5瓦,并且可以根据使用情况不同动态提高或降低。

SeriesIntel Kaby Lake
CodenameKaby Lake
Series: Kaby Lake Kaby Lake
Intel Core i7-7700K4.2 - 4.5 GHz4 / 88 MB
Intel Core i7-77003.6 - 4.2 GHz4 / 88 MB
Intel Xeon E3-1535M v63.1 - 4.2 GHz4 / 88 MB
Intel Core i7-7920HQ3.1 - 4.1 GHz4 / 88 MB
Intel Core i7-7700T2.9 - 3.8 GHz4 / 88 MB
Intel Core i5-7600K3.8 - 4.2 GHz4 / 48 MB
Intel Xeon E3-1505M v63 - 4 GHz4 / 88 MB
Intel Core i7-7820HQ2.9 - 3.9 GHz4 / 88 MB
Intel Core i7-7820HK2.9 - 3.9 GHz4 / 88 MB
Intel Core i7-7700HQ2.8 - 3.8 GHz4 / 86 MB
Intel Core i5-75003.4 - 3.8 GHz4 / 46 MB
Intel Core i5-7440HQ2.8 - 3.8 GHz4 / 46 MB
Intel Core i7-7567U3.5 - 4 GHz2 / 44 MB
Intel Core i7-7660U2.5 - 4 GHz2 / 44 MB
Intel Core i7-7600U2.8 - 3.9 GHz2 / 44 MB
Intel Core i5-7300HQ2.5 - 3.5 GHz4 / 46 MB
Intel Core i5-7500T2.7 - 3.3 GHz4 / 46 MB
Intel Core i5-7287U3.3 - 3.7 GHz2 / 44 MB
Intel Core i7-7560U2.4 - 3.8 GHz2 / 44 MB
Intel Core i5-7267U3.1 - 3.5 GHz2 / 44 MB
Intel Core i5-7360U2.3 - 3.6 GHz2 / 44 MB
Intel Core i7-7500U2.7 - 3.5 GHz2 / 44 MB
Intel Core i5-7300U2.6 - 3.5 GHz2 / 43 MB
Intel Core i5-7260U2.2 - 3.4 GHz2 / 44 MB
Intel Core i5-7200U2.5 - 3.1 GHz2 / 43 MB
Intel Core i3-7100H3 GHz2 / 43 MB
Intel Core i3-7167U2.8 GHz2 / 43 MB
Intel Core i3-7130U2.7 GHz2 / 43 MB
» Intel Core i7-7Y751.3 - 3.6 GHz2 / 44 MB
Intel Core i5-7Y571.2 - 3.3 GHz2 / 44 MB
Intel Core i5-7Y541.2 - 3.2 GHz2 / 44 MB
Intel Core i3-7100U2.4 GHz2 / 43 MB
Intel Core m3-7Y321 - 3 GHz2 / 44 MB
Intel Pentium Gold 4415U2.3 GHz2 / 42 MB
Intel Core m3-7Y301 - 2.6 GHz2 / 44 MB
Intel Celeron 3965U2.2 GHz2 / 22 MB
Intel Core i3-7020U2.3 GHz2 / 43 MB
Intel Celeron 3867U1.8 GHz2 / 22 MB
Intel Celeron 3865U1.8 GHz2 / 22 MB
Intel Pentium Gold 4425Y1.7 GHz2 / 42 MB
Intel Pentium Gold 4415Y1.6 GHz2 / 42 MB
Intel Pentium Gold 4410Y1.5 GHz2 / 42 MB
Intel Celeron 3965Y1.5 GHz2 / 22 MB
Clock Rate1300 - 3600 MHz
Level 1 Cache128 KB
Level 2 Cache512 KB
Level 3 Cache4 MB
Number of Cores / Threads2 / 4
Power Consumption (TDP = Thermal Design Power)4.5 Watt
Manufacturing Technology14 nm
Max. Temperature100 °C
SocketBGA
FeaturesDual-Channel DDR3L-1600/LPDDR3-1866 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI, vPro, TXT
GPUIntel HD Graphics 615 (300 - 1050 MHz)
64 Bit64 Bit support
Architecturex86
Starting Price$393 U.S.
Announcement Date08/30/2016
Product Link (external)Intel Kaby Lake i7-7Y75

Benchmarks

Performance Rating - CB R15 + R20 + 7-Zip + X265 + Blender + 3DM11 CPU
29.6 pt (34%)
AMD E1-2100 -88%
...
AMD 3020e -22%
AMD Athlon Silver 3050e -19%
Intel Core i5-4258U -8%
Intel Core i5-8210Y -1%
Intel Core i7-7Y75
Intel Core i7-8500Y 3%
AMD FX-8350 4%
AMD Ryzen 3 3300U 6%
AMD Ryzen 3 1200 10%
Intel Core i7-2860QM 10%
Intel Core i5-6287U 10%
Intel Core i7-6567U 11%
...
AMD Ryzen Threadripper PRO 3995WX 196%
0%
100%
Cinebench R23 - Cinebench R23 CPU (Multi Core)
1390 Points (2%)
Cinebench R23 - Cinebench R23 CPU (Single Core)
721 Points (43%)
Cinebench R20 - Cinebench R20 CPU (Single Core)
min: 202     avg: 235     median: 234.5 (36%)     max: 267 Points
Cinebench R20 - Cinebench R20 CPU (Multi Core)
min: 482     avg: 494     median: 493.5 (2%)     max: 505 Points
Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 236     avg: 251     median: 258 (3%)     max: 260 Points
0153045607590105120135150165180195210225240255235.62229.44230.3229.22230.15229.76228.6229.37229.55228.89229.39227.93229.04229.22228.21229.22229.91229.4229.33228.65259.23258.44257.9256.76254.79253.49253.97254.35253.97252.91252.5250.61252.21251.6250.79251.17248.89250.83251.13250.26250.64249.66250.03248.92248.24250.29248.62248.62248.43247.51248.42248.1246.58249.87248.05249.47248.29249.4249.51247.7248.47247.81246.67247.88247.36246.34246.71247.11246.34246.96247.17248.18248.34248.5246.59Tooltip
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 121     avg: 126     median: 126 (46%)     max: 130 Points
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 2.87     avg: 2.9     median: 2.9 (5%)     max: 2.98 Points
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 1.44     avg: 1.5     median: 1.5 (47%)     max: 1.54 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
5496 points (49%)
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
9392 points (15%)
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
11682 Points (11%)
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
6449 Points (46%)
wPrime 2.10 - wPrime 2.0 1024m *
619 s (7%)
wPrime 2.10 - wPrime 2.0 32m *
17.4 s (4%)
7-Zip 18.03 - 7-Zip 18.03 Multli Thread 4 runs
9657 MIPS (7%)
7-Zip 18.03 - 7-Zip 18.03 Single Thread 4 runs
4617 MIPS (66%)
X264 HD Benchmark 4.0 - x264 Pass 2
16 fps (7%)
X264 HD Benchmark 4.0 - x264 Pass 1
91.2 fps (27%)
HWBOT x265 Benchmark v2.2 - HWBOT x265 4k Preset
2 fps (4%)
TrueCrypt - TrueCrypt Serpent
0.2 GB/s (9%)
TrueCrypt - TrueCrypt Twofish
0.3 GB/s (9%)
TrueCrypt - TrueCrypt AES
2 GB/s (7%)
Blender 2.79 - Blender 2.79 BMW27 CPU *
1921 Seconds (14%)
R Benchmark 2.5 - R Benchmark 2.5 *
0.9 sec (20%)
3DMark 06 - CPU - 3DMark 06 - CPU
3309 Points (18%)
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
10.7 s (2%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
24.5 s (1%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
585 s (3%)
3DMark 11 - 3DM11 Performance Physics
min: 3347     avg: 3582     median: 3688 (13%)     max: 3710 Points
3DMark - 3DMark Ice Storm Physics
min: 34113     avg: 34681     median: 34680.5 (22%)     max: 35248 Points
3DMark - 3DMark Ice Storm Extreme Physics
min: 31394     avg: 32948     median: 32948 (35%)     max: 34502 Points
3DMark - 3DMark Ice Storm Unlimited Physics
min: 35750     avg: 40104     median: 37884 (39%)     max: 46679 Points
3DMark - 3DMark Cloud Gate Physics
min: 2706     avg: 2924     median: 2994 (8%)     max: 3072 Points
3DMark - 3DMark Fire Strike Standard Physics
min: 3838     avg: 4174     median: 4289 (11%)     max: 4395 Points
3DMark - 3DMark Time Spy CPU
1387 Points (10%)
Geekbench 5.0 - Geekbench 5.0 64 Bit Single-Core
864 points (46%)
Geekbench 5.0 - Geekbench 5.0 64 Bit Multi-Core
1393 points (4%)
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
min: 1142     avg: 1305     median: 1305.1 (2%)     max: 1468.2 ms
Sunspider - Sunspider 1.0 Total Score *
89.4 ms (1%)
Octane V2 - Octane V2 Total Score
min: 22300     avg: 24506     median: 24506 (35%)     max: 26712 Points
WebXPRT 3 - WebXPRT 3 Score
min: 110     avg: 127     median: 127 (43%)     max: 144 Points
Power Consumption - Prime95 Power Consumption - external Monitor *
18.5 Watt (5%)
Power Consumption - Cinebench R15 Multi Power Consumption - external Monitor *
17.9 Watt (5%)
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
