Intel Celeron N3060

Intel N3060

英特尔赛扬N3060是用于笔记本电脑的低端双核处理器,在2015年4月发布。它的主频为1.6 - 2.48GHz,采用Braswell架构。由于新的14纳米低功耗制程(P1273)与三栅极晶体管技术,它的能效相比前代 Bay Trail产品(如赛扬N2840)显著提高。N3060是赛扬N3050的后续型号,它提供了更高的加速频率(2.48相比2.1 GHz)。

除了处理器内核,它的芯片中还包括了支持DirectX 11.2的显卡以及一个DDR3L内存控制器(2×64位,25.6 GB/s)。

架构

处理器核心基于Airmont架构,基本上只是基于以前的Silvermont芯片稍微修改的缩小版。它的单位时钟频率性能并未改进,不过更加高效的14纳米制程让它可以更好地利用处理器加速,提供更高的整体性能。

性能

根据处理器散热情况,2.48GHz的最高频率如果可以保持更长的时间的话,它将会比只能达到2.16GHz的赛扬N3050有明显的性能优势。使用Windows时,这款处理器足以满足日常任务如上网浏览或办公应用的需要,但面对要求较高的软件和最新游戏可能会举步维艰。

图形

英特尔高清显卡400(Braswell)基于Broadwell架构(英特尔第八代)支持DirectX 11.2,也用于其他Broadwell系列处理器(如高清显卡5300)。搭配12个EU,最高频率600MHz,这款显卡相比高清显卡(Bay Trail)几乎快了一倍,不过仍然不足以满足大型3D游戏的需要。该显卡还支持4K / H.265视频加速。虽然命名不同,这款处理器相比N3050并没有改变(除了显卡命名不同)。

功耗

整个系统芯片的热设计功率为6瓦(SDP 4瓦)。因此,该芯片可采用被动散热。

SeriesIntel Celeron
CodenameBraswell
Series: Celeron Braswell
Intel Celeron N31601600 - 2240 MHz4 / 4
Intel Celeron N31501600 - 2080 MHz4 / 4
» Intel Celeron N30601600 - 2480 MHz2 / 2
Intel Celeron N30501600 - 2160 MHz2 / 2
Intel Celeron N30001040 - 2080 MHz2 / 2
Clock Rate1600 - 2480 MHz
Level 2 Cache2 MB
Number of Cores / Threads2 / 2
Max. Power Consumption (TDP = Thermal Design Power)6 Watt
Manufacturing Technology14 nm
Max. Temperature90 °C
SocketFCBGA1170
FeaturesIntel HD Graphics 400 (Braswell, 12 EUs, 320 - 700 MHz), Wireless Display, Quick Sync, AES-NI, max. 8 GB Dual-Channel DDR3L-1600 (25,6 GB/s), 5x USB 3.0, 4x PCIe 2.0, 2x SATA 6.0 Gbit/s
GPUIntel HD Graphics 400 (Braswell) (320 - 700 MHz)
64 Bit64 Bit support
Starting Price$107 U.S.
Announcement Date04/01/2015
Product Link (external)Intel Celeron N3060

Benchmarks

Cinebench R15 - CPU Multi 64Bit
min: 68     avg: 71.3     median: 71.5 (2%)     max: 74 Points
Cinebench R15 - CPU Single 64Bit
min: 36     avg: 37.8     median: 38 (18%)     max: 39 Points
Cinebench R11.5 - CPU Multi 64Bit
min: 0.8     avg: 0.8     median: 0.8 (3%)     max: 0.86 Points
Cinebench R11.5 - CPU Single 64Bit
min: 0.41     avg: 0.4     median: 0.4 (18%)     max: 0.46 Points
Cinebench R10 - Rendering Single 32Bit
min: 1216     avg: 1252.7     median: 1267 (14%)     max: 1275 Points
Cinebench R10 - Rendering Multiple CPUs 32Bit
min: 2256     avg: 2351.7     median: 2397 (5%)     max: 2402 Points
Cinebench R10 - Rendering Multiple CPUs 64Bit
3426 Points (5%)
Cinebench R10 - Rendering Single CPUs 64Bit
1800 Points (17%)
wPrime 2.0x - 1024m *
1361.2 seconds (16%)
wPrime 2.0x - 32m *
43.1 seconds (9%)
X264 HD Benchmark 4.0 - Pass 2
5.5 fps (4%)
X264 HD Benchmark 4.0 - Pass 1
28.4 fps (11%)
TrueCrypt - Serpent Mean 100MB
0.1 GB/s (0%)
TrueCrypt - Twofish Mean 100MB
0.1 GB/s (3%)
TrueCrypt - AES Mean 100MB
0.5 GB/s (2%)
Super Pi mod 1.5 XS 1M *
27.5 Seconds (6%)
Super Pi mod 1.5 XS 2M *
61.2 Seconds (3%)
Super Pi Mod 1.5 XS 32M *
1566.1 Seconds (7%)
3DMark 11 - Performance Physics 1280x720
min: 918     avg: 995     median: 993 (5%)     max: 1076 points
3DMark - Ice Storm Standard Physics 1280x720
10140 Points (7%)
3DMark - Ice Storm Extreme Physics 1920x1080
8087 Points (10%)
3DMark - Ice Storm Unlimited Physics 1280x720 offscreen
min: 10498     avg: 11006.5     median: 11006.5 (14%)     max: 11515 Points
3DMark - Cloud Gate Standard Physics 1280x720
min: 668     avg: 735     median: 735 (2%)     max: 802 Points
3DMark - Fire Strike Physics 1920x1080
1124 Points (4%)
Geekbench 3 - 32 Bit Multi-Core Score
1708 Points (5%)
Geekbench 3 - 32 Bit Single-Core Score
913 Points (19%)
Geekbench 4.0 - Compute OpenCL Score
6555 Points (3%)
Geekbench 4.0 - 64 Bit Multi-Core Score
1834 Points (7%)
Geekbench 4.0 - 64 Bit Single-Core Score
1087 Points (19%)
Geekbench 4.1/4.2 - 64 Bit Single-Core Score
1127 Points (18%)
Geekbench 4.1/4.2 - 64 Bit Multi-Core Score
1911 Points (5%)
Mozilla Kraken 1.1 - Total Score *
min: 4901.1     avg: 4928.5     median: 4928.5 (8%)     max: 4955.9 ms
Sunspider - 1.0 Total Score *
min: 366.5     avg: 785     median: 976 (24%)     max: 1012.6 ms
Octane V2 - Total Score
min: 7341     avg: 7793     median: 7735 (16%)     max: 8303 Points
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

v1.8
