Intel Core i7-6920HQ

Intel 6920HQ

英特尔酷睿i7-6920HQ是用于笔记本电脑的高端四核处理器。 它是Skylake架构系列的顶级型号,在2015年9月正式发布。 除了四个支持超线程的CPU核心运行于2.9 -  3.8 GHz(四核:最大3.4 GHz,双核:最大3.6 GHz),该芯片还集成了HD Graphics 530显卡和双通道DDR4- 2133 / DDR3L-1600内存控制器。 该CPU采用14纳米工艺与FinFET晶体管制造工艺。

架构

Skylake架构取代了Haswell和Broadwell,为从4.5到45瓦热设计功率的处理器都提供了相同的微架构。Skylake架构设计的众多改进包括增加了乱序缓冲,优化的预取和分支预测以及超线程模式的性能改进。 不过整体上,它的单位时钟频率性能仅增加了5%到10%(相比Haswell)而相比Broadwell架构不足5%,这对于一个新架构(“Tock”)来说十分低。

性能

根据时钟速率和改进的架构,酷睿i7-6920HQ应当与主频略高的前代产品酷睿i7-4910MQ(Haswell)相当。 在长时间负载下,Skylake芯片应该可以凭借更加先进的14纳米制程带来的更高能效和更低发热量占据优势。

它可以轻松承担大型软件或繁重多程序运行的任务。

图形

它的集成显示单元名为HD Graphics 530,代表了Skylake显卡的"GT2"版本(Intel第九代)。 它的24个执行单元,也被称为EU,主频在350-1050 MHz之间,提供的性能高于前代HD Graphics 4600约20%。 2015年的游戏应该可以在低中设置下流畅运行。 有关性能和功能的详细信息,请参考我们的HD Graphics 530页面。

功耗

设计热设计功率45瓦(包括CPU,GPU和内存控制器),酷睿i7-6920HQ最适合于15英寸或更大的笔记本电脑。 它的TDP也可以降低到35瓦(cTDP降低),从而同时降低发热量和性能。

SeriesIntel Core i7
CodenameSkylake

Series: Core i7 Skylake

Intel Core i7-6920HQ « 2.9 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i7-6970HQ2.8 - 3.7 GHz4 / 8 cores8 MB L3
Intel Core i7-6870HQ2.7 - 3.6 GHz4 / 8 cores8 MB L3
Intel Core i7-6820HK2.7 - 3.6 GHz4 / 8 cores8 MB L3
Intel Core i7-6820HQ2.7 - 3.6 GHz4 / 8 cores8 MB L3
Intel Core i7-6770HQ2.6 - 3.5 GHz4 / 8 cores6 MB L3
Intel Core i7-6700HQ2.6 - 3.5 GHz4 / 8 cores6 MB L3
Intel Core i7-6567U3.3 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i7-6600U2.6 - 3.4 GHz2 / 4 cores4 MB L3
Intel Core i7-6650U2.2 - 3.4 GHz2 / 4 cores4 MB L3
Intel Core i7-6560U2.2 - 3.2 GHz2 / 4 cores4 MB L3
Intel Core i7-6500U2.5 - 3.1 GHz2 / 4 cores4 MB L3
Clock Rate2900 - 3800 MHz
Level 1 Cache256 KB
Level 2 Cache1 MB
Level 3 Cache8 MB
Number of Cores / Threads4 / 8
Power Consumption (TDP = Thermal Design Power)45 Watt
Manufacturing Technology14 nm
Die Size122 mm2
Max. Temperature100 °C
SocketBGA
FeaturesDual-Channel DDR3L-1600/DDR4-2133 Memory Controller, AVX, AVX2, Quick Sync, Virtualization, AES-NI, vPro, TXT
GPUIntel HD Graphics 530 (350 - 1050 MHz)
64 Bit64 Bit support
Architecturex86
Announcement Date09/01/2015
Product Link (external)ark.intel.com

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 729     avg: 735     median: 734.5 (5%)     max: 740 Points
AMD A4-1200
31 -96%
...
708 -4%
Intel Core i5-8305G
710 -3%
Intel Core i7-7820HQ
710 -3%
Intel Core i7-6770HQ
711 -3%
Intel Xeon E3-1505M v5
715 -3%
717 -2%
Intel Core i7-7700HQ
727 -1%
Intel Xeon E3-1505M v6
728 -1%
Intel Core i5-1230U
734 0%
Intel Core i7-6920HQ
735
736 0%
739 1%
743 1%
Intel Xeon E3-1535M v5
746 1%
748 2%
749 2%
Intel Core i5-8279U
750 2%
Intel Core i5-8400H
762 4%
Intel Core i7-8705G
763 4%
...
5600 662%
max:
15842 2055%
0%
100%
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 156     avg: 159.5     median: 159.5 (48%)     max: 163 Points
AMD A4-1200
19 -88%
...
Intel Core i5-8305G
157 -2%
157 -2%
157.7 -1%
Intel Core i5-7440HQ
158 -1%
Intel Core i7-8709G
158 -1%
Intel Core i7-7660U
158.5 -1%
159 0%
Intel Core i7-7567U
159 0%
Intel Xeon E3-1535M v5
159.3 0%
Intel Core i7-6920HQ
159.5
160.4 1%
160.9 1%
161 1%
162.7 2%
163 2%
Intel Core i7-7820HQ
163 2%
163.9 3%
Intel Core i5-1035G4
164.4 3%
Intel Core i5-1035G1
164.6 3%
...
311 95%
max:
332 108%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
7.9 Points (10%)
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
1.9 Points (46%)
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
5906 points (36%)
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
22527 points (16%)
wPrime 2.10 - wPrime 2.0 1024m *
326 s (4%)
wPrime 2.10 - wPrime 2.0 32m *
10.2 s (2%)
WinRAR - WinRAR 4.0
4274 points (7%)
X264 HD Benchmark 4.0 - x264 Pass 2
45.3 fps (16%)
X264 HD Benchmark 4.0 - x264 Pass 1
176.5 fps (41%)
TrueCrypt - TrueCrypt Serpent
0.4 GB/s (0%)
TrueCrypt - TrueCrypt Twofish
0.7 GB/s (13%)
TrueCrypt - TrueCrypt AES
4.2 GB/s (11%)
3DMark 06 - CPU - 3DMark 06 - CPU
7807 Points (17%)
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
10.2 s (2%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
22.9 s (1%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
559 s (2%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
25990 Points (23%)
3DMark 11 - 3DM11 Performance Physics
8791 Points (24%)
3DMark - 3DMark Cloud Gate Physics
7239 Points (18%)
3DMark - 3DMark Fire Strike Standard Physics
10016 Points (18%)
Geekbench 4.0 - Geekbench 4.0 64 Bit Single-Core
4484 points (61%)
Geekbench 4.0 - Geekbench 4.0 64 Bit Multi-Core
14147 points (34%)
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
13821 points (25%)
Geekbench 3 - Geekbench 3 32 Bit Single-Core
3646 points (71%)
Geekbench 3 - Geekbench 3 64 Bit Multi-Core
14513 points (23%)
Geekbench 3 - Geekbench 3 64 Bit Single-Core
3814 points (57%)
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
972 ms (1%)
Sunspider - Sunspider 1.0 Total Score *
70.7 ms (1%)
Octane V2 - Octane V2 Total Score
39548 Points (36%)
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
