Lenovo ThinkPad X1 Carbon G9-20XWCTO1WW

Specifications

Lenovo ThinkPad X1 Carbon G9-20XWCTO1WW
Lenovo ThinkPad X1 Carbon G9-20XWCTO1WW (ThinkPad X1 Carbon G9 Series)
Processor
Intel Core i7-1165G7 4 x 2.8 - 4.7 GHz, 36 W PL2 / Short Burst, 28 W PL1 / Sustained, Tiger Lake UP3
Memory
32768 MB
, LPDDR4X-4266, on-board, Quad-Channel
Display
14.00 inch 16:10, 3840 x 2400 pixel 323 PPI, MNE007A1-2, IPS LED, glossy: yes, HDR
Mainboard
Intel Tiger Lake-UP3 PCH-LP
Storage
Samsung PM9A1 MZVL21T0HCLR, 1024 GB
, M.2 2280, NVMe PCIe 4.0, 845 GB free
Soundcard
Realtek ALC3306
Connections
2 USB 3.0 / 3.1 Gen1, 2 USB 4.0 40 Gbps, 2 Thunderbolt, USB-C Power Delivery (PD), 1 HDMI, 2 DisplayPort, 1 Kensington Lock, Audio Connections: 3.5mm Audio, 1 Fingerprint Reader
Networking
Intel Wi-Fi 6 AX201 (a/b/g/h/n = Wi-Fi 4/ac = Wi-Fi 5/ax = Wi-Fi 6), Bluetooth 5.1
Size
height x width x depth (in mm): 14.9 x 315 x 221.6
Battery
57 Wh Lithium-Polymer
Operating System
Microsoft Windows 10 Pro 64 Bit
Camera
Webcam: 720p w/IR & ThinkShutter
Additional features
Speakers: 2x 2 W, 2x 0.8 W, Dolby Atmos, Keyboard: 6 row Chiclet w/1.5mm travel, Keyboard Light: yes, 65 W USB C Charger, Lenovo Commercial Vantage, 36 Months Warranty
Weight
1.156 kg, Power Supply: 332 g
Price
2520 Euro



Pricecompare

Average Score: 90.15% - very good
Average of 2 scores (from 1 reviews)
price: - %, performance: 78%, features: 74%, display: 90% mobility: 76%, workmanship: 90%, ergonomy: 91%, emissions: 93%

Reviews for the Lenovo ThinkPad X1 Carbon G9-20XWCTO1WW

90.3% Lenovo ThinkPad X1 Carbon Gen 9 Laptop Review: Big 16:10 upgrade with Intel Tiger Lake | Notebookcheck
16:10, two fans, a bigger battery and a 4K UHD+ screen - Lenovo has made a lot of changes to the new ThinkPad X1 Carbon Gen 9. While doing so, Lenovo unfortunately also made alterations to the ThinkPad keyboard that are not necessarily positive. Find out why in our comprehensive review!
90% Understatement in Notebook-Form
Source: Netzwelt German DE→zh-CN
Single Review, online available, Long, Date: 07/10/2021
Rating: Total score: 90% performance: 80% features: 80% display: 90% ergonomy: 90%

Comment

Intel Iris Xe G7 96EUs:

基于96个EU(执行单元/着色器集群)的新Gen.12体系结构的英特尔Tiger Lake G4 SoC内置显卡。 时钟速率因处理器型号而异。 Tiger Lake芯片采用英特尔10纳米以上的现代工艺生产。



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


i7-1165G7:

基于Tiger Lake的低功耗四核处理器,适用于轻薄笔记本电脑。四个核心的频率约为2.8-4.7 GHz。由Intel生产的10nm+产品。

» Further information can be found in our Comparison of Mobile Processsors.


14.00":

大体上,这个屏幕尺寸常见于亚笔记本电脑,超极本和变形本中。对这三类产品来说这个尺寸都较大。亚笔记本中尺寸最大的机型是采用这个屏幕尺寸。

大尺寸可以让屏幕有更高的分辨率。因而例如字体等的细节将会更丰富。不过另一方面,小屏幕的功耗会较低,而设备也会更轻盈小巧,售价更低。

» To find out how fine a display is, see our DPI List.


1.156 kg: 这是10到11寸大尺寸平板电脑,小型亚笔记本,超极本和变形本的常见重量。


» Further information can be found in our Notebook Purchase Guide.
