Asus VivoBook Flip 14 TM420IA

Specifications

Asus VivoBook Flip 14 TM420IA
Asus VivoBook Flip 14 TM420IA (VivoBook Flip 14 Series)
Processor
AMD Ryzen 7 4700U 8 x 2 - 4.1 GHz, Renoir (Zen 2)
Graphics adapter
AMD Radeon RX Vega 7 - 512 MB, Core: 1600 MHz, Memory: 1333 MHz, DDR4, 19.40.44.03
Memory
8192 MB
, 双通道内存
Display
14.00 inch 16:9, 1920 x 1080 pixel 157 PPI, 10点电容, native pen support, BOE NV140FHM-N49, IPS, BOE07F7, glossy: yes, 60 Hz
Mainboard
AMD Promontory/Bixby FCH
Storage
Samsung PM991 MZVLQ512HALU, 512 GB
Soundcard
AMD Raven/Renoir/VanGogh/Cezanne - Audio Processor - HD Audio Controller
Connections
3 USB 2.0, 2 USB 3.0 / 3.1 Gen1, 2 USB 3.1 Gen2, 1 HDMI, 1 Kensington Lock, Audio Connections: 3.5毫米二合一, Card Reader: MicroSD
Networking
Intel Dual Band Wireless-AC 8265 (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5), Bluetooth 4.2
Size
height x width x depth (in mm): 18.2 x 324 x 220
Battery
42 Wh Lithium-Polymer, 3-cell
Operating System
Microsoft Windows 10 Home 64 Bit
Camera
Webcam: 720p
Primary Camera: 0.9 MPix
Additional features
Speakers: 立体声扬声器, Keyboard: 巧克力背光键盘, Keyboard Light: yes, Radeon Settings Lite, 12 Months Warranty
Weight
1.562 kg, Power Supply: 147 g
Price
700 USD



Pricecompare

Average Score: 77.68% - good
Average of 4 scores (from 6 reviews)
price: - %, performance: 77%, features: 51%, display: 76% mobility: 74%, workmanship: 78%, ergonomy: 75%, emissions: 89%

Reviews for the Asus VivoBook Flip 14 TM420IA

80.7% 华硕VivoBook Flip 14 TM420IA笔记本电脑评测:不需要i7 | Notebookcheck
这是价格实惠的Asus VivoBook Flip系列的又一本垒打,因为这台配备AMD的可翻转本比市场上许多Intel Core i7替代产品更快,更便宜。
ASUS VivoBook Flip 14 TM420 - disassembly and upgrade options
Source: Laptop Media English
Support, online available, Short, Date: 12/18/2020
ASUS VivoBook Flip 14 TM420 review – ASUS is back with a budget-conscious 2-in-1
Source: Laptop Media English EN→zh-CN
In conclusion, we would like to say that the VivoBook Flip 14 TM420 is a stunning looking piece of machinery. The color, the styling, the design – simply beautiful. Also, it was extremely snappy thanks to its fast NVMe SSD and the almighty Ryzen 4000U processors, which have the power to skip past any light-to-medium workload. And on top of that, you have one free RAM SODIMM slot for upgrades, providing the option for dual-channel memory, which boosts the graphics performance by quite a lot.
Single Review, online available, Very Long, Date: 12/18/2020
70% Asus VivoBook Flip 14
Source: PC Mag English EN→zh-CN
The Asus VivoBook Flip is a good budget convertible with no major weak points. The build is compact and lightweight, it has a healthy selection of ports and a nice screen, and battery life is decent. The performance, in particular, is a strong suit, thanks to the Ryzen 7 chip, which tops the Ryzen 5 and Intel alternatives in machines around the same price.
Single Review, online available, Long, Date: 09/15/2020
Rating: Total score: 70%
80% Asus Vivobook Flip 14 (2020) review
Source: Techradar English EN→zh-CN
A surpringly powerful 2-in-1, the Asus Vivobook Flip 14 is an excellent multitasker with some surprisingly good graphics performance for a hybrid laptop. Though the 8GB RAM slows it down a bit when working with a lot of multimedia data or Chrome tabs, its more than enough for school or workplace productivity tasks.
Single Review, online available, Long, Date: 09/03/2020
Rating: Total score: 80%
80% Asus VivoBook Flip 14 2020 review
Source: Laptop Mag English EN→zh-CN
The Asus VivoBook Flip 14 has a killer AMD Ryzen 4000-series CPU that crushed competitors within the same price range, and even outperformed pricier laptops (ahem, the Dell XPS 13). However, you’ll have to stomach a dim display and below-average battery life if you buy this notebook.
Single Review, online available, Very Long, Date: 09/02/2020
Rating: Total score: 80%
ASUS Vivobook Flip 14 TM420IA: Fleksibel dan Berperforma
Source: Pemmzchannel ID→zh-CN
Single Review, online available, Short, Date: 12/08/2020

Comment

AMD Vega 7:



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


R7 4700U:

移动式八核APU,使用Zen 2内核,频率为2-4 GHz,Vega图形卡具有7个CU,时钟频率高达1600 MHz。与更快的4800U相比,4700U提供的睿频略低,并且不支持SMT /超线程。

» Further information can be found in our Comparison of Mobile Processsors.


14.00":

大体上,这个屏幕尺寸常见于亚笔记本电脑,超极本和变形本中。对这三类产品来说这个尺寸都较大。亚笔记本中尺寸最大的机型是采用这个屏幕尺寸。

大尺寸可以让屏幕有更高的分辨率。因而例如字体等的细节将会更丰富。不过另一方面,小屏幕的功耗会较低,而设备也会更轻盈小巧,售价更低。

» To find out how fine a display is, see our DPI List.


1.562 kg: 这是11到13寸的超大尺寸平板电脑,亚笔记本电脑,超极本和变形本的常见重量。


» Further information can be found in our Notebook Purchase Guide.
