Lenovo ThinkBook 14-IML-20RV006TGE

Specifications

Lenovo ThinkBook 14-IML-20RV006TGE
Lenovo ThinkBook 14-IML-20RV006TGE (ThinkBook 14 Series)
Processor
Intel Core i5-10210U 4 x 1.6 - 4.2 GHz, Comet Lake-U
Graphics adapter
Memory
8192 MB
, DDR4-2666
Display
14 inch 16:9, 1920 x 1080 pixel 157 PPI, Chi Mei, CMN14D4, N140HCA-EAC, IPS, glossy: no
Mainboard
Intel Comet Lake-U PCH-LP Premium
Storage
Samsung SSD PM981a MZVLB256HBHQ, 256 GB
, 190 GB free
Soundcard
Intel Comet Lake PCH-LP - cAVS
Connections
1 USB 2.0, 3 USB 3.0 / 3.1 Gen1, 1 USB 3.1 Gen2, 1 Thunderbolt, 1 HDMI, 1 DisplayPort, Audio Connections: 3.5mm, Card Reader: 4-in-1 media reader (MMC, SD, SDHC, SDXC), 1 Fingerprint Reader, 2 x USB-C
Networking
Realtek RTL8168/8111 Gigabit-LAN (10/100/1000/2500/5000MBit/s), Intel Wireless-AC 9560 (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5), Bluetooth 5.0
Size
height x width x depth (in mm): 17.9 x 326 x 230
Battery
45 Wh, 3900 mAh Lithium-Ion, Battery runtime (according to manufacturer): 9 h
Operating System
Microsoft Windows 10 Pro 64 Bit
Camera
Webcam: HD 720p
Additional features
Speakers: Stereo, Keyboard: Chiclet, Keyboard Light: no, 65-Watt-Netzteil, 12 Months Warranty
Weight
1.57 kg, Power Supply: 352 g
Price
700 EUR



Pricecompare

Average Score: 82% - good
Average of 1 scores (from 3 reviews)
price: - %, performance: 65%, features: 63%, display: 76% mobility: 74%, workmanship: 83%, ergonomy: 81%, emissions: 95%

Reviews for the Lenovo ThinkBook 14-IML-20RV006TGE

82% Lenovo ThinkBook 14 Review: Business Laptop with Great Connectivity | Notebookcheck
Lenovo's ThinkBooks are aimed primarily at business users. They lack most of the ThinkPad series' numerous business features but should still perform adequately nevertheless. Find out in our review how well the new subnotebook did, and what its pros and cons are.
Lenovo ThinkBook 14 review – a whole load of I/O for a 14-incher
Source: Laptop Media English EN→zh-CN
Another disadvantage is the relatively poor touchpad experience and the unevenness in the keyboard feedback. Thankfully, though, the laptop has a fingerprint reader, embedded in the Power On/Off switch. Interestingly enough, the ThinkBook 14 has a 25W L1 Power Limit, which provides quite the headroom for a high frequency, during long time periods. However, the cooling is not really able to cope with it, which results in very high temperatures during full load.
Comparison, online available, Very Long, Date: 03/04/2020
ThinkBook 14: Laptop văn phòng CPU thế hệ 10 giá tốt
Source: FPT shop VN→zh-CN
Single Review, online available, Medium, Date: 12/05/2019
Review Lenovo ThinkBook 14-IML: Laptop Bisnis, Harga Ekonomis, Fitur Fantastis
Source: Pemmzchannel ID→zh-CN
Single Review, online available, Very Long, Date: 03/03/2020

Comment

Intel UHD Graphics 620:

集成显卡(GT2,24 EU),可以在一些Kaby-Lake-Refresh 中央处理器型号(15 W ULV系列)上找到。技术上与之前名为HD Graphics 620的Kaby-Lake的显卡相同。



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


i5-10210U:

基于Comet Lake的低功耗四核处理器(在技术上与Whiskey Lake相同,但仍采用14nm ++生产)。通过超线程(8个线程),CPU频率在1.6和4.2 GHz之间(全核最大为3.9 GHz)。集成内存控制器支持DDR4-2666,性能可以由OEM调整(可能为10-25瓦,默认为15W)。

与更快的i5-10510U相比,三级缓存从8 MB减少到6 MB。

» Further information can be found in our Comparison of Mobile Processsors.


14":

大体上,这个屏幕尺寸常见于亚笔记本电脑,超极本和变形本中。对这三类产品来说这个尺寸都较大。亚笔记本中尺寸最大的机型是采用这个屏幕尺寸。

大尺寸可以让屏幕有更高的分辨率。因而例如字体等的细节将会更丰富。不过另一方面,小屏幕的功耗会较低,而设备也会更轻盈小巧,售价更低。

» To find out how fine a display is, see our DPI List.


1.57 kg: 这是11到13寸的超大尺寸平板电脑,亚笔记本电脑,超极本和变形本的常见重量。


» Further information can be found in our Notebook Purchase Guide.
