Intel Core i3-6006U

Intel 6006U

英特尔酷睿i3-6006U是一颗ULV(超低电压)双核处理器,基于Skylake架构,在2016年11月正式推出。这台处理器常用于轻薄笔记本电脑中。

 除了两个支持超线程的CPU核心运行于(相对较低的)2.0 GHz(不支持Turbo Boost加速),该芯片还集成了HD Graphics 520显卡(仅900MHz)及双通道DDR4- 2133 / DDR3L-1600内存控制器。该芯片采用14纳米工艺与FinFET晶体管制造工艺。

架构

Skylake架构取代了Haswell和Broadwell,为从4.5到45瓦热设计功率的处理器都提供了相同的微架构。Skylake架构设计的众多改进包括增加了乱序缓冲,优化的预取和分支预测以及超线程模式的性能改进。不过整体上,它的单位时钟频率性能仅增加了5%到10%(相比Haswell)而相比Broadwell架构不足5%,这对于一个新架构(“Tock”)来说十分低。

性能

根据时钟速率和改进的架构,酷睿i7-6006U相比Broadwell架构酷睿i3-5005U稍强。因此,这颗处理器的性能足以满足办公和多媒体用途的需要,也可以胜任较复杂的应用程序和多任务处理。

图形

它的集成显示单元名为HD Graphics 520,代表了Skylake显卡的"GT2"版本(Intel第九代)。它的24个执行单元,也被称为EU,主频在300-900 MHz之间,提供的性能相当于GeForce 820M独立显卡。2015年的游戏应该可以在低设置下流畅运行。有关性能和功能的详细信息,请参考我们的HD Graphics 520页面。i3-6006U中运行频率900 MHz的高清显卡520是同型号集成显卡中最慢的变型(酷睿i7处理器最高达1050MHz)

功耗

设计热设计功率15瓦(包括CPU,GPU和内存控制器),这款处理器最适合于小型笔记本电脑和超极本(11寸或更大)。它的TDP也可以降低到7.5瓦(cTDP降低),从而同时降低发热量和性能,让更加紧凑的设计成为可能。

SeriesIntel Core i3
CodenameSkylake
Series: Core i3 Skylake
Intel Core i3-6167U2700 MHz2 / 43 MB
Intel Core i3-6100H2700 MHz2 / 43 MB
Intel Core i3-6157U2400 MHz2 / 43 MB
Intel Core i3-6100U2300 MHz2 / 43 MB
» Intel Core i3-6006U2000 MHz2 / 43 MB
Clock Rate2000 MHz
Level 1 Cache128 KB
Level 2 Cache512 KB
Level 3 Cache3 MB
Number of Cores / Threads2 / 4
Max. Power Consumption (TDP = Thermal Design Power)15 Watt
Manufacturing Technology14 nm
Die Size99 mm2
Max. Temperature100 °C
SocketBGA
FeaturesDual-Channel DDR3L-1600/DDR4-2133 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI
GPUIntel HD Graphics 520 (300 - 900 MHz)
64 Bit64 Bit support
Starting Price$281 U.S.
Announcement Date11/11/2016
Product Link (external)Intel Core i3 6006U

Benchmarks

Cinebench R15 - CPU Multi 64Bit
min: 154     avg: 200.3     median: 214 (5%)     max: 218 Points
Cinebench R15 - CPU Single 64Bit
min: 69     avg: 80     median: 83 (38%)     max: 84 Points
Cinebench R11.5 - CPU Multi 64Bit
2.4 Points (9%)
Cinebench R11.5 - CPU Single 64Bit
1 Points (48%)
Cinebench R10 - Rendering Single 32Bit
min: 3203     avg: 3222     median: 3227 (35%)     max: 3236 Points
Cinebench R10 - Rendering Multiple CPUs 32Bit
min: 7293     avg: 7348.3     median: 7364 (15%)     max: 7388 Points
wPrime 2.0x - 1024m *
767.7 seconds (9%)
wPrime 2.0x - 32m *
24.3 seconds (5%)
WinRAR - Result
1808 KB/s (21%)
X264 HD Benchmark 4.0 - Pass 2
14.1 fps (0%)
X264 HD Benchmark 4.0 - Pass 1
74.5 fps (28%)
TrueCrypt - Serpent Mean 100MB
0.1 GB/s (12%)
TrueCrypt - Twofish Mean 100MB
0.2 GB/s (7%)
TrueCrypt - AES Mean 100MB
1.2 GB/s (6%)
Super Pi mod 1.5 XS 1M *
18.8 Seconds (4%)
Super Pi mod 1.5 XS 2M *
42.3 Seconds (2%)
Super Pi Mod 1.5 XS 32M *
952 Seconds (4%)
3DMark 11 - Performance Physics 1280x720
min: 2837     avg: 2919.5     median: 2903 (16%)     max: 3034 points
3DMark - Ice Storm Unlimited Physics 1280x720 offscreen
27981 Points (32%)
3DMark - Cloud Gate Standard Physics 1280x720
2258 Points (6%)
3DMark - Fire Strike Physics 1920x1080
3220 Points (12%)
Geekbench 2 - 32 Bit - Stream
4835 Points (39%)
Geekbench 2 - 32 Bit - Memory
4572 Points (41%)
Geekbench 2 - 32 Bit - Floating Point
4402 Points (13%)
Geekbench 2 - 32 Bit - Integer
4464 Points (14%)
Geekbench 2 - 32 Bit - Total Score
4501 Points (17%)
Geekbench 3 - 32 Bit Multi-Core Score
min: 4265     avg: 4354.7     median: 4384 (14%)     max: 4415 Points
Geekbench 3 - 32 Bit Single-Core Score
min: 1943     avg: 1991     median: 2012 (42%)     max: 2018 Points
Geekbench 3 - 64 Bit Multi-Core Score
4435 Points (12%)
Geekbench 3 - 64 Bit Single-Core Score
2054 Points (42%)
Geekbench 4.0 - Compute OpenCL Score
min: 13454     avg: 14437     median: 14916 (5%)     max: 14941 Points
Geekbench 4.0 - 64 Bit Multi-Core Score
min: 4723     avg: 4814     median: 4805 (17%)     max: 4914 Points
Geekbench 4.0 - 64 Bit Single-Core Score
min: 2468     avg: 2525.7     median: 2516 (44%)     max: 2593 Points
Geekbench 4.3 - 64 Bit Single-Core Score
min: 2575     avg: 2607     median: 2607 (41%)     max: 2639 Points
Geekbench 4.3 - 64 Bit Multi-Core Score
min: 4975     avg: 5042     median: 5042 (14%)     max: 5109 Points
Mozilla Kraken 1.1 - Total Score *
min: 1734     avg: 1758.5     median: 1743 (3%)     max: 1797 ms
Sunspider - 1.0 Total Score *
min: 135     avg: 239.6     median: 147 (2%)     max: 436 ms
Octane V2 - Total Score
min: 18570     avg: 19275.3     median: 19174 (37%)     max: 20082 Points
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
