MSI Stealth 14 AI Studio A1VGG

Specifications

MSI Stealth 14 AI Studio A1VGG
MSI Stealth 14 AI Studio A1VGG
Processor
Intel Core Ultra 9 185H 16 x 3.8 - 5.1 GHz, Meteor Lake-H
Graphics adapter
NVIDIA GeForce RTX 4070 Laptop GPU - 8 GB VRAM, 90 W TDP, GDDR6
Memory
35 GB
, DDR5-5600
Display
14.00 inch 16:10, 2560 x 1600 pixel 216 PPI, IPS, 240 Hz
Storage
M.2 PCIe
Connections
1 USB 3.0 / 3.1 Gen1, 1 USB 3.1 Gen2, 1 Thunderbolt, USB-C Power Delivery (PD), 1 HDMI, Audio Connections: 3.5mm
Networking
Wi-Fi 7 (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/ax = Wi-Fi 6/ Wi-Fi 6E 6 GHz be = Wi-Fi 7), Bluetooth 5.4
Size
height x width x depth (in mm): 21.8 x 315.6 x 246.25
Battery
72 Wh, 4-cell
Operating System
Microsoft Windows 11 Home
Camera
Webcam: IR
Primary Camera: 2 MPix
Additional features
Speakers: Stereo, Keyboard: Chiclet, Keyboard Light: yes
Weight
1.7 kg



Price comparison

Reviews for the MSI Stealth 14 AI Studio A1VGG

微星Stealth 14 AI Studio A1V评测–小巧、强大、坚固、噪音小
Source: Laptopmedia CN
微星 Stealth 14 AI Studio A1V 有潜力成为同类产品中的真正爆款。蒸气室散热功能强大,这就是为什么 CPU 即使在较长的负载下也能保持 14 英寸处理器的惊人高频率(P 核心 3.6 Ghz,E 核心 ~2.90 Ghz)。图形处理器在游戏过程中保持 90W TGP 和 ~2000 MHz 频率也不成问题。对于如此小巧的设备来说,这一切听起来都很不错,但它的主要缺点是重负载时风扇噪音很大。在游戏过程中,键盘的触感也很热。您可以切换到 “平衡 “预设来避免这种情况,该预设的特点是 CPU 和 GPU 时钟明显较低。不过,键盘和触摸板还是非常不错的。16:10 120Hz OLED 显示屏(三星 ATNA40CU04-0 (SDC419B))是真正的精品。它完全覆盖了 sRGB 和 DCI-P3 色域。借助我们的 “设计和游戏 “配置文件,该面板实现了良好的色彩准确性,因此适合内容创作和色彩敏感型工作。在 HDR 模式下,该显示器拥有无限对比度和 636 尼特的最大亮度。面板具有典型的 OLED 闪烁现象,但至少脉动频率高达 480 赫兹。镁铝合金机身坚固耐用,触感优质。该设备配备了一个 MUX 开关、Wi-Fi 7 + 蓝牙 v5.4,端口选择虽然有限,但很现代。考虑到高分辨率屏幕和饥渴的硬件,近 6 小时的视频续航时间还算可以。
Single Review, online available, Very Long, Date: 06/07/2024

Foreign Reviews

How to open MSI Stealth 14 AI Studio A1V - disassembly and upgrade options
Source: Laptop Media English
Support, online available, Short, Date: 06/08/2024
MSI Stealth 14 AI Studio A1V review – small, powerful, solid, and noisy
Source: Laptop Media English EN→zh-CN
The MSI Stealth 14 AI Studio A1V has the potential to be a true hit in its category. The vapor chamber cooling is potent and that’s why the CPU can maintain surprisingly high clocks for a 14-incher even in longer loads (3.6 Ghz for the P cores and ~2.90 Ghz for the E cores). The GPU has no problems sustaining 90W TGP and ~2000 MHz frequency during gaming. All that sounds great for such a compact device but its main con is the loud fan noise during heavy loads. The keyboard also feels hot to the touch during gaming. You can avoid that by switching to the “Balanced” preset which is characterized by notably lower CPU and GPU clocks. Still, the keyboard and the touchpad are very good. The 16:10 120Hz OLED display (Samsung ATNA40CU04-0 (SDC419B)) is a true gem. It covers fully the sRGB and DCI-P3 gamuts.
Single Review, online available, Very Long, Date: 06/07/2024

Comment

NVIDIA NVIDIA GeForce RTX 4070 Laptop GPU:

基于 Ada Lovelace 架构的笔记本电脑高端显卡。提供 8 GB GDDR6(128 位),可配置为 35 - 115W(+ 动态升压)的 TGP。



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


Ultra 9 185H: 2023 年 12 月亮相的顶级流星湖芯片。这款第 1 代酷睿 Ultra 处理器将取代第 13 代酷睿芯片;它拥有 16 个内核(6 + 8 + 2)和 22 个线程。其中,性能内核有 6 个,运行频率最高可达 5.1 GHz,而高效内核有 10 个(8 个主内核加上低功耗岛中的 2 个额外内核),运行频率最高可达 3.8 GHz。刚刚出炉的 8 核 Arc GPU 可用作集成图形适配器,其运行频率高达 2.35 GHz,此外还提供了大量其他全新技术,如集成的 AI Boost NPU(带有两个用于硬件 AI 工作负载加速的第 3 代引擎)。这款笔记本处理器的 "基本 "功耗为 45 W,而 Turbo 功耗不会超过 115 W。» Further information can be found in our Comparison of Mobile Processsors.


14.00":

大体上,这个屏幕尺寸常见于亚笔记本电脑,超极本和变形本中。对这三类产品来说这个尺寸都较大。亚笔记本中尺寸最大的机型是采用这个屏幕尺寸。

大尺寸可以让屏幕有更高的分辨率。因而例如字体等的细节将会更丰富。不过另一方面,小屏幕的功耗会较低,而设备也会更轻盈小巧,售价更低。

» To find out how fine a display is, see our DPI List.


1.7 kg: 这是11到13寸的超大尺寸平板电脑,亚笔记本电脑,超极本和变形本的常见重量。


» Further information can be found in our Notebook Purchase Guide.
