Intel Pentium N3710

Intel N3710

英特尔奔腾N3710是面向入门级笔记本电脑,在2016年年初发布的四核处理器。它的主频为1.1  -  2.56 GHz,采用Braswell架构。由于新的14纳米低功耗制程(P1273)与三栅极晶体管技术,它的能效相比前代产品(如奔腾N3520)显著提高。除了处理器内核,它的芯片中还包括了支持DirectX 11.2的显卡以及一个DDR3L内存控制器(2×64位,25.6 GB/s)。

它是2016年奔腾N3700的后续型号,最高主频从2.4GHz提高到了2.56GHz,而基础频率只有1.1GHz(相比1.6 GHz)。它的集成显卡技术参数基本相同,不过现在重命名为英特尔高清显卡405。

架构

处理器核心基于Airmont架构,基本上只是基于以前的Silvermont芯片稍微修改的缩小版。它的单位时钟频率性能并未改进,不过更加高效的14纳米制程让它可以更好地利用处理器加速,提供更高的整体性能。

性能

相比前代型号奔腾N3700,N3710在可以保持最高速度的情况下性能稍高。如果散热效果差,它的性能甚至会更低。

 在我们的第一批测试样本中,N3710和A6-5200在Cinebench R15中的性能相近,略快于N3700。在3DMark 11的物理测试它和N3700表现相同。使用Windows时,这款处理器足以满足日常任务如上网浏览或办公应用的需要,但面对要求较高的软件可能会举步维艰。

图形

英特尔高清显卡405(Braswell)基于Broadwell架构(英特尔第八代)支持DirectX 11.2,也用于其他Broadwell系列处理器(如高清显卡5300)。搭配16个EU,最高频率700MHz,这款显卡相比高清显卡(Bay Trail)几乎快了一倍,不过仍然不足以满足2015年大型3D游戏的需要。该显卡还支持4K / H.265视频加速。

功耗

整个系统芯片的热设计功率为6瓦(SDP 4瓦)。因此这款处理器可采用被动冷却,不过并不是所有设备都适用。

SeriesIntel Pentium
CodenameBraswell
Series: Pentium Braswell
» Intel Pentium N37101600 - 2560 MHz4 / 4
Intel Pentium N37001600 - 2400 MHz4 / 4
Clock Rate1600 - 2560 MHz
Level 2 Cache2 MB
Number of Cores / Threads4 / 4
Max. Power Consumption (TDP = Thermal Design Power)6 Watt
Manufacturing Technology14 nm
Max. Temperature90 °C
SocketFCBGA1170
FeaturesIntel HD Graphics 405 (Braswell, 400 - 700 MHz), Wireless Display, Quick Sync, AES-NI, max. 8 GB Dual-Channel DDR3L-1600 (25,6 GB/s), 5x USB 3.0, 4x PCIe 2.0, 2x SATA 6.0 Gbit/s
GPUIntel HD Graphics 405 (Braswell) (400 - 700 MHz)
64 Bit64 Bit support
Starting Price$161 U.S.
Announcement Date04/01/2016
Product Link (external)Intel Pentium N3710

Benchmarks

Cinebench R15 - CPU Multi 64Bit
min: 105     avg: 139.7     median: 145 (5%)     max: 152 Points
Cinebench R15 - CPU Single 64Bit
min: 39     avg: 40.7     median: 41 (19%)     max: 42 Points
Cinebench R11.5 - CPU Multi 64Bit
min: 1.39     avg: 1.6     median: 1.6 (6%)     max: 1.89 Points
Cinebench R11.5 - CPU Single 64Bit
min: 0.48     avg: 0.5     median: 0.5 (20%)     max: 0.5 Points
Cinebench R10 - Rendering Single 32Bit
min: 1238     avg: 1307.3     median: 1323.5 (14%)     max: 1344 Points
Cinebench R10 - Rendering Multiple CPUs 32Bit
min: 3417     avg: 4369.5     median: 4653 (9%)     max: 4755 Points
wPrime 2.0x - 1024m *
min: 718.266     avg: 725.3     median: 725.3 (9%)     max: 732.26 seconds
wPrime 2.0x - 32m *
min: 22.928     avg: 23.3     median: 23.3 (5%)     max: 23.59 seconds
WinRAR - Result
1004 KB/s (12%)
X264 HD Benchmark 4.0 - Pass 2
10.7 fps (7%)
X264 HD Benchmark 4.0 - Pass 1
52.8 fps (20%)
TrueCrypt - Serpent Mean 100MB
0.1 GB/s (0%)
TrueCrypt - Twofish Mean 100MB
0.2 GB/s (8%)
TrueCrypt - AES Mean 100MB
1 GB/s (5%)
3DMark 06 - CPU
min: 2362     avg: 2473.5     median: 2473.5 (7%)     max: 2585 Points
Super Pi mod 1.5 XS 1M *
min: 34.159     avg: 35     median: 34.9 (8%)     max: 35.74 Seconds
Super Pi mod 1.5 XS 2M *
min: 75.24     avg: 77     median: 77 (3%)     max: 78.72 Seconds
Super Pi Mod 1.5 XS 32M *
min: 1625.54     avg: 1665.8     median: 1665.8 (7%)     max: 1706.02 Seconds
3DMark Vantage - P CPU no PhysX 1280x1024
5320 Points (9%)
3DMark 11 - Performance Physics 1280x720
min: 1574     avg: 1751.2     median: 1742.5 (9%)     max: 1949 points
3DMark - Ice Storm Standard Physics 1280x720
min: 17238     avg: 18207.5     median: 18207.5 (12%)     max: 19177 Points
3DMark - Ice Storm Extreme Physics 1920x1080
min: 12409     avg: 15740.5     median: 15740.5 (20%)     max: 19072 Points
3DMark - Ice Storm Unlimited Physics 1280x720 offscreen
19869 Points (25%)
3DMark - Cloud Gate Standard Physics 1280x720
min: 1400     avg: 1512     median: 1552 (4%)     max: 1584 Points
3DMark - Fire Strike Physics 1920x1080
min: 1957     avg: 2157.5     median: 2157.5 (8%)     max: 2358 Points
Geekbench 3 - 32 Bit Multi-Core Score
min: 3382     avg: 3471.7     median: 3480 (11%)     max: 3553 Points
Geekbench 3 - 32 Bit Single-Core Score
min: 1012     avg: 1018     median: 1019 (22%)     max: 1023 Points
Geekbench 3 - 64 Bit Multi-Core Score
3581 Points (10%)
Geekbench 3 - 64 Bit Single-Core Score
1068 Points (22%)
Geekbench 4.0 - Compute OpenCL Score
9335 Points (4%)
Geekbench 4.0 - 64 Bit Multi-Core Score
3433 Points (12%)
Geekbench 4.0 - 64 Bit Single-Core Score
1179 Points (20%)
Mozilla Kraken 1.1 - Total Score *
min: 4424.7     avg: 4564.1     median: 4564.1 (8%)     max: 4703.4 ms
Sunspider - 1.0 Total Score *
361 ms (9%)
Octane V2 - Total Score
min: 7623     avg: 8327.5     median: 8327.5 (17%)     max: 9032 Points
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

v1.8
