Aorus MASTER 16 AM6H
Specifications
Aorus Master 16 (Master 16 Series)
Processor
Intel Core Ultra 9 275HX 24 x 2.1 - 5.4 GHz, 155 W PL2 / Short Burst, 115 W PL1 / Sustained, Arrow Lake-HX
Graphics adapter
NVIDIA GeForce RTX 5090 Laptop - 24 GB VRAM, 175 W TDP ( including 25 W Dynamic Boost), Geforce 583.61
Memory
32 GB
, 2x 16 GB DDR5-5600
Display
16.00 inch 16:10, 2560 x 1600 pixel 189 PPI, ATNA60DL03-0 (SDC41AB), OLED, G-Sync, HDR True Black 500, ClearMR 10000, Pantone Validated, glossy: yes, HDR, 240 Hz, Adaptive Sync
Mainboard
Intel HM870 (Arrow Lake-HX PCH)
Storage
Kingston OM8PGP41024Q-A0, 1024 GB
, 2x Kingston OM8PGP41024Q-A0, 1860 GB free
Soundcard
Intel Arrow Lake-S PCH - ACE (Audio Context Engine)
Connections
2 USB 3.1 Gen2, 2 USB4 40 Gbps, 2 Thunderbolt, USB-C Power Delivery (PD), 1 HDMI, 2 DisplayPort, Audio Connections: Headset jack, Card Reader: Micro-SD-Reader
Networking
Realtek RTL8168/8111 Gigabit-LAN (10/100/1000MBit/s), Intel Wi-Fi 7 BE200 320MHz (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/ax = Wi-Fi 6/ Wi-Fi 6E 6 GHz be = Wi-Fi 7), Bluetooth Bluetooth 5.4
Size
height x width x depth (in mm): 29.9 x 357 x 254
Battery
99 Wh Lithium-Polymer
Operating System
Microsoft Windows 11 Pro
Camera
Webcam: Full-HD Webcam
Primary Camera: 0.9 MPix
Primary Camera: 0.9 MPix
Additional features
Speakers: 4x 2 W speakers, Keyboard: Chiclet, Keyboard Light: yes, 24 Months Warranty
Weight
2.493 kg, Power Supply: 729 g
Price
4.75 Euro
Price comparison
Average Score:
Average of 3 scores (from 3 reviews)
Average of 3 scores (from 3 reviews)
price: 77%, performance: 97%, features: 85%, display: 92% mobility: 77%, workmanship: 81%, ergonomy: 82%, emissions: 74%
Reviews for the Aorus MASTER 16 AM6H
搭载 RTX 5090 和 240 Hz OLED，与 ROG、Legion 等公司竞争 - 技嘉 Aorus Master 16 游戏笔记本评测 | Notebookcheck
我们终于拿到了精通测试的 Aorus Master 16，它配备了 RTX 5090、OLED 显示屏、Thunderbolt 5、PCIe 5.0 和 WiFi 7。这就是售价 4300 美元的新性能之王？
我们终于拿到了精通测试的 Aorus Master 16，它配备了 RTX 5090、OLED 显示屏、Thunderbolt 5、PCIe 5.0 和 WiFi 7。这就是售价 4300 美元的新性能之王？
Gigabyte AORUS Master 18: Bigger IS Better!
Source: Matthew Moniz
Single Review, online available, Long, Date: 06/12/2025
Source: Matthew Moniz
Single Review, online available, Long, Date: 06/12/2025
Fantastische Leistung für pralle Geldbeutel
Source: Chip.de
DE→zh-CN
Single Review, online available, Long, Date: 05/16/2025
Rating: Total score: 97% price: 77% performance: 100% features: 98% display: 99% mobility: 90% ergonomy: 82%
Source: Chip.de
DE→zh-CNSingle Review, online available, Long, Date: 05/16/2025
Rating: Total score: 97% price: 77% performance: 100% features: 98% display: 99% mobility: 90% ergonomy: 82%
AORUS MASTER 16 AM6H BYH Review
Source: Geeknetic
ES→zh-CN
Single Review, online available, Very Long, Date: 07/01/2025
Rating: Total score: 90%
Source: Geeknetic
ES→zh-CNSingle Review, online available, Very Long, Date: 07/01/2025
Rating: Total score: 90%
Comment
NVIDIA GeForce RTX 5090 Laptop: GeForce RTX 5090 移动版使用的是 GB203 芯片，使用了 10,496 个着色器/CUDA 内核，而该芯片的最大值为 10,752 个。这使得 RTX 5090 笔记本电脑与 RTX 5080 台式机变体（相同芯片）比 台式机 RTX 5090更接近。
» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.
Ultra 9 275HX: 基于 Arrow Lake 架构的游戏笔记本移动高端 CPU。提供 24 个内核，包括 8 个主频高达 5.4 GHz 的高性能内核和 16 个主频高达 4.6 GHz 的高效能内核。CPU 可访问 40 MB 二级缓存和 36 MB 三级缓存，TDP 为 55 瓦。SoC 集成了一个名为 AI Boost 的小型专用 NPU，具有 13 个 TOPS (Int8)，可选择支持 vPro Essentials。» Further information can be found in our Comparison of Mobile Processsors.
