Asus TUF Gaming F17 FX706LI-HX177T

Specifications

Asus TUF Gaming F17 FX706LI-HX177T
Asus TUF Gaming F17 FX706LI-HX177T (TUF Gaming F17 Series)
Processor
Intel Core i7-10870H 8 x 2.2 - 5 GHz, Comet Lake-H
Graphics adapter
Memory
16384 MB
, DDR4-2933
Display
17.30 inch 16:9, 1920 x 1080 pixel 127 PPI, IPS, glossy: no, 120 Hz
Storage
1TB SSD
Connections
2 USB 3.0 / 3.1 Gen1, USB-C Power Delivery (PD), 1 HDMI, 1 DisplayPort, Audio Connections: 3.5mm
Networking
10/100/1000 LAN Card (10/100/1000/2500/5000MBit/s), 802.11 a/b/g/n/ac/ax (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/ax = Wi-Fi 6), Bluetooth 5.1
Size
height x width x depth (in mm): 26 x 399 x 269
Battery
48 Wh Lithium-Polymer, 3-cell
Operating System
Microsoft Windows 10 Home 64 Bit
Camera
Webcam: HD 720p
Additional features
Speakers: Stereo, Keyboard: Chiclet, Keyboard Light: yes, 24 Months Warranty
Weight
2.6 kg



Pricecompare

Reviews for the Asus TUF Gaming F17 FX706LI-HX177T

ASUS TUF Gaming F17 (FX706) review – big boy with a low price
Source: Laptop Media English EN→zh-CN
Yes, this device does well, what it’s intended to do. It brings AAA gaming on a budget. Albeit it’s not able to handle the latest titles at their maximum visual settings, most people will be satisfied by the performance it offers. On the other hand, some things were sacrificed. Usually, the first thing to be compromised is the build quality, but here, we feel this wasn’t the case. Despite the fact that ASUS uses plastic for the majority of this build, the notebook is pretty strong and doesn’t feel cheap. However, the battery life is mediocre. If you get the device with the 48Wh unit, it will last for no more than 6 hours of Web browsing, and a bit over 4 hours of video playback. This figure will be a lot smaller if you multitask or add an intensive workload. ASUS TUF Gaming F17 (FX706)’s 144Hz IPS panel (AUO B173HAN04.9) has a Full HD resolution, comfortable viewing angles, and a good contrast ratio. Thankfully, it doesn’t flicker at any brightness level.
Single Review, online available, Very Long, Date: 05/31/2021
ASUS TUF Gaming F17 (FX706) - disassembly and upgrade options
Source: Laptop Media English
Single Review, online available, Short, Date: 05/31/2021

Comment

NVIDIA GeForce GTX 1650 Ti Mobile:

适用于笔记本电脑的中端专用图形卡,使用不带光线追踪和Tensor核心的Turing TU117芯片。应该比GTX 1650快一点,但是也可以提供TGP 55至80瓦(以及两个封装)的不同型号。



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


i7-10870H:

基于咖啡湖的处理器,适用于大型、重型笔记本电脑。 内置8个处理器内核,时钟为2.2~5GHz(8个内核最高4.2GHz),支持Hyper穿线。 采用第3代14nm英特尔工艺制造。

» Further information can be found in our Comparison of Mobile Processsors.


17.30":

这个大尺寸屏幕常见于以桌面使用为主的笔记本电脑。

大尺寸可以让屏幕有更高的分辨率。因而例如字体等的细节将会更丰富。不过另一方面,小屏幕的功耗会较低,而设备也会更轻盈小巧,售价更低。

» To find out how fine a display is, see our DPI List.


2.6 kg: 这是14到16寸的标准笔记本电脑的常见重量。


» Further information can be found in our Notebook Purchase Guide.
