Asus ZenBook UX430UA-DH74

Specifications

Asus ZenBook UX430UA-DH74
Asus ZenBook UX430UA-DH74 (ZenBook UX430 Series)
Processor
Intel Core i7-8550U 4 x 1.8 - 4 GHz, Kaby Lake Refresh
Graphics adapter
Intel UHD Graphics 620
Memory
16 GB
, DDR4-2133 MHz
Display
14.00 inch 16:10, 1920 x 1200 pixel 162 PPI, IPS
Storage
512 MB NAND Flash, 0.5 GB
Connections
1 USB 2.0, 1 USB 3.0 / 3.1 Gen1, 1 HDMI, Audio Connections: 3.5mm, Card Reader: SD, 1 x USB 3.1 Type C
Networking
802.11 a/b/g/n/ac (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/), Bluetooth 4.1
Size
height x width x depth (in mm): 15.9 x 324 x 225
Battery
50 Wh Lithium-Polymer, 3-cell, Battery runtime (according to manufacturer): 9 h
Operating System
Microsoft Windows 10 Home 64 Bit
Camera
Webcam: HD 720p
Additional features
Speakers: Stereo, Keyboard: Chiclet, Keyboard Light: yes
Weight
1.25 kg
Price
1000 Euro
Links
Asus homepage
Asus notebook section



Pricecompare

Average Score: 80% - good
Average of 2 scores (from 2 reviews)

Reviews for the Asus ZenBook UX430UA-DH74

80% Asus ZenBook UX430U
Source: PC Mag English EN→zh-CN Archive.org version
The sleek but affordable Asus UX430U packs an Intel Core i7 and a sharp 14-inch full HD display, making it a powerful ultraportable that won't break the bank.
Single Review, online available, Medium, Date: 02/28/2018
Rating: Total score: 80%
80% Asus ZenBook UX430UA Review
Source: Laptop Mag English EN→zh-CN Archive.org version
The Asus ZenBook UX430UA offers powerful specs and a stunning screen in an extremely portable package.
Single Review, online available, Medium, Date: 11/07/2017
Rating: Total score: 80%

Comment

Intel UHD Graphics 620:

集成显卡（GT2,24 EU），可以在一些Kaby-Lake-Refresh 中央处理器型号（15 W ULV系列）上找到。技术上与之前名为HD Graphics 620的Kaby-Lake的显卡相同。



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


i5-8550U:

基于Kaby-Lake-Refresh的低功耗四核处理器。这四个内核的时钟频率介于1.8和4 GHz之间（Turbo Boost），并支持超线程。集成GPU的时钟频率介于300和1,150 MHz之间。 SoC采用14nm + FinFET工艺制造。

» Further information can be found in our Comparison of Mobile Processsors.


14.00":

大体上，这个屏幕尺寸常见于亚笔记本电脑，超极本和变形本中。对这三类产品来说这个尺寸都较大。亚笔记本中尺寸最大的机型是采用这个屏幕尺寸。

大尺寸可以让屏幕有更高的分辨率。因而例如字体等的细节将会更丰富。不过另一方面，小屏幕的功耗会较低，而设备也会更轻盈小巧，售价更低。

» To find out how fine a display is, see our DPI List.


1.25 kg: 这是10到11寸大尺寸平板电脑，小型亚笔记本，超极本和变形本的常见重量。


» Further information can be found in our Notebook Purchase Guide.
