Asus ProArt Studiobook 16 OLED H7604

Specifications

Asus ProArt Studiobook 16 OLED H7604
Asus ProArt Studiobook 16 OLED H7604 (ProArt StudioBook 16 Series)
Processor
Intel Core i9-13980HX 24 x 1.6 - 5.6 GHz, 170 W PL2 / Short Burst, 130 W PL1 / Sustained, Raptor Lake-HX
Graphics adapter
NVIDIA GeForce RTX 4070 Laptop GPU - 8 GB VRAM, Core: 2175 MHz, Memory: 2000 MHz, 130 W TDP ( including 25 W Dynamic Boost), GDDR6, 535.98, Optimus
Memory
64 GB
, DDR5-5600, Dual-Channel, 2 Slots, max. 64 GB
Display
16.00 inch 16:10, 3200 x 2000 pixel 236 PPI, capacitive, native pen support, ATNA60BX01-1, OLED, glossy: yes, 120 Hz
Mainboard
Intel HM770 (Raptor Lake-S PCH)
Storage
Phison EM2804TBMTCB47, 4096 GB
, 3717 GB free
Soundcard
Intel Raptor Lake-S PCH - cAVS
Connections
2 USB 3.1 Gen2, 2 USB 4.0 40 Gbps, 2 Thunderbolt, 1 HDMI, 2 DisplayPort, Audio Connections: 3.5 mm Stereo, Card Reader: SD Express 7.0
Networking
Realtek RTL8125 2.5GBe Family Ethernet Controller (10/100/1000/2500MBit/s), Intel Wi-Fi 6E AX211 (a/b/g/h/n = Wi-Fi 4/ac = Wi-Fi 5/ax = Wi-Fi 6/ Wi-Fi 6E 6 GHz), Bluetooth 5.3
Size
height x width x depth (in mm): 23.9 x 356 x 271
Battery
90 Wh, 5845 mAh Lithium-Polymer
Operating System
Microsoft Windows 11 Pro
Camera
Webcam: 1080p with Privacy Shutter & IR
Primary Camera: 2 MPix
Additional features
Speakers: Quad speakers, Keyboard: Chiclet 1.4mm travel, Keyboard Light: yes, 240W PSU, Mouse, Stylus, MyAsus, ProArt Creator Hub, 24 Months Warranty
Weight
2.434 kg, Power Supply: 737 g
Price
4000 Euro



Pricecompare

Average Score: 87.02% - good
Average of 5 scores (from 4 reviews)
price: 80%, performance: 94%, features: 73%, display: 95% mobility: 69%, workmanship: 95%, ergonomy: 92%, emissions: 67%

Reviews for the Asus ProArt Studiobook 16 OLED H7604

86.1% 华硕ProArt Studiobook 16 OLED回顾:具有极端CPU性能的多媒体笔记本电脑 | Notebookcheck
华硕在ProArt Studiobook 16 OLED中为创意用户提供了一台强大的机器。英特尔的酷睿i9-13980HX和GeForce RTX 4070笔记本电脑照顾到了性能相关的事项,但新的120赫兹OLED面板并不完全令人信服。
80% Asus ProArt Studiobook 16 OLED (H7604) 2023 review: Top components and build quality throughout
Source: It Pro English EN→zh-CN
This is a great update to the Studiobook and one that should particularly appeal to 3D designers – when that model becomes available. It will then be possible to rapidly iterate through prototypes: design, get feedback, and tweak. If you can take advantage of the Asus Dial, the stylus, and the sheer firepower within this laptop, then it could be a transformative purchase. For everyone else, it's probably overkill. Especially at this price. But if you like the idea of the integrated dial, then Google for "ProArt Studiobook 16 OLED" and you'll find cheaper options based on last year's silicon. The ProArt Studiobook 16 OLED has a unique design, and if you need its skillset then you can be assured of top components and build quality throughout.
Single Review, online available, Short, Date: 07/10/2023
Rating: Total score: 80%
90% ASUS ProArt Studiobook OLED (H7604) review: state of the arts
Source: Creative Bloq English EN→zh-CN
A laptop that manages to crowbar in some of the most powerful components currently on the market, then keep them cool enough to extract huge levels of performance, the ASUS ProArt Studiobook is ideal for everything from basic image editing to 3D rendering. It laughs at 4K video, plays games, flies through raw image processing and looks good while doing it. A laptop that manages to crowbar in some of the most powerful components currently on the market, then keep them cool enough to extract huge levels of performance, the ASUS ProArt Studiobook is ideal for everything from basic image editing to 3D rendering. It laughs at 4K video, plays games, flies through raw image processing and looks good while doing it.
Single Review, online available, Short, Date: 06/14/2023
Rating: Total score: 90%
86% ASUS ProArt Studiobook 16 OLED, análisis: soñar, crear, jugar
Source: MuyComputer Spanish ES→zh-CN
Single Review, online available, Very Long, Date: 12/17/2023
Rating: Total score: 86% price: 80% performance: 90% mobility: 75% workmanship: 95%
93% ASUS ProArt Studiobook 16 OLED, review completa en español
Source: Game IT Spanish ES→zh-CN
Single Review, online available, Medium, Date: 05/01/2023
Rating: Total score: 93% display: 100% workmanship: 100% ergonomy: 90%

Comment

NVIDIA NVIDIA GeForce RTX 4070 Laptop GPU:

基于 Ada Lovelace 架构的笔记本电脑高端显卡。提供 8 GB GDDR6(128 位),可配置为 35 - 115W(+ 动态升压)的 TGP。



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


i9-13980HX: Raptor Lake 系列移动 CPU,提供 24 个内核(8 个性能内核、16 个效率内核),P 内核的 Boost 内核频率最高可达 5.8 GHz。与台式机 i9-13900K 类似,但降低了时钟速度和 TDP。» Further information can be found in our Comparison of Mobile Processsors.


16.00": 15到16寸是笔记本电脑的标准尺寸,产品型号最为丰富。» To find out how fine a display is, see our DPI List.


2.434 kg: 这是14到16寸的标准笔记本电脑的常见重量。


» Further information can be found in our Notebook Purchase Guide.
