AMD A6-9225

AMD A6-9225

AMD A6-9225是Stoney-Ridge APU系列笔记本电脑的入门级芯片(第7代APU),于2018年中期发布。与2年以前的A4-9220相比,A4-9225提供更高的CPU频率。它集成了两个频率2.6-3 GHz的CPU内核(一个带有2个整数且位于FP单元上的Excavator模块)。它还包括一个Radeon R4 GPU,频率655 MHz,具有192个着色器,以及一个单通道DDR4-2133存储器控制器,H.265视频引擎和具有所有I / O端口的芯片组。

建筑

Stoney Ridge是Carrizo架构的后继者,设计几乎相同。但是,由于优化了制造工艺和更激进的睿频,在相同功耗下,频率要高一些。内存控制器现在还支持DDR4,最高可达2133 MHz。 Stoney Ridge是较小的双核和单核芯片的名称,而Bristol Ridge是具有双通道内存控制器的较大的四核芯片。以下文章提供了更多技术细节:

AMD的Bristol Ridge和Stoney Ridge体系结构

AMD:Bristol Ridge APU发布

性能

由于时钟范围明显较低,因此A6-9225应该比A9-9410慢得多。因此,它处于2018年移动CPU的绝对低端,仅适合基本任务。

显示卡

集成的R​​adeon R4(Stoney Ridge)GPU具有192个活动着色器单元(3个计算内核)的R5类似,但是频率降至655,而不是800 MHz。有关GPU的更多详细信息,请参见上面的链接文章。

能耗

AMD指定A6-9225的TDP为15瓦,但可以将其配置为10-15瓦。这意味着APU是轻薄笔记本电脑的不错选择。

SeriesAMD Bristol Ridge
CodenameStoney Ridge
Series: Bristol Ridge Stoney Ridge
AMD A9-94253100 - 3700 MHz2 / 2
AMD A9-9420e - 2500? MHz2 / 2
AMD A9-94203000 - 3600 MHz2 / 2
AMD A9-94102900 - 3500 MHz2 / 2
» AMD A6-92252600 - 3000 MHz2 / 2
AMD A6-92202500 - 2900 MHz2 / 2
AMD A6-9220C1800 - 2700 MHz2 / 2
AMD A6-92102400 - 2800 MHz2 / 2
AMD A4-91202200 - 2500 MHz2 / 2
AMD A4-9120C1600 - 2400 MHz2 / 2
AMD E2-90102000 - 2200 MHz2 / 2
AMD E2-90001800 - 2200 MHz2 / 2
AMD A6-9220e1600 - 2400 MHz2 / 2
Clock Rate2600 - 3000 MHz
Level 1 Cache160 KB
Level 2 Cache1 MB
Number of Cores / Threads2 / 2
Max. Power Consumption (TDP = Thermal Design Power)10-15 Watt
Transistor Count1200 Million
Manufacturing Technology28 nm
Die Size124.5 mm2
Max. Temperature90 °C
SocketBGA
FeaturesSingle-Channel DDR4-2133, Virtualization,
GPUAMD Radeon R4 (Stoney Ridge) ( - 655 MHz)
64 Bit64 Bit support
Announcement Date06/01/2018

Benchmarks

Cinebench R20 - CPU (Single Core)
182 Points (35%)
Cinebench R20 - CPU (Multi Core)
273 Points (3%)
Cinebench R15 - CPU Multi 64Bit
min: 96     avg: 109     median: 108.5 (2%)     max: 121 Points
Cinebench R15 - CPU Single 64Bit
73 Points (33%)
Cinebench R11.5 - CPU Multi 64Bit
min: 1.03     avg: 1.2     median: 1.2 (3%)     max: 1.44 Points
Cinebench R11.5 - CPU Single 64Bit
0.9 Points (35%)
Cinebench R10 - Rendering Single 32Bit
2532 Points (26%)
Cinebench R10 - Rendering Multiple CPUs 32Bit
4193 Points (7%)
wPrime 2.0x - 1024m *
852 seconds (10%)
wPrime 2.0x - 32m *
26.3 seconds (5%)
WinRAR - Result
852 KB/s (10%)
X264 HD Benchmark 4.0 - Pass 2
9.1 fps (6%)
X264 HD Benchmark 4.0 - Pass 1
48.9 fps (17%)
TrueCrypt - Serpent Mean 100MB
0.1 GB/s (6%)
TrueCrypt - Twofish Mean 100MB
0.2 GB/s (0%)
TrueCrypt - AES Mean 100MB
1 GB/s (5%)
3DMark 06 - CPU
2132 Points (14%)
Super Pi mod 1.5 XS 1M *
20.2 Seconds (4%)
Super Pi mod 1.5 XS 2M *
45.5 Seconds (2%)
Super Pi Mod 1.5 XS 32M *
968 Seconds (4%)
3DMark 11 - Performance Physics 1280x720
1568 points (8%)
3DMark - Ice Storm Standard Physics 1280x720
16446 Points (11%)
3DMark - Ice Storm Extreme Physics 1920x1080
15678 Points (19%)
3DMark - Ice Storm Unlimited Physics 1280x720 offscreen
16322 Points (19%)
3DMark - Cloud Gate Standard Physics 1280x720
1304 Points (3%)
3DMark - Fire Strike Physics 1920x1080
1821 Points (6%)
Geekbench 2 - 32 Bit - Stream
3899 Points (31%)
Geekbench 2 - 32 Bit - Memory
2849 Points (26%)
Geekbench 2 - 32 Bit - Floating Point
4490 Points (9%)
Geekbench 2 - 32 Bit - Integer
4014 Points (8%)
Geekbench 2 - 32 Bit - Total Score
3936 Points (10%)
Geekbench 3 - 32 Bit Multi-Core Score
3103 Points (6%)
Geekbench 3 - 32 Bit Single-Core Score
1855 Points (38%)
Geekbench 3 - 64 Bit Multi-Core Score
3323 Points (5%)
Geekbench 3 - 64 Bit Single-Core Score
1974 Points (40%)
Geekbench 4.0 - 64 Bit Single-Core Score
1920 Points (30%)
Geekbench 4.0 - 64 Bit Multi-Core Score
3035 Points (8%)
Geekbench 4.4 - 64 Bit Single-Core Score
1980 Points (31%)
Geekbench 4.4 - 64 Bit Multi-Core Score
3190 Points (6%)
Mozilla Kraken 1.1 - Total Score *
2657 ms (4%)
Sunspider - 1.0 Total Score *
204 ms (2%)
Octane V2 - Total Score
11962 Points (23%)
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

v1.10

Reviews for the AMD Bristol Ridge A6-9225 processor

HP 255 G6-4LT47ES (AMD Radeon R4 (Stoney Ridge), 15.6")
» HP 255 G6-4LT47ES - External Review

Lenovo Ideapad S145-15AST-81N30042GE (AMD Radeon R4 (Stoney Ridge), 15.6")
» Lenovo Ideapad S145-15AST-81N30042GE - External Review

»移动处理器 对比
所有移动处理器的对比


»移动处理器 基准测试
所有已有笔记本电脑中使用的处理器的基准测试成绩 (桌面处理器或移动处理器)

Other CPUs of the series AMD Bristol Ridge

» AMD Bristol Ridge FX-9830P
   3 GHz / 2 MB L2
» AMD Bristol Ridge PRO A12-9830B
   3 GHz / 2 MB L2
» AMD Bristol Ridge FX-9800P
   2.7 GHz / 2 MB L2
» AMD Bristol Ridge PRO A12-9800B
   2.7 GHz / 2 MB L2
» AMD Bristol Ridge A12-9720P
   2.7 GHz / 2 MB L2
» AMD Bristol Ridge A12-9700P
   2.5 GHz / 2 MB L2
» AMD Bristol Ridge A10-9620P
   2.5 GHz / 2 MB L2
» AMD Bristol Ridge A10-9600P
   2.4 GHz / 2 MB L2
» AMD Bristol Ridge A8-9600B
   2.4 GHz / 2 MB L2
» AMD Bristol Ridge A9-9425
   3.1 GHz / 1 MB L2
» AMD Bristol Ridge A9-9420
   3 GHz / 1 MB L2
» AMD Bristol Ridge A9-9410
   2.9 GHz / 1 MB L2
» AMD Bristol Ridge A6-9225
   2.6 GHz / 1 MB L2
» AMD Bristol Ridge A6-9220
   2.5 GHz / 1 MB L2
» AMD Bristol Ridge A6-9220C
   1.8 GHz / 1 MB L2
» AMD Bristol Ridge A6-9210
   2.4 GHz
» AMD Bristol Ridge A4-9120
   2.2 GHz / 1 MB L2
» AMD Bristol Ridge A4-9120C
   1.6 GHz / 1 MB L2
» AMD Bristol Ridge E2-9010
   2 GHz / 1 MB L2
» AMD Bristol Ridge E2-9000
   1.8 GHz / 1 MB L2
» AMD Bristol Ridge A6-9220e
   1.6 GHz / 1 MB L2

Surrounding CPUs

- Kirin 950
   2.3 GHz / 0 MB
- Samsung Exynos Exynos 9609
   1.6 GHz / 0 MB
- AMD A-Series A4-7210
   1.8 GHz / 2 MB
- AMD A-Series A6-3430MX
   1.7 GHz / 4 MB
- Intel Pentium 3558U
   1.7 GHz / 0.5 MB + 2 MB
» AMD Bristol Ridge A6-9225
   2.6 GHz / 1 MB L2
+ AMD Bristol Ridge A6-9220
   2.5 GHz / 1024 KB
+ AMD Bristol Ridge A6-9220C
   1.8 GHz / 1024 KB
+ Intel Pentium 3556U
   1.7 GHz / 512 KB + 2048 KB
+ Intel Pentium 2117U
   1.8 GHz / 512 KB + 2048 KB
+ Intel Celeron 1000M
   1.8 GHz / 512 KB + 2048 KB
