Asus ZenBook Flip 14 UN5401QA-KN085W

Specifications

Asus ZenBook Flip 14 UN5401QA-KN085W
Asus ZenBook Flip 14 UN5401QA-KN085W (ZenBook Flip 14 Series)
Processor
AMD Ryzen 7 5800H 8 x 3.2 GHz @ 4.45 GHz, 54 W PL2 / Short Burst, 45 W PL1 / Sustained, Cezanne-H (Zen 3)
Graphics adapter
AMD Radeon RX Vega 8 (Ryzen 4000/5000) - 512 MB VRAM, Core: 2000 MHz, Memory: 2100 MHz
Memory
16 GB
, LPDDR4-3200, Dual-Channel, Onboard
Display
14.00 inch 16:10, 2880 x 1800 pixel 243 PPI, 10-point capacitive, native pen support, SDC4154, OLED, glossy: yes, detachable screen, HDR, 90 Hz
Mainboard
AMD CZ FCH
Storage
Intel SSD 600p SSDPEKKW512G7, 512 GB
, 430 GB free
Soundcard
AMD Raven/Renoir/Van Gogh/Cezanne/Rembrandt/Raphael - HD Audio Controller
Connections
3 USB 3.1 Gen2, USB-C Power Delivery (PD), 1 HDMI, 1 DisplayPort, Audio Connections: 3,5 mm, Card Reader: MicroSD, 1 Fingerprint Reader, Brightness Sensor
Networking
Intel Wi-Fi 6 AX200 (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/ax = Wi-Fi 6/), Bluetooth 5.0
Size
height x width x depth (in mm): 15.9 x 311.2 x 222.5
Battery
63 Wh Lithium-Ion, Battery runtime (according to manufacturer): 10 h
Charging
fast charging / Quickcharge
Operating System
Microsoft Windows 11 Home
Camera
Webcam: 720p
Primary Camera: 0.9 MPix
Additional features
Speakers: Stereo, Keyboard: Chiclet, Keyboard Light: yes, MyAsus, 24 Months Warranty
Weight
1.4 kg, Power Supply: 404 g
Price
1299 Euro



Pricecompare

Average Score: 78.25% - good
Average of 2 scores (from 2 reviews)
price: - %, performance: 79%, features: 72%, display: 90% mobility: 77%, workmanship: 81%, ergonomy: 87%, emissions: 85%

Reviews for the Asus ZenBook Flip 14 UN5401QA-KN085W

86.5% 华硕Zenbook Flip 14 OLED回顾。归功于AMD和OLED的绝对感觉 | Notebookcheck
华硕以Zenbook Flip 14 OLED的形式在市场上推出了一款强劲的可折叠机。这款产品拥有出色的14英寸OLED显示屏,刷新率为90赫兹,采用流行的16:10格式的3K分辨率。但这并不是唯一闪亮的功能。在下面的评论中,我们将了解其他的优势和劣势。
70% Asus ZenBook 14 Flip OLED Review: Dripping with features and value
Source: The Times of India English EN→zh-CN
The Asus ZenBook 14 Flip OLED is a great option for someone who wants a premium Windows convertible laptop experience. The 14-inch 2.8K OLED display and the Ryzen 9 5900H processor certainly make for compelling reasons to consider this over its rivals from Dell and HP at this price. The overall build quality as well as the choice of I/O ports add to the appeal as well. However, Asus is launching this laptop at a time when the AMD Ryzen 6000 series processors are making their way to high-end Windows laptops. Hence, investing this much money into a laptop offering a last-gen processor does not seem sensible. Asus could have offered this laptop with the latest generation Ryzen 6000 series processor. On the whole, those seeking a great viewing experience and fast performance with a solid build and design should check out the Asus ZenBook 14 Flip OLED once.
Single Review, online available, Short, Date: 03/21/2022
Rating: Total score: 70%
Asus Zenbook 14 Flip OLED: černočerný otočný displej (recenze)
Source: CNews.cz CZ→zh-CN
Single Review, online available, Medium, Date: 06/14/2022

Comment

AMD Vega 8:

基于Vega架构的Ryzen APU的集成图形卡,具有8个CU(= 512着色器)和最高1.750 MHz的频率。



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


R7 5800H:

移动Octa-Core APU 使用 Zen 3 核心,时钟为 3.2 到 4.4 GHz,8 CU 时钟为 2000 MHz 的 Vega 显卡。

» Further information can be found in our Comparison of Mobile Processsors.


14.00":

大体上,这个屏幕尺寸常见于亚笔记本电脑,超极本和变形本中。对这三类产品来说这个尺寸都较大。亚笔记本中尺寸最大的机型是采用这个屏幕尺寸。

大尺寸可以让屏幕有更高的分辨率。因而例如字体等的细节将会更丰富。不过另一方面,小屏幕的功耗会较低,而设备也会更轻盈小巧,售价更低。

» To find out how fine a display is, see our DPI List.


1.4 kg: 这是11到13寸的超大尺寸平板电脑,亚笔记本电脑,超极本和变形本的常见重量。


» Further information can be found in our Notebook Purchase Guide.
