Intel Celeron N2815

Intel N2815

Intel Celeron N2815是一款为入门级笔记本电脑设计的高能效双核整合系统芯片。它属于Bay Trail-M平台,运行于1.86 - 2.13GHz。得利于特别优化设计的22纳米低功耗制程(P1271)和三栅极晶体管技术,它的性能和能效明显高于前代Intel Atom处理器产品。 架构 它的处理器核心基于新的Silvermont架构,它第一次采用了乱序执行技术的设计。更高的流水线利用率和很多其他的改进(优化的分支预测,缓存的提升,加强的解码器)帮助单位频率性能提升了约50%。不过,相对于前代,它没有采用超线程技术。其他重要改进还有新增加的对SSE 4.1和4.2,AES-NI指令集的支持(根据型号)。 性能 得力于四个处理器核心更高的单位时钟频率性能,Celeron N2815快于前代的Intel Atom处理器如N2800。它的表现可以与AMD的APU如A4-4355M竞争。它的性能足够满足日常应用如上网和办公,但不适合大型软件和最新游戏。 图形 HD Graphics(Bay Trail)基于同样使用在Ivy Bridge系列处理器中(如HD Graphics 4000)的Intel Gen7架构,支持DirectX 11。由于只有4个执行单元(EU)和756MHz的较低运行频率,它的性能低于HD Graphics(Ivy Bridge)。因此,只有较老和要求较低的Windows游戏可以流畅运行。 功耗 这块整合系统芯片的热设计功率为7.5W。因此,它可以用于紧凑设计的轻薄笔记本电脑和变形本中。

SeriesIntel Celeron
CodenameBay Trail-M
Series: Celeron Bay Trail-M
Intel Celeron N29401830 - 2250 MHz4 / 4
Intel Celeron N29301830 - 2160 MHz4 / 4
Intel Celeron N29201860 - 2000 MHz4 / 4
Intel Celeron N28402160 - 2580 MHz2 / 2
Intel Celeron N29101600 MHz4 / 4
Intel Celeron N28302160 - 2410 MHz2 / 2
Intel Celeron N28202170 - 2390 MHz2 / 2
» Intel Celeron N28151860 - 2133 MHz2 / 2
Intel Celeron N28102000 MHz2 / 2
Intel Celeron N28081580 - 2250 MHz2 / 2
Intel Celeron N28071580 - 2160 MHz2 / 2
Intel Celeron N28061580 - 2000 MHz2 / 2
Intel Celeron N28051460 MHz2 / 2
Clock Rate1860 - 2133 MHz
Level 1 Cache112 KB
Level 2 Cache1 MB
Number of Cores / Threads2 / 2
Power Consumption (TDP = Thermal Design Power)7.5 Watt
Manufacturing Technology22 nm
Max. Temperature105 °C
SocketFCBGA1170
FeaturesHD Graphics (Bay Trail, max. 756 MHz)
GPUIntel HD Graphics (Bay Trail) (313 - 756 MHz)
64 Bit64 Bit support
Starting Price$107 U.S.
Announcement Date12/01/2013
Product Link (external)Intel Celeron N2815

Benchmarks

Cinebench R15 - CPU Multi 64Bit
min: 49     avg: 55.5     median: 55.5 (1%)     max: 62 Points
Cinebench R15 - CPU Single 64Bit
min: 31     avg: 32.5     median: 32.5 (15%)     max: 34 Points
Cinebench R11.5 - CPU Multi 64Bit
min: 0.62     avg: 0.7     median: 0.7 (2%)     max: 0.76 Points
Cinebench R11.5 - CPU Single 64Bit
min: 0.32     avg: 0.4     median: 0.4 (14%)     max: 0.4 Points
Cinebench R10 - Rendering Single 32Bit
1068 Points (11%)
Cinebench R10 - Rendering Multiple CPUs 32Bit
2038 Points (3%)
Cinebench R10 - Rendering Multiple CPUs 64Bit
2781 Points (3%)
Cinebench R10 - Rendering Single CPUs 64Bit
1509 Points (14%)
wPrime 2.0x - 1024m *
1818 seconds (21%)
wPrime 2.0x - 32m *
57.8 seconds (12%)
WinRAR - Result
594 KB/s (6%)
X264 HD Benchmark 4.0 - Pass 2
4.5 fps (3%)
X264 HD Benchmark 4.0 - Pass 1
24.1 fps (8%)
TrueCrypt - Serpent Mean 100MB
0.1 GB/s (2%)
TrueCrypt - Twofish Mean 100MB
0.1 GB/s (2%)
TrueCrypt - AES Mean 100MB
0.1 GB/s (1%)
Super Pi mod 1.5 XS 1M *
42.3 Seconds (9%)
Super Pi mod 1.5 XS 2M *
92.7 Seconds (4%)
Super Pi Mod 1.5 XS 32M *
1965 Seconds (9%)
3DMark 11 - Performance Physics 1280x720
min: 850     avg: 872     median: 871.5 (4%)     max: 893 points
3DMark - Ice Storm Standard Physics 1280x720
min: 2209     avg: 5878     median: 5878 (4%)     max: 9547 Points
3DMark - Cloud Gate Standard Physics 1280x720
min: 166     avg: 459     median: 459 (1%)     max: 752 Points
3DMark - Fire Strike Physics 1920x1080
1017 Points (3%)
Geekbench 2 - 32 Bit - Stream
2183 Points (18%)
Geekbench 2 - 32 Bit - Memory
1950 Points (18%)
Geekbench 2 - 32 Bit - Floating Point
1747 Points (3%)
Geekbench 2 - 32 Bit - Integer
1993 Points (4%)
Geekbench 2 - 32 Bit - Total Score
1917 Points (5%)
Geekbench 3 - 32 Bit Multi-Core Score
1343 Points (2%)
Geekbench 3 - 32 Bit Single-Core Score
781 Points (16%)
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

v1.11
