Samsung Exynos 1480

Samsung Exynos 1480

三星 Exynos 1480 是一款用于中端智能手机和平板电脑的片上系统（SoC），基于Android 。CPU 由两个集群组成，每个集群由四个内核组成。使用四个 Cortex-A78 功率内核（最高 2.75 GHz）和四个 Cortex-A55 功率内核（最高 2.05 GHz）。集成图形处理器（GPU）为三星 Xclipse 530。芯片组支持 Wi-Fi 6E 和蓝牙 5.3。内存可连接 LPDDR4x 和 LPDDR5。UFS 3.1 可作为内置存储器。

配备 6K MAC NPU 的全新 AI 引擎的性能据称比上一代产品高出约四倍。此外，还可使用高达 144 Hz 和 Full HD+ 的显示器，并支持高达 200 MPix 的摄像头。改进后的 ISP 现在还能以高达每秒 60 帧的速度播放超高清视频，并能支持 HDR 和零快门延迟（ZSL）。

集成调制解调器的下载速度再次得到大幅提升，5G-Sub6（下载：高达 5.1 GBit/s，上传：高达 1.28 GBit/s）和 5G-mmWave（下载：高达 4.84 GBit/s，上传：高达 0.92 GBit/s）的速度也大大加快，但上传速度与 Exynos 1280 相比没有变化。LTE（Cat.18，下载：最高 1.2 GBit/s，上传：最高 0.211 GBit/s）没有变化。

Exynos 1480 由三星采用 4 纳米工艺制造（三星 4LPP）。

SeriesSamsung Exynos
CodenameARM Cortex-A55 / A78

Series: Exynos ARM Cortex-A55 / A78

Samsung Exynos 1480 « 2.05 - 2.75 GHz8 / 8 cores ARM Cortex-A55 / A78
Samsung Exynos 13802 - 2.4 GHz8 / 8 cores ARM Cortex-A55 / A78
Clock Rate2050 - 2750 MHz
Number of Cores / Threads8 / 8
4 x 2.8 GHz ARM Cortex-A78
4 x 2.1 GHz ARM Cortex-A55
Manufacturing Technology4 nm
Features6K MAC NPU, Wi-Fi 6E, Bluetooth 5.3, GNSS (GPS, Glonass, BeiDou, Galileo)
GPUSamsung Xclipse 530 ( - 1300 MHz)
64 Bit64 Bit support
ArchitectureARM
Announcement Date03/28/2024
Product Link (external)semiconductor.samsung.com

Benchmarks

3DMark - 3DMark Sling Shot Extreme (ES 3.1) Unlimited Physics
5850 Points (69%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 6.2 - Geekbench 6.2 Single-Core
1157 points (35%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 6.2 - Geekbench 6.2 Multi-Core
3456 points (14%)
+ 1 benchmarks and specifications   - Hide comparison chart
Geekbench 5.5 - Geekbench 5.1 - 5.4 64 Bit Single-Core
891 points (38%)
+ 1 benchmarks and specifications   - Hide comparison chart
Mediatek MT6737
58 -93%
...
Samsung Exynos 9820
825 -7%
MediaTek Dimensity 1200
833 -7%
Samsung Exynos 9825
834 -6%
MediaTek Dimensity 8020
835 -6%
Apple A10X Fusion
850 -5%
HiSilicon Kirin 9000W
867 -3%
MediaTek Dimensity 8050
868 -3%
Qualcomm QCM6490
870 -2%
MediaTek Dimensity 7200
889 0%
Samsung Exynos 1480
891
Qualcomm Snapdragon 865
903 1%
MediaTek Dimensity 8100
922 3%
Apple A11 Bionic
927 4%
Samsung Exynos 990
929 4%
Qualcomm Snapdragon 865+ (Plus)
979 10%
Qualcomm Snapdragon 870 5G
989 11%
MediaTek Dimensity 8200-Ultra
1018 14%
Google Tensor
1041 17%
Google Tensor G2
1053 18%
...
Apple M3
2316 160%
max:
Apple M3 Pro 11-Core
2331 162%
0%
100%
Geekbench 5.5 - Geekbench 5.1 - 5.4 64 Bit Multi-Core
3349 points (6%)
+ 1 benchmarks and specifications   - Hide comparison chart
Mediatek MT6580M
248 -93%
...
Qualcomm Snapdragon 780G 5G
2998 -10%
Qualcomm Snapdragon 778G 4G
3020 -10%
HiSilicon Kirin 990 5G
3077 -8%
Google Tensor G2
3198 -5%
Qualcomm Snapdragon 888 4G
3207 -4%
Qualcomm Snapdragon 865+ (Plus)
3243 -3%
Qualcomm Snapdragon 870 5G
3245 -3%
Qualcomm Snapdragon 865
3268 -2%
MediaTek Dimensity 8020
3310 -1%
Samsung Exynos 1480
3349
Apple A13 Bionic
3381 1%
Samsung Exynos 2100 5G
3392 1%
Google Tensor G3
3510 5%
Qualcomm Snapdragon 8 Gen 1
3548 6%
Qualcomm Snapdragon G3x Gen 1
3553 6%
Qualcomm Snapdragon 888 5G
3571 7%
Qualcomm Snapdragon 888 Plus 5G
3572 7%
Samsung Exynos 2200
3600 7%
MediaTek Dimensity 8100
3811 14%
...
Apple M3
10697 219%
max:
AMD Ryzen Threadripper PRO 7995WX
55811 1566%
0%
100%
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
4189 points (42%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
13929 points (16%)
+ 1 benchmarks and specifications   + Show comparison chart
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
1013 ms (1%)
+ 1 benchmarks and specifications   + Show comparison chart
Octane V2 - Octane V2 Total Score
41576 Points (37%)
+ 1 benchmarks and specifications   + Show comparison chart
WebXPRT 4 - WebXPRT 4 Score
126 Points (36%)
+ 1 benchmarks and specifications   + Show comparison chart
WebXPRT 3 - WebXPRT 3 Score
135 Points (28%)
+ 1 benchmarks and specifications   + Show comparison chart
Antutu v9 - AnTuTu v9 Total Score
636128 Points (39%)
+ 1 benchmarks and specifications   + Show comparison chart
Antutu v9 - AnTuTu v9 CPU
190193 Points (52%)
+ 1 benchmarks and specifications   + Show comparison chart
PCMark for Android - PCM f. Android Storage 2.0 random write internal
46.3 MB/s (34%)
+ 1 benchmarks and specifications   + Show comparison chart
PCMark for Android - PCM f. Android Storage 2.0 seq write internal
250.7 MB/s (8%)
+ 1 benchmarks and specifications   + Show comparison chart
PCMark for Android - PCM f. Android Storage 2.0 random read internal
36.5 MB/s (45%)
+ 1 benchmarks and specifications   + Show comparison chart
PCMark for Android - PCM f. Android Storage 2.0 seq read internal
1220 MB/s (34%)
+ 1 benchmarks and specifications   + Show comparison chart
PCMark for Android - PCM f. Android Storage 2.0 score
15251 Points (24%)
+ 1 benchmarks and specifications   + Show comparison chart
PCMark for Android - PCM f. Android Work Score 3.0
13393 Points (62%)
+ 1 benchmarks and specifications   + Show comparison chart
CrossMark - CrossMark Overall
784 Points (30%)
+ 1 benchmarks and specifications   + Show comparison chart
Power Consumption - Geekbench 5.5 Power Consumption 150cd *
4.4 Watt (2%)
+ 1 benchmarks and specifications   + Show comparison chart
012345678910Tooltip
Power Consumption - Idle Power Consumption 150cd 1min *
1.2 Watt (1%)
+ 1 benchmarks and specifications   + Show comparison chart
00.10.20.20.30.40.50.60.60.70.80.9111.11.21.31.41.41.5Tooltip
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
