Intel Core m3-7Y30

Intel 7Y30

英特尔酷睿m3-7Y30是基于对Kaby Lake架构的高能效平板电脑和被动冷却的笔记本双核处理器,在2016年8月底公布。该处理器提供两个主频为1.0-2.6GHz的处理核心(2核Turbo加速频率尚未公布)。由于支持超线程技术,这款处理器可以同时执行多达四个线程。该芯片还集成了英特尔高清显卡615,双通道内存控制器(DDR3L / LPDDR3)以及VP9和H.265视频解码编码器。它仍然采用14纳米FinFET工艺生产。

架构

英特尔基本上采用与Skylake处理器相同的架构设计,因此单位频率性能应该变化很小。只有Speed-Shift技术的电压和时钟速度的动态调整得到了改进,采用更成熟的14纳米工艺制造,使得它可以实现更高的频率和比以前更高的功效。

性能

由于英特尔停止了酷睿m5和m7系列的进一步开发,将它们并入更高的i5和i7系列,因此m3-7Y30是酷睿m系列的最后一个正式芯片。由于其较高的Turbo加速频率,7Y30有时可以达到接近15瓦处理器的短期高负荷和单线程性能表现,但在持续负载中时钟频率将明显下降。该处理器仍然适用于要求苛刻的应用以及多任务处理。由于功效提高,这颗处理器甚至优于上一代SKYLAKE微架构酷睿M5和M7处理器。

图形

这款处理器中集成的英特尔高清显卡615具备和前代高清显卡515一样的24个执行单元(EU),主频300到900MHz。它的性能很大程度上取决于热设计功率限制以及内存配置,使用高速双通道LPDDR3-1866内存,这块显卡在一些情况下可以与高清显卡520竞争,但也可能在其他情况下慢得多。2016年的最新游戏将只能在最低设置下运行。

与Skylake不同的是Kaby Lake现在支持硬件解码10 位色深的H.265/HEVC Main 10视频,同时支持谷歌VP9编码。

功耗

该芯片采用14纳米制程FinFET工艺制造,这进一步提高了它的能效。Y系列的芯片的常见热设计功率是4.5瓦,并且可以根据使用情况不同动态提高或降低。

SeriesIntel Core m3
CodenameKaby Lake
Series: Core m3 Kaby Lake
Intel Core m3-7Y321000 - 3000 MHz2 / 44 MB
» Intel Core m3-7Y301000 - 2600 MHz2 / 44 MB
Clock Rate1000 - 2600 MHz
Level 1 Cache128 KB
Level 2 Cache512 KB
Level 3 Cache4 MB
Number of Cores / Threads2 / 4
Max. Power Consumption (TDP = Thermal Design Power)4.5 Watt
Manufacturing Technology14 nm
Max. Temperature100 °C
SocketBGA
FeaturesDual-Channel DDR3L-1600/LPDDR3-1866 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI, TXT
GPUIntel HD Graphics 615 (300 - 900 MHz)
64 Bit64 Bit support
Starting Price$281 U.S.
Announcement Date08/30/2016
Product Link (external)Intel Core m3 7Y30

Benchmarks

Cinebench R15 - CPU Multi 64Bit
min: 226     avg: 244.7     median: 250 (8%)     max: 258 Points
Cinebench R15 - CPU Single 64Bit
min: 103     avg: 105.3     median: 105 (51%)     max: 108 Points
Cinebench R11.5 - CPU Multi 64Bit
min: 2.67     avg: 2.8     median: 2.8 (12%)     max: 2.85 Points
Cinebench R11.5 - CPU Single 64Bit
min: 1.23     avg: 1.2     median: 1.2 (53%)     max: 1.24 Points
Cinebench R10 - Rendering Single 32Bit
min: 4071     avg: 4086     median: 4086 (49%)     max: 4101 Points
Cinebench R10 - Rendering Multiple CPUs 32Bit
min: 8431     avg: 8638.5     median: 8638.5 (17%)     max: 8846 Points
Cinebench R10 - Rendering Multiple CPUs 64Bit
min: 9764     avg: 10514     median: 10514 (15%)     max: 11264 Points
Cinebench R10 - Rendering Single CPUs 64Bit
min: 5253     avg: 5269.5     median: 5269.5 (58%)     max: 5286 Points
wPrime 2.0x - 1024m *
691.7 seconds (8%)
wPrime 2.0x - 32m *
20.2 seconds (4%)
WinRAR - Result
1255 KB/s (15%)
X264 HD Benchmark 4.0 - Pass 2
15.6 fps (12%)
X264 HD Benchmark 4.0 - Pass 1
85.3 fps (36%)
TrueCrypt - Serpent Mean 100MB
0.2 GB/s (0%)
TrueCrypt - Twofish Mean 100MB
0.3 GB/s (0%)
TrueCrypt - AES Mean 100MB
1.5 GB/s (8%)
3DMark 06 - CPU
min: 3405     avg: 3406.5     median: 3406.5 (27%)     max: 3408 Points
Super Pi mod 1.5 XS 1M *
14.7 Seconds (3%)
Super Pi mod 1.5 XS 2M *
33.4 Seconds (1%)
Super Pi Mod 1.5 XS 32M *
718.9 Seconds (3%)
3DMark 11 - Performance Physics 1280x720
min: 3611     avg: 3615.5     median: 3615.5 (20%)     max: 3620 points
3DMark - Ice Storm Standard Physics 1280x720
31762 Points (20%)
3DMark - Ice Storm Extreme Physics 1920x1080
min: 29788     avg: 30302.5     median: 30302.5 (39%)     max: 30817 Points
3DMark - Ice Storm Unlimited Physics 1280x720 offscreen
min: 33164     avg: 33771     median: 33229 (42%)     max: 34920 Points
3DMark - Cloud Gate Standard Physics 1280x720
min: 2550     avg: 2691     median: 2744 (7%)     max: 2779 Points
3DMark - Fire Strike Physics 1920x1080
min: 3727     avg: 3847.3     median: 3866 (15%)     max: 3949 Points
Geekbench 3 - 32 Bit Multi-Core Score
5006 Points (16%)
Geekbench 3 - 32 Bit Single-Core Score
2538 Points (54%)
Geekbench 3 - 64 Bit Multi-Core Score
5526 Points (15%)
Geekbench 3 - 64 Bit Single-Core Score
2538 Points (52%)
Mozilla Kraken 1.1 - Total Score *
min: 1414.1     avg: 1421.1     median: 1421.1 (2%)     max: 1428 ms
Octane V2 - Total Score
min: 23605     avg: 24813     median: 24813 (51%)     max: 26021 Points
Power Consumption - Prime95 V28,10 Stress Power Consumption (external Monitor) ultra *
16.7 Watt (7%)
Power Consumption - Cinebench R15 Multi Power Consumption (external Monitor) ultra *
15.7 Watt (6%)
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

v1.8
